6A–85 ENGINE MECHANICAL (6VD1 3.2L) f The ”Grade” mark (1) is stamped at the position 012RS006 Reassembly 1. Install cylinder block. f Install the main bearings to the cylinder block and f Be sure that they are positioned correctly. f Apply new engine oil to the upper and lower main NOTE: Do not apply engine oil to the bearing back faces. 015RS012 Legend (1) Number 1 and 4 main bearing upper and lower. f Carefully mount the crankshaft. f Apply engine oil to the thrust washer. f Assemble the thrust washer to the No. 3 bearing 015RS013 3. Install rear oil seal retainer. f Remove oil on cylinder block and retainer fitting f Apply sealant (TB1207B or equivalent) to retainer f The oil seal retainer must be installed within 5 015RW002 Legend (1) Around Bolt Holes |
