Infiniti Jx35 (2013 year). Instruction - part 34





Trailer brakes

When towing a trailer load of 3,500 lbs.
(1,587 kg) or more, trailers with a brake
system MUST be used.
However, most states
require a separate braking system on trailers with
a loaded weight above a specific amount. Make
sure the trailer meets the local regulations and
the regulations where you plan to tow.

Several types of braking systems are available.

Surge Brakes -The surge brake actuator is
mounted on the trailer tongue with a hydraulic line
running to each trailer wheel. Surge brakes are
activated by the trailer pushing against the hitch
ball when the tow vehicle is braking. Hydraulic
surge brakes are common on rental trailers and
some boat trailers. In this type of system, there is
no hydraulic or electric connection for brake op-
eration between the tow vehicle and the trailer.

Electric Trailer Brakes -Electric braking sys-
tems are activated by an electronic signal sent
from a trailer brake controller (special brake-
sensing module). If electric trailer brakes are
used, see “Electric trailer brake controller” in this
section.

Have a professional supplier of towing equip-
ment make sure the trailer brakes are properly
installed and demonstrate proper brake function
testing.

WARNING

Never connect a trailer brake system di-
rectly to the vehicle brake system.

Electric trailer brake controller

Trailers equipped with electric brakes may re-
quire the installation of an aftermarket trailer
brake controller.

Your vehicle is equipped with a connector and
jumper harness that is specifically designed to be
used when installing an aftermarket brake con-
troller.

To install the electric trailer brake controller jumper
harness, perform the following procedure:

1. Open the driver door. Move the seat to the

rearmost position.

example

LTI0117

9-24

Technical and consumer information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Locate the jumper harness connector under

the lower portion of the instrument panel.
The connector is taped to the wiring harness

1

as indicated.

● The connector is marked with a white tag

with “elec brake conn”.

Wire color designation for electric trailer brake
controller jumper harness.

WIRE COLOR

NOTE

WHITE

Vehicle stop lamp switch
to trailer brake controller.

BLACK

Brake controller ground
(-).

WHITE

Trailer brake controller
switched output.

GREEN

Fused trailer brake con-
troller battery feed (B+).

3. Peel off the tape and connect the jumper

harness to the connector .

4. Release the parking brake.

5. Install the aftermarket electric trailer brake

controller according to the manufacturer’s
instructions.

Pre-towing tips

● Be certain your vehicle maintains a level

position when a loaded and/or unloaded
trailer is hitched. Do not drive the vehicle if it
has an abnormal nose-up or nose-down
condition; check for improper tongue load,
overload, worn suspension or other possible
causes of either condition.

● Always secure items in the trailer to prevent

load shift while driving.

LTI2045

LTI2046

Technical and consumer information

9-25

-------------------------------------------------------------------------------------------------------------------------------------------------------------

● Keep the cargo load as low as possible in

the trailer to keep the trailer center of gravity
low.

● Load the trailer so approximately 60% of the

trailer load is in the front half and 40% is in
the back half. Also make sure the load is
balanced side to side.

● Check your hitch, trailer tire pressure, ve-

hicle tire pressure, trailer light operation, and
trailer wheel lug nuts every time you attach a
trailer to the vehicle.

● Be certain your rearview mirrors conform to

all federal, state or local regulations. If not,
install any mirrors required for towing before
driving the vehicle.

● Determine the overall height of the vehicle

and trailer so the required clearance is
known.

Trailer towing tips

In order to gain skill and an understanding of the
vehicle’s behavior, you should practice turning,
stopping and backing up in an area which is free
from traffic. Steering stability and braking perfor-
mance will be somewhat different than under
normal driving conditions.

● Always secure items in the trailer to prevent

load shift while driving.

● Lock the trailer hitch coupler with a pin or

lock to prevent the coupler from inadver-
tently becoming unlatched.

● Avoid abrupt starts, acceleration or stops.
● Avoid sharp turns or lane changes.
● Always drive your vehicle at a moderate

speed.

● When backing up, hold the bottom of the

steering wheel with one hand. Move your
hand in the direction in which you want the
trailer to go. Make small corrections and
back up slowly. If possible, have someone
guide you when you are backing up.

Always block the wheels on both vehicle and
trailer when parking. Parking on a slope is not
recommended; however, if you must do so:

CAUTION

If you move the shift selector to the P
(Park)

position

before

blocking

the

wheels and applying the parking brake,
transmission damage could occur.

1. Apply and hold the brake pedal.

2. Have someone place blocks on the downhill

side of the vehicle and trailer wheels.

3. After the wheel blocks are in place, slowly

release the brake pedal until the blocks ab-
sorb the vehicle load.

