Infiniti Q70 (2019 year). Instruction

2-62

Instruments and controls

PROGRAMMING HomeLink

FOR

CANADIAN CUSTOMERS AND
GATE OPENERS

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission –
which may not be long enough for
HomeLink

to pick up the signal during

programming. Similar to this Canadian law,
some U.S. gate operators are designed to
“time-out” in the same manner.

If you live in Canada or you are having
difficulties programming a gate operator or
garage door opener by using the “Program-
ming HomeLink

” procedures, replace “Pro-

gramming HomeLink

” Step 2 with the

following:

NOTE:

When programming a garage door opener,
etc., unplug the device during the “cycling”
process to prevent possible damage to the
garage door opener components.

Step 2: Using both hands, simultaneously
press and hold the desired HomeLink

button and the hand-held transmitter but-
ton. During programming, your hand-held
transmitter may automatically stop trans-
mitting. Continue to press and hold the
desired HomeLink

button while you press

and re-press (“cycle”) your hand-held trans-

mitter every two seconds until the frequency
signal has been learned. The HomeLink

indicator light will flash slowly and then
rapidly after several seconds upon success-
ful programming. DO NOT release until the
HomeLink

indicator light flashes slowly and

then rapidly. When the indicator light flashes
rapidly, both buttons may be released. The
rapid flashing indicates successful program-
ming.

Proceed with “Programming HomeLink

”

step 3 to complete.

Remember to plug the device back in when
programming is completed.

OPERATING THE HomeLink

UNIVERSAL TRANSCEIVER

The HomeLink

Universal Transceiver, after

it is programmed, can be used to activate the
programmed device. To operate, simply
press and release the appropriate pro-
grammed HomeLink

Universal Transceiver

button. The amber indicator light will illumi-
nate while the signal is being transmitted.

For convenience, the hand-held transmitter
of the device may also be used at any time.

PROGRAMMING TROUBLE-
SHOOTING

If the HomeLink

does not quickly learn the

hand-held transmitter information:
. replace the hand-held transmitter bat-

teries with new batteries.

. position the hand-held transmitter with

its battery area facing away from the
HomeLink

surface.

. press and hold both the HomeLink

and

hand-held transmitter buttons without
interruption.

. position the hand-held transmitter 1-3 in

(26-76 mm) away from the HomeLink

surface. Hold the transmitter in that
position for up to 15 seconds. If
HomeLink

is not programmed within

that time, try holding the transmitter in
another position - keeping the indicator
light in view at all times.

If you have any questions or are having
difficulty programming your HomeLink

buttons, refer to the HomeLink

web site

at: www.homelink.com or 1-800-355-
3515.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLEARING THE PROGRAMMED
INFORMATION

The following procedure clears the pro-
grammed information from both buttons.
Individual buttons cannot be cleared. How-
ever, individual buttons can be repro-
grammed, see “Reprogramming a single
HomeLink

button” (P.2-63).

To clear all programming

1. Press and hold the two outer HomeLink

buttons until the indicator light begins to
flash in approximately 10 seconds. Do
not hold for longer than 20 seconds.

2. Release both buttons.

HomeLink

is now in the programming mode

and can be programmed at any time begin-
ning with “Programming HomeLink

” - Step

REPROGRAMMING A SINGLE
HomeLink

BUTTON

To reprogram a HomeLink

Universal Trans-

ceiver button, complete the following.

1. Press and hold the desired HomeLink

button. Do not release the button.

2. The indicator light will begin to flash

after 20 seconds. Without releasing the
HomeLink

button, proceed with “Pro-

gramming HomeLink

” - Step 1.

For questions or comments, contact
HomeLink

at: www.homelink.com or 1-

800-355-3515.

The HomeLink

Universal Transceiver but-

ton has now been reprogrammed. The new
device can be activated by pushing the
HomeLink

button that was just pro-

grammed. This procedure will not affect
any other programmed HomeLink

buttons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change
the codes of any non-rolling code device that
has been programmed into HomeLink

Consult the Owner’s Instruction of each device
or call the manufacturer or retailer of those
devices for additional information.

