6A1-68 4JB1/4JB1-TC/4JG2/4JH1-TC - ENGINE 2. Oil Pump Assembly • Prepare a solution of 80% engine oil and 20% mo- lybdenum disulfide. • Apply and ample coat of the solution to the teeth of the oil pump pinion. • Apply engine oil to oil pipe O-ring and insert the O- ring in O-ring hold on cylinder block. • Install oil pump asm with oil pipe in cylinder block and tighten fixing bolts to the specified torque. Tighten: • Oil pump bolt to 19 N ⋅m (1.9 kg⋅m / 14 lb⋅ft) • Tighten sleeve nut to the specified torque. Tighten: • Oil pump bolt to 25 N ⋅m (2.5 kg⋅m / 18 lb⋅ft) 3. Oil Pan Assembly Above works refer to “OIL PAN” Section in this 4. Timing Belt 1) Camshaft timing pulley 2) Timing belt Above works refer to “TIMING BELT (Belt 5. Timing Gear (Gear Type) 1) Camshaft timing gear Above works refer to “TIMING GEAR (Gear 6. Cylinder Head Assembly and Gasket 1) Cylinder head gasket Above works refer to “CYLINDER HEAD AS- 7. Engine Assembly 1) Engine assembly (With Power Steering Model) 7) A/C compressor assembly (A/C Model) 8. Transmission and Clutch Assembly N6A3106E N6A3305E |
