MANUAL TRANSMISSION 7B–53 26. Install the top gear shaft. 1. Align the projection of the hub No.2 with the synchronizer ring slots, and install the top gear 2. Check that the gear rotates smoothly. 226RW006 27. Install the counter gear shaft. 1. Temporarily install the counter gear shaft to the intermediate plate. 226RW028 2. Using installer J–42796 and a hammer, drive in the center bearing as shown. NOTE: Outer race snap ring groove toward rear. 226RW007 Reference: Drive in the counter rear bearing 226RW022 |