When your vehicle is recovered, you will
need to reprogram the HomeLink

Univer-

sal Transceiver with your new transmitter
information.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.

For Canada:

This device complies with Industry Canada
licence-exempt RSS standard(s). Operation
is subject to the following two conditions:
(1) this device may not cause interference,
and (2) this device must accept any inter-
ference, including interference that may
cause undesired operation of the device.

Instruments and controls

2-63

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-2

Pre-driving checks and adjustments

A key number plate is supplied with your
keys. Record the key number and keep it in a
safe place (such as your wallet), not in the
vehicle. If you lose your keys, it is recom-
mended you visit an INFINITI retailer for
duplicates by using the key number. INFINITI
does not record any key numbers so it is very
important to keep track of your key number
plate.

A key number is only necessary when you
have lost all keys and do not have one to
duplicate from. If you still have a key, it can
be duplicated without knowing the key
number.

SPA2222

Intelligent Keys (2 sets)

Mechanical keys (inside the Keys) (2
sets)

Key number plate (1 set)

INTELLIGENT KEY

Your vehicle can only be driven with the
Intelligent Keys which are registered to your
vehicle’s Intelligent Key system components
and INFINITI Vehicle Immobilizer System
components. As many as 4 Intelligent Keys
can be registered and used with one vehicle.
The new keys must be registered by an
INFINITI retailer prior to use with the
Intelligent Key system and INFINITI Vehicle
Immobilizer System of your vehicle. Since the

registration process requires erasing all
memory in the Intelligent Key components
when registering new keys, be sure to take
all Intelligent Keys that you have to the
INFINITI retailer.

It is possible that the Intelligent Key func-
tions become canceled. Contact an INFINITI
retailer.

CAUTION

. Be sure to carry the Intelligent Key

with you when driving. The Intelli-
gent Key is a precision device with a
built-in transmitter. To avoid dama-
ging it, please note the following.

— The Intelligent Key is water re-

sistant; however, wetting may
damage the Intelligent Key. If the
Intelligent Key gets wet, immedi-
ately wipe until it is completely
dry.

— Do not bend, drop or strike it

against another object.

— If the outside temperature is

below 14°F (−10°C), the battery
of the Intelligent Key may not
function properly.

— Do not place the Intelligent Key

for an extended period in a place

KEYS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

where temperatures exceed
140°F (60°C).

— Do not change or modify the

Intelligent Key.

— Do not use a magnet key holder.

— Do not place the Intelligent Key

near an electric appliance such as
a television set or personal com-
puter.

— Do not allow the Intelligent Key

to come into contact with water
or salt water, and do not wash it
in a washing machine. This could
affect the system function.

. If an Intelligent Key is lost or stolen,

INFINITI recommends erasing the ID
code of that Intelligent Key. This will
prevent the Intelligent Key from un-
authorized use to unlock the vehicle.
For information regarding the eras-
ing procedure, it is recommended you
visit an INFINITI retailer.

SPA2033

Mechanical key

To remove the mechanical key, release the
lock knob at the back of the Intelligent Key.

To install the mechanical key, firmly insert it
into the Intelligent Key until the lock knob
returns to the lock position.

Use the mechanical key to lock or unlock the
doors, glove box and trunk pass-through lid,
if they are equipped with a key cylinder.

See “Doors” (P.3-4) and “Trunk lid” (P.3-18),
“Storage” (P.2-47) and “Seats” (P.1-2).

CAUTION

Always carry the mechanical key in-
stalled in the key.

VALET HAND-OFF

When you have to leave a key with a valet,
give them the Intelligent Key itself and keep
the mechanical key with you to protect your
belongings.

To prevent the glove box and the trunk from
being opened during valet hand-off, follow
the procedures below.

1. Push the trunk release power cancel

switch to the CANCEL side.

2. Remove the mechanical key from the

Intelligent Key.