4. Apply the parking brake.

5. Shift the transmission into P (Park).

6. Turn off the engine.

To drive away:

1. Start the vehicle.

2. Apply and hold the brake pedal.

3. Shift the transmission into gear.

4. Release the parking brake.

5. Drive slowly until the vehicle and trailer are

clear from the blocks.

6. Apply and hold the brake pedal.

7. Have someone retrieve and store the blocks.

9-26

Technical and consumer information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

● While going downhill, the weight of the

trailer pushing on the tow vehicle may de-
crease overall stability. Therefore, to main-
tain adequate control, reduce your speed
and shift to a lower gear. Avoid long or
repeated use of the brakes when descend-
ing a hill, as this reduces their effectiveness
and could cause overheating. Shifting to a
lower gear instead provides “engine brak-
ing” and reduces the need to brake as fre-
quently.

● If the engine coolant temperature rises to a

high temperature, refer to “If your vehicle
overheats” in the “In case of emergency”
section of this owner’s instruction.

● Trailer towing requires more fuel than normal

circumstances.

● Avoid towing a trailer for your vehicle’s first

500 miles (805 km).

● For the first 500 miles (805 km) that you do

tow, do not drive over 50 MPH (80 km/h).

● Have your vehicle serviced more often than

at intervals specified in the recommended
Maintenance Schedule in the “INFINITI Ser-
vice and Maintenance Guide”.

● When making a turn, your trailer wheels will

be closer to the inside of the turn than your
vehicle wheels. To compensate for this,
make a larger than normal turning radius
during the turn.

● Crosswinds and rough roads will adversely

affect vehicle/trailer handling, possibly caus-
ing vehicle sway. When being passed by
larger vehicles, be prepared for possible
changes in crosswinds that could affect ve-
hicle handling.

Do the following if the trailer begins to sway:

1. Take your foot off the accelerator pedal to

allow the vehicle to coast and steer as
straight ahead as the road conditions allow.
This combination will help stabilize the ve-
hicle

– Do not correct trailer sway by steering or

applying the brakes.

2. When the trailer sway stops, gently apply the

brakes and pull to the side of the road in a
safe area.

3. Try to rearrange the trailer load so it is bal-

anced as described earlier in this section.

● Be careful when passing other vehicles.

Passing while towing a trailer requires con-
siderably more distance than normal pass-
ing. Remember, the length of the trailer must
also pass the other vehicle before you can
safely change lanes.

● Downshift the transmission to a lower gear

for engine braking when driving down steep
or long hills. This will help slow the vehicle
without applying the brakes.

● Avoid holding the brake pedal down too long

or too frequently. This could cause the
brakes to overheat, resulting in reduced
braking efficiency.

● Increase your following distance to allow for

greater stopping distances while towing a
trailer. Anticipate stops and brake gradually.

● INFINITI recommends that the cruise control

not be used while towing a trailer.

● Some states or provinces have specific

regulations and speed limits for vehicles that
are towing trailers. Obey the local speed
limits.

● Check your hitch, trailer wiring harness con-

nections, and trailer wheel lug nuts after
50 miles (80 km) of travel and at every break.

Technical and consumer information

9-27

-------------------------------------------------------------------------------------------------------------------------------------------------------------

● When launching a boat, don’t allow the wa-

ter level to go over the exhaust tail pipe or
rear bumper.

● Make sure you disconnect the trailer lights

before backing the trailer into the water or
the trailer lights may burn out.

When towing a trailer, final drive gear oil
should

be

replaced

and

transmission

oil/fluid should be changed more fre-
quently. For additional information, see the
“Maintenance and do-it-yourself” section
earlier in this instruction.

FLAT TOWING

Towing your vehicle with all four wheels on the
ground is sometimes called flat towing. This
method is sometimes used when towing a vehicle
behind a recreational vehicle, such as a motor
home.

CAUTION

● Failure to follow these guidelines can

result in severe transmission damage.

● Whenever flat towing your vehicle, al-

ways tow forward, never backward.

● DO NOT tow any automatic transmis-

sion vehicle with all four wheels on the
ground (flat towing). Doing so WILL
DAMAGE internal transmission parts
due to lack of transmission lubrication.

● For emergency towing procedures refer

to “Towing recommended by INFINITI”
in the “In case of emergency” section of
this instruction.

Continuously Variable Transmission

To tow a vehicle equipped with a continuously
variable transmission, an appropriate vehicle
dolly MUST be placed under the towed vehicle’s
drive wheels. Always follow the dolly manufac-
turer’s recommendations when using their prod-
uct.

DOT (Department of Transportation) Quality
Grades: All passenger car tires must conform to
federal safety requirements in addition to these
grades.

Quality grades can be found where applicable on
the tire sidewall between tread shoulder and
maximum section width. For example:

Treadwear 200 Traction AA Temperature A

Treadwear

The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified gov-
ernment test course. For example, a tire graded
150 would wear one and one-half (1 1/2) times
as well on the government course as a tire graded
100. The relative performance of tires depends
upon the actual conditions of their use, however,
and may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.

