Isuzu N-Series. Service manual - part 1080
8-32 CAB AND CHASSIS ELECTRICAL
For 12 Volt-4JH1 Engine
HEATER &
A/C RELAY
10A
HEAD LIGHT LH
F-24
10A
HEAD LIGHT RH
F-23
10A
STARTER
F-22
F-21
10A
ABS (IG)
F-20
15A
HORN, HAZARD
F-19
F-18
F-17
10A
METER
F-16
15A
AUDIO (IG), CIGAR LIGHTER
F-15
F-14
F-13
10A
H/LAMP LEVEL
F-12
10A
TURN LIGHT
15A
F-11
15A
FRONT WIPER & WASHER
F-10
15A
ENG. (B2)
F-9
15A
ENG. (B1)
F-8
10A
TAIL LIGHT
F-7
F-25
10A
FRT FOG LIGHT, CORNERING LAMP
F-6
10A
STOP LIGHT
F-5
15A
AUDIO (B), DOOR LOCK
F-4
15A
REAR HEATER
F-3
15A
FUEL HEATER
F-2
10A
AIR CON
F-1
30A
POWER WINDOW
FL-26
30A
HEAD LAMP
FL-4
30A
FL-25
HEATER
INDICATION ON LABEL
INDICATION ON LABEL
KEY ON
RELAY
HEATER
RELAY
TAIL
RELAY
HEAD LIGHT
RELAY
COMBINATION SWITCH
STARTER
STARTER
RELAY
CONDENSER FAN
ABS UNIT
GLOW PLUG
GLOW PLUG
RELAY
CONDENSER FAN
RELAY
KEY SW OFF
ACC
ON
ST
60A
GLOW
FL-3
60A
ABS
FL-9
60A
STARTER
FL-8
50A
KEY
FL-2
REAR FOG
RELAY
REAR FOG
COMBINATION
SWITCH
CHARGE
WARNING
RELAY
MARKER LIGHT
100A
MAIN
FL-1
MARKER
LIGHT
RELAY
15A
F-26
10A
F-27
F-28
GENERATOR
GENERATOR B
RR FOG
COND. FAN
MARKER LAMP
N8A5585E
