5C–29 POWER–ASSISTED BRAKE SYSTEM Inspection and Repair Visual Check Make necessary parts replacement if cuts, nicks, f Yoke clevis f Valve body guard f Silencer f Filter plate and seal assembly Installation 1. Install plate and seal assembly. 3. Install 2 gaskets and spacer. specified torque. Torque: 20 N·m (15 lb ft) 9. Install vacuum booster, refer to “Vacuum Booster” in this section. 10. Install master cylinder, refer to “Master Cylinder” in this section and after installation, perform brake pedal Vacuum Booster Overhaul Vacuum Booster The vacuum booster cannot be disassembled for repair. |
