SDI1949
Checking the tire pressure
1. Remove the valve stem cap from
the tire.
2. Press the pressure gauge squarely
onto the valve stem. Do not press
too hard or force the valve stem
sideways, or air will escape. If the
hissing sound of air escaping from
the tire is heard while checking the
pressure, reposition the gauge to
eliminate this leakage.
3. Remove the gauge.
4. Read the tire pressure on the
gauge stem and compare it to the
specification shown on the Tire
and Loading Information label.
5. Add air to the tire as needed. If too
much air is added, press the core of
the valve stem briefly with the tip
of the gauge stem to release
pressure. Recheck the pressure
and add or release air as needed.
6. Install the valve stem cap.
7. Check the pressure of all other
tires, including the spare.
SIZE
COLD
TIRE IN-
FLATION
PRES-
SURE
FRONT
ORIGINAL
TIRE
P245/
40RF19
94V
240 kPa,
35 PSI
245/
40RF19
94W
240 kPa,
35 PSI
REAR
ORIGINAL
TIRE
P245/
40RF19
94V
240 kPa,
35 PSI
245/
40RF19
94W
240 kPa,
35 PSI
Do-it-yourself
8-31