Traction AA, A, B and C

The traction grades, from highest to lowest, are
AA, A, B, and C. Those grades represent the
tire’s ability to stop on wet pavement as mea-
sured under controlled conditions on specified
government test surfaces of asphalt and con-
crete. A tire marked C may have poor traction
performance.

UNIFORM TIRE QUALITY GRADING

9-28

Technical and consumer information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

The traction grade assigned to this tire is
based on straight-ahead braking traction
tests, and does not include acceleration,
cornering, hydroplaning, or peak traction
characteristics.

Temperature A, B and C

The temperature grades are A (the highest), B,
and C, representing the tire’s resistance to the
generation of heat, and its ability to dissipate heat
when tested under controlled conditions on a
specified indoor laboratory test wheel. Sustained
high temperature can cause the material of the
tire to degenerate and reduce tire life, and exces-
sive temperature can lead to sudden tire failure.
The grade C corresponds to a level of perfor-
mance which all passenger car tires must meet
under the Federal Motor Safety Standard No.
109. Grades B and A represent higher levels of
performance on the laboratory test wheel than
the minimum required by law.

WARNING

The temperature grade for this tire is es-
tablished for a tire that is properly inflated
and not overloaded. Excessive speed,
under-inflation, or excessive loading, ei-
ther separately or in combination, can
cause heat build-up and possible tire
failure.

Your INFINITI is covered by the following emis-
sion warranties:

For USA

1. Emission Defects Warranty

2. Emissions Performance Warranty

Details of these warranties may be found with other
vehicle warranties in your Warranty Information
Booklet which comes with your INFINITI. If you did
not receive a Warranty Information Booklet, or it is
lost, you may obtain a replacement by writing to:

● INFINITI Division

Nissan North America, Inc.
Consumer Affairs Department
P.O. Box 685003
Franklin, TN 37068-5003

For Canada

Emission Control System Warranty

Details of these warranties may be found with other
vehicle warranties in your Warranty Information
Booklet which comes with your INFINITI. If you did
not receive a Warranty Information Booklet, or it is
lost, you may obtain a replacement by writing to:

● Nissan Canada Inc.

5290 Orbitor Drive
Mississauga, Ontario, L4W 4Z5

EMISSION CONTROL SYSTEM
WARRANTY

Technical and consumer information

9-29

-------------------------------------------------------------------------------------------------------------------------------------------------------------

For USA

If you believe that your vehicle has a de-
fect which could cause a crash or could
cause injury or death, you should immedi-
ately inform the National Highway Traffic
Safety Administration (NHTSA) in addi-
tion to notifying INFINITI.

If NHTSA receives similar complaints, it
may open an investigation, and if it finds
that a safety defect exists in a group of
vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot be-
come involved in individual problems be-
tween you, your retailer, or INFINITI.

To contact NHTSA, you may call the Ve-
hicle Safety Hotline toll-free at 1-888-
327-4236 (TTY: 1-800-424-9153); go
to http://www.safercar.gov; or write to:
Administrator, NHTSA, 400 Seventh
Street, SW., Washington, D.C. 20590.
You can also obtain other information
about

motor

vehicle

safety

from

http://www.safercar.gov.

You may notify INFINITI by contacting our
Consumer Affairs Department, toll-free, at
1-800-662-6200.

For Canada

If you believe that your vehicle has a de-
fect which could cause a crash or could
cause injury or death, you should immedi-
ately inform Transport Canada in addition
to notifying INFINITI.

If Transport Canada receives complaints,
it may open an investigation, and if it finds
that a safety defect exists in a group of
vehicles, it may request that INFINITI con-
duct a recall campaign. However, Trans-
port Canada cannot become involved in
individual problems between you, your re-
tailer, or INFINITI.

You may contact Transport Canada’s De-
fect Investigations and Recalls Division
toll free at 1-800-333-0510. You may
also report safety defects online at:
https://wwwapps.tc.gc.ca/Saf-Sec-
Sur/7/PCDB-BDPP/Index.aspx.

Additional information concerning motor
vehicle safety may be obtained from Trans-
port Canada’s Road Safety Information
Centre at 1-800-333-0371 or online at
www.tc.gc.ca/roadsafety (English speak-
ers)

or

www.tc.gc.ca/securiteroutiere

(French speakers).

To notify INFINITI of any safety concerns
please contact our Consumer Information
Centre toll free at 1-800-361-4792.

REPORTING SAFETY DEFECTS

9-30

Technical and consumer information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

A vehicle equipped with All -Wheel Drive
(AWD) should never be tested using a two
wheel dynamometer (such as the dyna-
mometers used by some states for emis-
sions testing), or similar equipment. Make
sure you inform the test facility personnel
that your vehicle is equipped with AWD
before it is placed on a dynamometer.
Using the wrong test equipment may re-
sult in transmission damage or unex-
pected vehicle movement which could re-
sult in serious vehicle damage or personal
injury.

