REAR AXLE 4B-25 12. Outer Oil Seal Apply grease to the oil seal lip inner and outer cir- 13. Axle Shaft 1) Clean the axle shaft. Take care not to damage the oil seal. 4) Tighten the axle shaft nuts to the specified torque a little at a time in the numerical order Tighten: ⋅m (4.7 kg⋅m / 34 lb⋅ft) 14. Wheel and Tire Tighten: • NHR Dual Tire, NKR NPR Flat low: 343 N ⋅m (35 kg⋅m / 253 lb ⋅ft) • Except above models: 490 N ⋅m (50 kg⋅m / 361 lb⋅ft) • NHR, NKR, S/Tire: 167 N ⋅m (17 kg⋅m / 123 lb⋅ft) N4A0119E N4A0120E |
