MANUAL TRANSMISSION 7B-89 Counter Shaft (6MT) Components Disassembly 1. Remove the bearing fixing snap ring using snap ring pliers. 2. Remove the bearing; counter front using the bear- ing remover 5-8840-2587-0. 3. Remove the anti-lash plate fixing snap ring using snap ring pliers. 4. Remove the anti-lash plate using the flange holder 5-8840-4056-0. 5. Remove the three coil springs from the 5th gear. using a bearing remover. Legend 1. Snap ring 6. Straight pin 2. Bearing; Counter front 7. Counter shaft assembly 3. Snap ring 8. Bearing; Counter rear 4. Anti-lash plate 9. Thrust washer 5. Coil spring 10. Collar 1 2 3 7 8 9 10 4 6 5 N7A0403E N7A1253E N7A0397E |
