ENGINE ELECTRICAL 6D-29 4. Check for continuity between slip ring and rotor core or slip ring and rotor shaft. Rear Ball Bearing Stator Coil 1. Check for continuity between respective phases. In case of no continuity, replace the stator. Legend 1. Slip ring Legend 1. Slip ring N6A3535E N6A3536E Bearing press-in measurement: L mm (in) Standard 41.8 — 42.0 (1.64 — 1.65) Legend 1. Stopper ring Legend 1. Tester N6A3537E N6A3538E |
