Isuzu D-Max / Isuzu Rodeo (TFR/TFS). Service manual - part 1042
CLUTCH 7C-27
CLUTCH CONTROL
REMOVAL AND INSTALLATION
Except 6VD1 Engine
Removal Steps
1. Pin2. Jaw joint pin3. Pedal assembly4. Oil line5. Master cylinder assembly6. Oil line7. Slave cylinder assembly8. Damper cylinder assembly
Installation Steps
To install, follow the removal steps in thereverse order.
