4C–12 DRIVE SHAFT SYSTEM 8. Remove lock washer and lock screw. 901RW054 10. Remove hub and disc assembly. 11. Remove ABS sensor ring. 12. Remove outer bearing. the following manner. D Apply a scribe mark(1) to disc to hub. D Clamp the hub and disc assembly in a vise, using 411RS003 D Place hub on a suitable work surface and remove 411RS004 Inspection and Repair Make necessary correction or parts replacement if wear, D Hub D Hub bearing oil seal D Knuckle spindle D Disc D Caliper D Shift on the fly system parts (Cap, Hub flange, Shim, D ABS sensor ring For inspection and servicing of disc caliper and related Reassembly 1. Install wheel pin. D Place the hub on a wood workbench or a block of |