Due to legal requirements in some states and
Canadian Provinces, your vehicle may be re-
quired to be in what is called the “ready condi-
tion” for an Inspection/Maintenance (I/M) test of
the emission control system.

The vehicle is set to the “ready condition” when it
is driven through certain driving patterns. Usually,
the ready condition can be obtained by ordinary
usage of the vehicle.

If a powertrain system component is repaired or
the battery is disconnected, the vehicle may be
reset to a “not ready” condition. Before taking the
I/M

test,

check

the

vehicle’s

inspection/maintenance test readiness condi-
tion. Place the ignition switch in the ON position
without starting the engine. If the Malfunction
Indicator Light (MIL) comes on steady for 20 sec-
onds and then blinks for 10 seconds , the I/M test
condition is “not ready”. If the MIL does not blink
after 20 seconds, the I/M test condition is
“ready”. Contact a INFINITI retailer to set the
“ready condition” or to prepare the vehicle for
testing.

This vehicle is equipped with an Event Data Re-
corder (EDR). The main purpose of an EDR is to
record, in certain crash or near crash-like situa-
tions, such as an air bag deployment or hitting a
road obstacle, data that will assist in understand-
ing how a vehicle’s systems performed. The EDR
is designed to record data related to vehicle
dynamics and safety systems for a short period of
time, typically 30 seconds or less. The EDR in this
vehicle is designed to record such data as:

● How various systems in your vehicle were

operating;

● Whether or not the driver and passenger

safety belts were buckled/fastened;

● How far (if at all) the driver was depressing

the accelerator and/or brake pedal; and,

● How fast the vehicle was traveling.
● Sounds are not recorded.

These data can help provide a better understand-
ing of the circumstances in which crashes and
injuries occur. NOTE: EDR data are recorded by
your vehicle only if a nontrivial crash situation
occurs; no data are recorded by the EDR under
normal driving conditions and no personal data
(e.g. name, gender, age and crash location) are
recorded. However, other parties, such as law
enforcement, could combine the EDR data with
the type of personally identifying data routinely
acquired during a crash investigation.

READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST

EVENT DATA RECORDERS (EDR)

Technical and consumer information

9-31

-------------------------------------------------------------------------------------------------------------------------------------------------------------

To read data recorded by an EDR, special equip-
ment is required and access to the vehicle or the
EDR is needed. In addition to the vehicle manu-
facturer and INFINITI retailer, other parties, such
as law enforcement, that have the special equip-
ment, can read the information if they have ac-
cess to the vehicle or the EDR. EDR data will only
be accessed with the consent of the vehicle
owner or lessee or as otherwise required or per-
mitted by law.

Genuine INFINITI Service Instructions for this model
year and prior can be purchased. A genuine
INFINITI Service Instruction is the best source of
service and repair information for your vehicle.
This instruction is the same one used by the factory-
trained technicians working at INFINITI retailer-
ships. Genuine INFINITI Owner’s Manuals can
also be purchased.

For USA

For current pricing and availability of genuine
INFINITI Service Instructions, contact:

1-800-450-9491
www.infiniti-techinfo.com

For current pricing and availability of genuine
INFINITI Owner’s Instructions, contact:

1-800-247-5321

For Canada

To purchase a copy of a genuine INFINITI Service
Instruction or Owner’s Instruction, for this model year
and prior, please contact your nearest INFINITI
retailer. For the phone number and location of an
INFINITI retailer in your area call the INFINITI
Satisfaction Center at 1-800-361-4792 and a
bilingual INFINITI representative will assist you.

OWNER’S MANUAL/SERVICE
MANUAL ORDER INFORMATION

9-32

Technical and consumer information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

10 Index

A

Aiming control, headlights . . . . . . . . . . .2-33
Air bag (See supplemental restraint
system) . . . . . . . . . . . . . . . . . . . . .1-49
Air bag system

Front (See supplemental front impact
air bag system) . . . . . . . . . . . . . . .1-57

Air bag warning labels . . . . . . . . . . . . .1-64
Air bag warning light. . . . . . . . . . .1-64, 2-11
Air cleaner housing filter . . . . . . . . . . . .8-18
Air conditioner

Air conditioner service . . . . . . . . . . .4-60
Air conditioner specification label . . . . .9-11
Air conditioner system refrigerant and
oil recommendations . . . . . . . . . . . . .9-6
Heater and air conditioner controls . . . .4-55
Servicing air conditioner . . . . . . . . . .4-60