3. Lock the glove box and the trunk pass-

through with the mechanical key.

4. Hand the Intelligent Key to the valet,

keeping the mechanical key in your
pocket or bag for insertion into the
Intelligent Key when you retrieve your
vehicle.

See “Trunk lid” (P.3-18), “Storage” (P.2-47)
and “Seats” (P.1-2).

Pre-driving checks and adjustments

3-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-4

Pre-driving checks and adjustments

WARNING

. Always have the doors locked while

driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from unintention-
ally opening the doors, and will help
keep out intruders.

. Before opening any door, always look

for and avoid oncoming traffic.

. To help avoid risk of injury or death

through unintended operation of the
vehicle and or its systems, including
entrapment in windows or inadver-
tent door lock activation, do not
leave children, people who require
the assistance of others or pets
unattended in your vehicle. Addition-
ally, the temperature inside a closed
vehicle on a warm day can quickly
become high enough to cause a sig-
nificant risk of injury or death to
people and pets.

JVP0231X

LOCKING WITH MECHANICAL
KEY

The power door lock system allows you to
lock or unlock all doors simultaneously using
the mechanical key.
. Turning the driver’s door key cylinder to

the front of the vehicle

will lock all

doors.

. Turning the driver’s door key cylinder

once to the rear of the vehicle

will

unlock the driver’s door. After returning
the key to the neutral position

, turning

it to the rear again within 60 seconds will
unlock all doors.

. You can switch the lock system to the

mode that allows you to open all the
doors when the key is turned once. (See
the INFINITI InTouch

Owner’s Man-

ual.)

OPENING AND CLOSING WIN-
DOWS WITH THE MECHANICAL
KEY

The driver’s door key operation also allows
you to open and close the window that is
equipped with the automatic open/close
function. (See “Power windows” (P.2-51).)

To open the window, turn the driver’s door
key cylinder to the rear of the vehicle for
longer than 1 second. The door is unlocked
and the window keeps opening while turning
the key.

This function can also be performed by
pushing and holding the door UNLOCK
button of the Intelligent Key. (See “Remote
keyless entry system” (P.3-14).)

To close the window, turn the driver’s door
key cylinder to the front of the vehicle for
longer than 1 second. The door is locked and
the window keeps closing while turning the
key.

DOORS

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SPA2726

LOCKING WITH INSIDE LOCK
KNOB

To lock the door individually, move the inside
lock knob to the lock position

then close

the door.

To unlock, move the inside lock knob to the
unlock position

When locking the door without an Intelli-
gent Key, be sure not to leave the Intelligent
Key inside the vehicle.

REAR DOOR AUTO CLOSURE (if
so equipped)

The rear door auto closure will actuate when
the rear door is not completely closed.

CAUTION

. The rear door will automatically close

from a partly open position. To avoid
pinching, keep hands and fingers
away from rear door opening.

. Do not let children operate the rear

door.

NOTE:

. The rear doors can be opened instructionly

by pulling the outside door handle or
inside door handle, even while the auto
closure is operating.

. The rear doors can be closed instructionly.

. The auto closure will not operate if the

rear door is closed while the outside
door handle or inside door handle pulled.

JVP0319X

LOCKING WITH POWER DOOR
LOCK SWITCH

Operating the power door lock switch will
lock or unlock all the doors. The switches are
located on the driver’s and front passenger’s
door armrests.

To lock the doors, push the power door lock
switch to the lock position

with the

driver’s or front passenger’s door open, then
close the door.

When locking the door this way, be certain
not to leave the Intelligent Key inside the
vehicle.

To unlock the doors including the fuel-filler
door, push the power door lock switch to the

Pre-driving checks and adjustments

3-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-6

Pre-driving checks and adjustments

unlock position

Lockout protection

When the power door lock switch is moved
to the lock position and any door open, all
doors will lock and unlock automatically.
With the Intelligent Key left in the vehicle
and any door open, all doors will unlock
automatically and a chime will sound after
the door is closed.

