8-368 CAB AND CHASSIS ELECTRICAL Diagnostic Mode Door Lock Operational Test 1. Check for continuity between the 1-B-219 connec- tor and the 2-B-219 connector (harness side). 2. Check the remaining connectors to see that they have battery voltage. 3. If the above conditions are normal but the lock does not operate, check the door lock switch (driv- N8A5454E 5 6 1 2 9 8 10 4 3 7 Connector 1(B/R) 2(G/R) Position Unlock Lock B-219 Harness side + + - - N8A5455E |