Alarm system
(See vehicle security system) . . . . . . . . .2-24
Anchor point locations . . . . . . . . . . . . .1-34
Antenna . . . . . . . . . . . . . . . . . . . .4-102
Anti-lock brake warning light . . . . . . . . . .2-7
Anti-lock Braking System (ABS). . . . . . . .5-91
Audible reminders . . . . . . . . . . . . . . .2-13
Audio system . . . . . . . . . . . . . . . . . .4-61

Bluetooth® audio. . . . . . . . . . . . . .4-97
Compact disc (CD) player . . . . . . . . .4-82
FM/AM/SAT radio with compact disc
(CD) player . . . . . . . . . . . . . . . . .4-78

Audio System

iPod® Player . . . . . . . . . . . . . . . .4-93

Audio system

Radio . . . . . . . . . . . . . . . . . . . .4-61
Steering wheel audio control switch . . .4-101
USB interface . . . . . . . . . . . . . . . .4-89

Autolight switch. . . . . . . . . . . . . . . . .2-31
Automatic

Automatic drive positioner . . . . . . . . .3-31
Automatic power window switch . . . . .2-51

Automatic anti-glare inside mirror . . . . . . .3-29
Automatic door locks . . . . . . . . . . . . . .3-6

B

Battery . . . . . . . . . . . . . . . . . . . . . .8-14

Charge warning light . . . . . . . . . . . . .2-8

Before starting the engine . . . . . . . . . . .5-14
Belt (See drive belt) . . . . . . . . . . . . . .8-16
Block heater

Engine . . . . . . . . . . . . . . . . . . . .5-97

Bluetooth® audio. . . . . . . . . . . . . . . .4-97
Bluetooth® hands-free phone
system . . . . . . . . . . . . . . . . .4-115, 4-129
Booster seats . . . . . . . . . . . . . . . . . .1-45
Brake

Anti-lock Braking System (ABS). . . . . .5-91
Brake fluid . . . . . . . . . . . . . . . . . .8-12
Brake light (See stop light). . . . . . . . .8-27
Brake system . . . . . . . . . . . . . . . .5-90
Brake warning light. . . . . . . . . . . . . .2-8
Brake wear indicators . . . . . . . .2-13, 8-20
Parking brake operation . . . . . . . . . .5-19
Self-adjusting brakes . . . . . . . . . . . .8-20

Brakes . . . . . . . . . . . . . . . . . . . . . .8-20
Break-in schedule . . . . . . . . . . . . . . .5-84
Brightness/contrast button . . . . . . .4-13, 4-28
Brightness control

Instrument panel . . . . . . . . . . . . . .2-34

Bulb check/instrument panel . . . . . . . . . .2-7
Bulb replacement . . . . . . . . . . . . . . . .8-27

C

Capacities and recommended
fuel/lubricants. . . . . . . . . . . . . . . . . . .9-2
Cargo light . . . . . . . . . . . . . . . . . . .2-56
Cargo (See vehicle loading information) . . .9-13
Car phone or CB radio . . . . . . . . . . . .4-115
CD care and cleaning. . . . . . . . . . . . .4-100
CD player (See audio system) . . . . . . . . .4-82
Check tire pressure. . . . . . . . . . . . . . .2-23
Child restraints . . . . . . .1-28, 1-28, 1-29, 1-31

Precautions on child
restraints . . . . . . . .1-29, 1-36, 1-41, 1-45
Top tether strap anchor point locations . .1-34

Child restraint with top tether strap . . . . . .1-33
Child safety rear door lock. . . . . . . . . . . .3-7
Chimes, audible reminders. . . . . . . . . . .2-13
Cleaning exterior and interior . . . . . . . . . .7-2
Clock

(models with navigation system) . . . . . .4-25

Clock set . . . . . . . . . . . . . . . . . . . .4-25
C.M.V.S.S. certification label. . . . . . . . . .9-10
Cold weather driving . . . . . . . . . . . . . .5-96
Compact disc (CD) player . . . . . . . . . . .4-82

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Console box . . . . . . . . . . . . . . . . . . .2-47
Continuously Variable Transmission (CVT). . .5-15

Continuously Variable Transmission
(CVT) fluid . . . . . . . . . . . . . . . . . .8-11
Driving with Continuously Variable
Transmission (CVT) . . . . . . . . . . . . .5-15

Control panel buttons . . . . . . . . . . . . . .4-14

Brightness/contrast button. . . . . .4-13, 4-28
Enter button. . . . . . . . . . . . . . .4-4, 4-14
Setting button . . . . . . . . . . . . .4-9, 4-22
Without navigation system . . . . . . . . . .4-4

Controls

Audio controls (steering wheel) . . . . . .4-101
Heater and air conditioner controls. . . . .4-55

Coolant

Capacities and recommended
fuel/lubricants . . . . . . . . . . . . . . . . .9-2
Changing engine coolant . . . . . . . . . . .8-8
Checking engine coolant level . . . . . . . .8-8
Engine coolant temperature gauge . . . . .2-5