These functions help to prevent the Intelli-
gent Key from being accidentally locked
inside the vehicle.

AUTOMATIC DOOR LOCKS

. All doors lock automatically when the

vehicle speed reaches 15 MPH (24
km/h).

. All doors unlock automatically when the

ignition switch is placed in the OFF
position.

The automatic unlock function can be
deactivated or activated. To deactivate or
activate the automatic door unlock system,
perform the following procedure:

1. Close all doors.

2. Place the ignition switch in the ON

position.

3. Within 20 seconds of performing Step 2,

push and hold the power door lock
switch to the

position (UNLOCK)

for more than 5 seconds.

4. When activated, the hazard indicator will

flash twice. When deactivated, the ha-
zard indicator will flash once.

5. The ignition switch must be placed in the

OFF and ON position again between
each setting change.

When the automatic door unlock system is
deactivated, the doors do not unlock when
the ignition switch is placed in the OFF
position. To unlock the door instructionly, use
the inside lock knob or the power door lock
switch (driver’s or front passenger’s side).

SPA2745

CHILD SAFETY REAR DOOR
LOCK

The child safety rear door lock helps prevent
doors from being opened accidentally, espe-
cially when small children are in the vehicle.

When the levers are in the lock position

the rear doors can be opened only from the
outside.

To disengage, move the levers to the unlock
position

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

. Radio waves could adversely affect

electric medical equipment. Those
who use a pacemaker should contact
the electric medical equipment man-
ufacturer for the possible influences
before use.

. The Intelligent Key transmits radio

waves when the buttons are pushed.
The FAA advises that the radio
waves may affect aircraft navigation
and communication systems. Do not
operate the Intelligent Key while on
an airplane. Make sure the buttons
are not operated unintentionally
when the unit is stored during a
flight.

The Intelligent Key system can operate all
the doors and the trunk lid using the remote
controller function or pushing the request
switch on the vehicle without taking the key
out from a pocket or purse. The operating
environment and/or conditions may affect
the Intelligent Key system operation.

Be sure to read the following before using
the Intelligent Key system.

CAUTION

. Be sure to carry the Intelligent Key

with you when operating the vehicle.

. Never leave the Intelligent Key in the

vehicle when you leave the vehicle.

The Intelligent Key is always communicating
with the vehicle as it receives radio waves.
The Intelligent Key system transmits weak
radio waves. Environmental conditions may
interfere with the operation of the Intelligent
Key system under the following operating
conditions.
. When operating near a location where

strong radio waves are transmitted, such
as a TV tower, power station and broad-
casting station.

. When in possession of wireless equip-

ment, such as a cellular telephone,
transceiver, and CB radio.

. When the Intelligent Key is in contact

with or covered by metallic materials.

. When any type of radio wave remote

control is used nearby.

. When the Intelligent Key is placed near

an electric appliance such as a personal
computer.

. When the vehicle is parked near a parking

meter.

In such cases, correct the operating condi-
tions before using the Intelligent Key func-
tion or use the mechanical key.

Although the life of the battery varies
depending on the operating conditions, the
battery’s life is approximately 2 years. If the
battery is discharged, replace it with a new
one.

When the Intelligent Key battery is almost
discharged, see “Intelligent Key battery dis-
charge” (P.5-13) to start the engine.

Since the Intelligent Key is continuously
receiving radio waves, if the key is left near
equipment which transmits strong radio
waves, such as signals from a TV and
personal computer, the battery life may
become shorter.

For information regarding replacement of a
battery, see “Intelligent Key battery replace-
ment” (P.8-25).

For models with a steering wheel lock
mechanism: Because the steering wheel is
locked electrically, unlocking the steering
wheel with the ignition switch in the LOCK
position is impossible when the vehicle
battery is completely discharged. Pay special
attention that the vehicle battery is not
completely discharged.

Pre-driving checks and adjustments

3-7

INTELLIGENT KEY SYSTEM

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-8

Pre-driving checks and adjustments

As many as 4 Intelligent Keys can be
registered and used with one vehicle. For
information about the purchase and use of
additional Intelligent Keys, contact an
INFINITI retailer.