Corrosion protection . . . . . . . . . . . . . . .7-6
Cruise control . . . . . . . . . . . . . . . . . .5-47
Cup holders . . . . . . . . . . . . . . . . . . .2-45

D

Daytime running light system (Canada only) . .2-33
Defroster switch

Rear window and outside mirror defroster
switch. . . . . . . . . . . . . . . . . . . . .2-30

Digital Versatile Disc (DVD) player . . . . . . .4-86
Dimensions and weights . . . . . . . . . . . . .9-8
Dimmer switch for instrument panel . . . . . .2-34
Display controls
(see control panel buttons) . . . . . . . .4-4, 4-14

Distance to empty . . . . . . . . . . . . .4-7, 4-19
Door locks . . . . . . . . . . . . . . . . . . . . .3-4
Drive belt . . . . . . . . . . . . . . . . . . . . .8-16
Drive positioner, Automatic . . . . . . . . . . .3-31
Driving

Cold weather driving . . . . . . . . . . . .5-96
Driving with Continuously Variable
Transmission (CVT) . . . . . . . . . . . . .5-15
Precautions when starting and driving . . . .5-2

E

Economy - fuel . . . . . . . . . . . . . . . . . .5-86
Emission control information label . . . . . . .9-10
Emission control system warranty . . . . . . .9-29
Engine

Before starting the engine. . . . . . . . . .5-14
Block heater . . . . . . . . . . . . . . . . .5-97
Capacities and recommended
fuel/lubricants . . . . . . . . . . . . . . . . .9-2
Changing engine coolant . . . . . . . . . . .8-8
Changing engine oil . . . . . . . . . . . . .8-10
Changing engine oil filter . . . . . . . . . .8-11
Checking engine coolant level . . . . . . . .8-8
Checking engine oil level . . . . . . . . . . .8-9
Engine compartment check locations . . . .8-6
Engine coolant temperature gauge . . . . .2-5
Engine cooling system . . . . . . . . . . . .8-7
Engine oil . . . . . . . . . . . . . . . . . . .8-9
Engine oil and oil filter recommendation . . .9-5
Engine oil viscosity . . . . . . . . . . . . . .9-5
Engine serial number . . . . . . . . . . . .9-10
Engine specifications . . . . . . . . . . . . .9-7
Starting the engine . . . . . . . . . . . . .5-14

Enter button. . . . . . . . . . . . . . . . .4-4, 4-14

Event data recorders . . . . . . . . . . . . . .9-31
Exhaust gas (Carbon monoxide) . . . . . . . . .5-2
Extended storage switch . . . . . . . . . . . .8-24
Eyeglass case . . . . . . . . . . . . . . . . . .2-44

F

Flashers (See hazard warning flasher switch) . .6-2
Flat tire . . . . . . . . . . . . . . . . . . . . . . .6-3
Floor mat positioning aid . . . . . . . . . . . . .7-5
Fluid

Brake fluid . . . . . . . . . . . . . . . . . .8-12
Capacities and recommended
fuel/lubricants . . . . . . . . . . . . . . . . .9-2
Continuously Variable Transmission
(CVT) fluid . . . . . . . . . . . . . . . . . .8-11
Engine coolant. . . . . . . . . . . . . . . . .8-7
Engine oil . . . . . . . . . . . . . . . . . . .8-9
Power steering fluid . . . . . . . . . . . . .8-12
Windshield-washer fluid. . . . . . . . . . .8-13

F.M.V.S.S. certification label. . . . . . . . . . .9-10
Fog light switch . . . . . . . . . . . . . . . . .2-35
Front air bag system
(See supplemental restraint system) . . . . . .1-57
Front seats . . . . . . . . . . . . . . . . . . . . .1-2
Fuel

Capacities and recommended
fuel/lubricants . . . . . . . . . . . . . . . . .9-2
Fuel economy . . . . . . . . . . . . . . . .5-86
Fuel-filler door and cap . . . . . . . . . . .3-24
Fuel gauge . . . . . . . . . . . . . . . . . . .2-6
Fuel octane rating . . . . . . . . . . . . . . .9-4
Fuel recommendation . . . . . . . . . . . . .9-3
Loose fuel cap warning . . . . . . . . . . .2-24

Fuses . . . . . . . . . . . . . . . . . . . . . . .8-21

10-2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fusible links . . . . . . . . . . . . . . . . . . .8-22

G

Garage door opener, HomeLink® Universal
Transceiver . . . . . . . . . . . . . . . .2-57, 2-61
Gas cap . . . . . . . . . . . . . . . . . . . . .3-24
Gauge