CAUTION

. Do not allow the Intelligent Key,

which contains electrical compo-
nents, to come into contact with
water or salt water. This could affect
the system function.

. Do not drop the Intelligent Key.
. Do not strike the Intelligent Key

sharply against another object.

. Do not change or modify the Intelli-

gent Key.

. Wetting may damage the Intelligent

Key. If the Intelligent Key gets wet,
immediately wipe until it is comple-
tely dry.

. Do not place the Intelligent Key for

an extended period in an area where
temperatures exceed 140°F (60°C).

. If the outside temperature is below

14°F (−10°C), the battery of the
Intelligent Key may not function
properly.

. Do not attach the Intelligent Key

with a key holder that contains a
magnet.

. Do not place the Intelligent Key near

equipment that produces a magnetic
field, such as a TV, audio equipment
and personal computers.

If an Intelligent Key is lost or stolen, INFINITI
recommends erasing the ID code of that
Intelligent Key from the vehicle. This may
prevent the unauthorized use of the Intelli-
gent Key to operate the vehicle. For infor-
mation regarding the erasing procedure, it is
recommended that you contact an INFINITI
retailer.

SPA2538

INTELLIGENT KEY OPERATING
RANGE

The Intelligent Key functions can only be
used when the Intelligent Key is within the
specified operating range from the request
switch

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When the Intelligent Key battery is dis-
charged or strong radio waves are present
near the operating location, the Intelligent
Key system’s operating range becomes nar-
rower, and the Intelligent Key may not
function properly.

The operating range is within 31.50 in (80
cm) from each request switch

If the Intelligent Key is too close to the door
glass, handle or rear bumper the request
switches may not function.

When the Intelligent Key is within the
operating range, it is possible for anyone
who does not carry the Intelligent Key to
push the request switch to lock/unlock the
doors and open the trunk lid.

SPA2407

DOOR LOCKS/UNLOCKS PRE-
CAUTION

. Do not push the door handle request

switch with the Intelligent Key held in
your hand as illustrated. The close dis-
tance to the door handle will cause the
Intelligent Key system to have difficulty
recognizing that the Intelligent Key is
outside the vehicle.

. After locking with the door handle re-

quest switch, verify the doors are se-
curely locked by testing them.

. To prevent the Intelligent Key from being

left inside the vehicle or the trunk, make
sure you carry the key with you and then

lock the doors or the trunk.

. Do not pull the door handle before

pushing the door handle request switch.
The door will be unlocked but will not
open. Release the door handle once and
pull it again to open the door.

. The Intelligent Key system (opening/

closing doors with the door handle
request switch) can be set to remain
inactive. (See the INFINITI InTouch

Owner’s Instruction.)

Pre-driving checks and adjustments

3-9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-10

Pre-driving checks and adjustments

JVP0330X

INTELLIGENT KEY OPERATION

You can lock or unlock the doors without
taking the key out from your pocket or bag.

JVP0331X

When you carry the Intelligent Key with you,
you can lock or unlock all doors by pushing
the door handle request switch (driver’s or
front passenger’s)

within the range of

operation.

When you lock or unlock the doors or the
trunk lid, the hazard indicator will flash and
the horn (if so equipped) (or the outside
chime) will sound as a confirmation. For
details, see “Setting hazard indicator and
horn mode” (P.3-16).

Welcome light and farewell light
function

When you lock or unlock the doors and fuel-
filler door, front and rear side marker lights,

parking lights, tail lights and the license plate
light will illuminate for a period of time. The
welcome light and farewell light function can
be disabled. For information about disabling
the welcome light and farewell light func-
tion, it is recommended you see an INFINITI
retailer.

Locking doors and fuel-filler door

1. Push the ignition switch to the OFF

position and make sure you carry the
Intelligent Key with you.*1

2. Close all the doors.*2

3. Push the door handle request switch

(driver’s or front passenger’s)

while

carrying the Intelligent Key with you.*3

4. All the doors and fuel-filler door will lock.

5. The hazard indicator flashes twice and

the outside chime sounds twice.