Engine coolant temperature gauge . . . . .2-5
Fuel gauge . . . . . . . . . . . . . . . . . . .2-6
Odometer . . . . . . . . . . . . . . . . . . .2-4
Speedometer . . . . . . . . . . . . . . . . .2-4
Tachometer . . . . . . . . . . . . . . . . . .2-5
Trip odometer . . . . . . . . . . . . . . . . .2-4

General maintenance . . . . . . . . . . . . . . .8-2
Glove box. . . . . . . . . . . . . . . . . . . . .2-46
Glove box lock . . . . . . . . . . . . . . . . . .2-46

H

Hands-free phone system,
Bluetooth®. . . . . . . . . . . . . . .4-115, 4-129
Hazard warning flasher switch . . . . . . . . . .6-2
Headlight and turn signal switch . . . . . . . .2-30
Headlight control switch . . . . . . . . . . . .2-31
Headlights . . . . . . . . . . . . . . . . . . . .8-26
Headlights, aiming control. . . . . . . . . . . .2-33
Heated seats . . . . . . . . . . . .2-35, 2-37, 2-38
Heated steering wheel . . . . . . . . . . . . .2-39
Heater

Heater and air conditioner controls. . . . .4-55
Heater operation . . . . . . . . . . . . . . .4-55

HomeLink® Universal Transceiver . . . .2-57, 2-61
Hood release . . . . . . . . . . . . . . . . . . .3-20

Hook

Luggage hook . . . . . . . . . . . . . . . .2-48

Horn . . . . . . . . . . . . . . . . . . . . . . .2-35

I

Ignition Switch

Push-Button Ignition Switch . . . . . . . .5-10

Image viewer . . . . . . . . . . . . . . . . . . .4-28
Immobilizer system . . . . . . . . . . . . .3-4, 5-13
Important vehicle information label . . . . . . .9-10
In-cabin microfilter . . . . . . . . . . . . . . . .8-18
Increasing fuel economy. . . . . . . . . . . . .5-86
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders) . . . . . . . . . . . . . . . . . . . . .2-7
INFINITI vehicle immobilizer
system . . . . . . . . . . . . . . . .2-25, 3-4, 5-13
Inside automatic anti-glare mirror . . . . . . . .3-29
Inside mirror . . . . . . . . . . . . . . . . . . .3-29
Instrument brightness control . . . . . . . . . .2-34
Instrument panel . . . . . . . . . . . . . . .0-6, 2-2
Instrument panel dimmer switch . . . . . . . .2-34
Intelligent cruise control (ICC) system

Brake assist . . . . . . . . . . . . . . . . .5-49

Intelligent Key system

Key operating range . . . . . . . . . . . . . .3-9
Key operation . . . . . . . . . . . . . . . .3-10
Mechanical key . . . . . . . . . . . . . . . .3-3
Remote keyless entry operation. . . . . . .3-13
Troubleshooting guide . . . . . . . . . . . .3-17
Warning signals . . . . . . . . . . . . . . .3-17

Interior light. . . . . . . . . . . . . . . . . . . .2-55
iPod® Player . . . . . . . . . . . . . . . . . . .4-93
ISOFIX child restraints . . . . . . . . . . . . .1-31

J

Jump starting . . . . . . . . . . . . . . . . . . .6-10

K

Keyfob battery replacement . . . . . . . . . . .8-25
Keyless entry

With Intelligent Key system
(See Intelligent Key system). . . . . . . . .3-13

Keys, For Intelligent Key system. . . . . . .3-2, 3-7

L

Labels

Air conditioner specification label . . . . .9-11
C.M.V.S.S. certification label . . . . . . . .9-10
Emission control information label . . . . .9-10
Engine serial number . . . . . . . . . . . .9-10
F.M.V.S.S. certification label. . . . . . . . .9-10
Tire and Loading Information label . . . . .9-11
Vehicle identification number (VIN) plate . .9-9
Warning labels (for SRS) . . . . . . . . . .1-64

LATCH (Lower Anchors and Tethers for CHildren)
System . . . . . . . . . . . . . . . . . . . . . .1-31
License plate

Installing the license plate . . . . . . . . . .9-12

Lift gate . . . . . . . . . . . . . . . . . . . . . .3-20
Lift gate release . . . . . . . . . . . . . . . . .3-23
Light

Air bag warning light . . . . . . . . .1-64, 2-11
Brake light (See stop light) . . . . . . . . .8-27
Bulb check/instrument panel . . . . . . . . .2-7
Bulb replacement . . . . . . . . . . . . . .8-27