*1: Doors will lock with the Intelligent Key

while the ignition switch is in the ACC
or ON position.

*2: Doors will not lock with the Intelligent

Key while any door is open.

*3: Doors will not lock by pushing the door

handle request switch with the Intelli-
gent Key inside the vehicle. However,
when an Intelligent Key is inside the
vehicle, doors can be locked with
another registered Intelligent Key.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking doors and fuel-filler door

1. Push the door handle request switch

(driver’s or front passenger’s)

once

while carrying the Intelligent Key with
you.

2. The hazard indicator flashes once and

outside chime sounds once. The corre-
sponding door will unlock.

The fuel-filler door will also unlock when
the driver’s door handle request switch is
pushed.

3. Push the door handle request switch

again within 1 minute.

4. The hazard indicator flashes once and

outside chime sounds once again. All the
doors will unlock.

All doors and the fuel-filler door will be
locked automatically unless one of the
following operations is performed within 1
minute after pushing the request switch
while the doors are locked.
. Opening any door

. Pushing the ignition switch
During this 1-minute time period, if the
UNLOCK

button on the Intelligent Key

is pushed, all doors will be locked automa-
tically after another 1 minute.

JVP0332X

JVP0333X

Opening trunk lid

1. Push the trunk open request switch

for

more than 1 second.

2. The trunk will unlatch. An outside chime

will sound four times.

3. Raise the trunk lid to open the trunk.

Lockout protection:
To prevent the Intelligent Key from being
accidentally locked in the trunk, lockout
protection is equipped with the Intelligent
Key system.

When the trunk lid is closed with the
Intelligent Key inside the trunk, the outside
chime will sound and the trunk will open.

BATTERY SAVER SYSTEM

When all the following conditions are met
for a period of time, the battery saver
system will cut off the power supply to
prevent battery discharge.
. The ignition switch is in the ACC position,

and

. All doors are closed, and

. The shift lever is in the P (Park) position.

Pre-driving checks and adjustments

3-11

-------------------------------------------------------------------------------------------------------------------------------------------------------------

TROUBLESHOOTING GUIDE

Symptom

Possible cause

Action to take

When pushing the ignition
switch to stop the engine

The SHIFT P warning appears on the
display and the inside warning chime
sounds continuously.

The shift lever is not in the P (Park)
position.

Shift the shift lever to the P (Park)
position.

When opening the driver’s door
to get out of the vehicle

The inside warning chime sounds continu-
ously.

The ignition switch is in the ACC
position.

Push the ignition switch to the OFF
position.

When closing the door after
getting out of the vehicle

The NO KEY warning appears on the
display, the outside chime sounds 3 times
and the inside warning chime sounds for a
few seconds.

The ignition switch is in the ACC or
ON position.

Push the ignition switch to the OFF
position.

The SHIFT P warning appears on the
display and the outside chime sounds
continuously.

The ignition switch is in the ACC or
OFF position and the shift lever is not
in the P (Park) position.

Move the shift lever to the P (Park)
position and push the ignition switch to
the OFF position.

When closing the door with the
inside lock knob turned to
LOCK

The outside chime sounds for a few
seconds and all the doors unlock.

The Intelligent Key is inside the
vehicle or trunk.

Carry the Intelligent Key with you.

When pushing the request
switch or LOCK button on the
Intelligent Key to lock the door

The outside chime sounds for a few
seconds.

The Intelligent Key is inside the
vehicle or trunk.

Carry the Intelligent Key with you.

A door is not closed securely.

Close the door securely.

When closing the trunk lid

The outside chime sounds for approxi-
mately 10 seconds and the trunk lid opens.

The Intelligent Key is inside the trunk. Carry the Intelligent Key with you.

Pre-driving checks and adjustments

3-13

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infiniti Q70 (2019 year). Instruction - part 9