10-3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Charge warning light . . . . . . . . . . . . .2-8
Fog light switch . . . . . . . . . . . . . . .2-35
Headlight and turn signal switch . . . . . .2-30
Headlight control switch . . . . . . . . . .2-31
Headlights . . . . . . . . . . . . . . . . . .8-26
Interior light. . . . . . . . . . . . . . . . . .2-55
Light bulbs . . . . . . . . . . . . . . . . . .8-26
Low tire pressure warning light. . . . . . . .2-8
Low windshield-washer fluid warning
light . . . . . . . . . . . . . . . . . . . . . .2-23
Passenger air bag and status light . . . . .1-58
Security indicator light. . . . . . . . . . . .2-13
Warning/indicator lights and audible
reminders . . . . . . . . . . . . . . . . . . .2-7

Lights

Map lights . . . . . . . . . . . . . . . . . .2-56

Lock

Child safety rear door lock . . . . . . . . . .3-7
Door locks . . . . . . . . . . . . . . . . . . .3-4
Glove box lock . . . . . . . . . . . . . . . .2-46
Lift gate release . . . . . . . . . . . . . . .3-23
Power door locks . . . . . . . . . . . . . . .3-6

Loose fuel cap warning . . . . . . . . . . . . .2-24
Low fuel warning light . . . . . . . . . .2-10, 2-22
Low tire pressure warning light. . . . . . . . . .2-8
Low windshield-washer fluid warning light. . .2-23
Luggage hook . . . . . . . . . . . . . . . . . .2-48
Luggage rack (see roof rack) . . . . . . . . . .2-49
Luggage (See vehicle loading information) . .9-13
Luggage storage
(see vehicle loading information) . . . . . . . .2-48

M

Maintenance

Changing the maintenance interval . .4-8, 4-20
Displaying the maintenance notice
reminder. . . . . . . . . . . . . . . . .4-8, 4-21
General maintenance . . . . . . . . . . . . .8-2
Inside the vehicle . . . . . . . . . . . . . . .8-3
Maintenance precautions . . . . . . . . . . .8-5
Outside the vehicle . . . . . . . . . . . . . .8-2
Resetting the maintenance interval . .4-8, 4-20
Seat belt maintenance. . . . . . . . . . . .1-27
Setting . . . . . . . . . . . . . . . . .4-8, 4-20
Under the hood and vehicle . . . . . . . . .8-4

Malfunction indicator light . . . . . . . . . . . .2-12
Map lights . . . . . . . . . . . . . . . . . . . .2-56
Map pocket. . . . . . . . . . . . . . . . . . . .2-43
Meters and gauges . . . . . . . . . . . . . . . .2-4

Instrument brightness control . . . . . . . .2-34

Mirror

Automatic anti-glare inside mirror. . . . . .3-29
Inside mirror . . . . . . . . . . . . . . . . .3-29
Outside mirror control . . . . . . . . . . . .3-30
Outside mirrors . . . . . . . . . . . . . . .3-30
Vanity mirror . . . . . . . . . . . . . . . . .3-28

Moonroof . . . . . . . . . . . . . . . . . . . . .2-52

N

NISSAN voice recognition system . . . . . .4-140

O

Octane rating (See fuel octane rating). . . . . .9-4

Odometer . . . . . . . . . . . . . . . . . . . . .2-4
Oil

Capacities and recommended
fuel/lubricants . . . . . . . . . . . . . . . . .9-2
Changing engine oil . . . . . . . . . . . . .8-10
Changing engine oil filter . . . . . . . . . .8-11
Checking engine oil level . . . . . . . . . . .8-9
Engine oil . . . . . . . . . . . . . . . . . . .8-9
Engine oil and oil filter recommendation . . .9-5
Engine oil viscosity . . . . . . . . . . . . . .9-5

Outside mirror control . . . . . . . . . . . . . .3-30
Outside mirrors . . . . . . . . . . . . . . . . .3-30
Overheat

If your vehicle overheats . . . . . . . . . . .6-12

Owner’s instruction order form . . . . . . . . . . .9-32
Owner’s instruction/service manual order
information . . . . . . . . . . . . . . . . . . . .9-32

P

Parking

Parking brake operation . . . . . . . . . . .5-19
Parking/parking on hills . . . . . . . . . . .5-89

Phone, Bluetooth® hands-free
system . . . . . . . . . . . . . . . . .4-115, 4-129
Power

Power door locks . . . . . . . . . . . . . . .3-6
Power outlet . . . . . . . . . . . . . .2-41, 2-43
Power rear windows . . . . . . . . . . . . .2-51
Power steering fluid . . . . . . . . . . . . .8-12
Power steering system . . . . . . . . . . .5-90
Power windows . . . . . . . . . . . . . . .2-50
Rear power windows . . . . . . . . . . . .2-51

Power inverter switch . . . . . . . . . . . . . .2-41

10-4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Precautions

Maintenance precautions . . . . . . . . . . .8-5
On-pavement and off-road driving
precautions . . . . . . . . . . . . . . . . . .5-6
Precautions on child
restraints. . . . . . . . .1-29, 1-36, 1-41, 1-45
Precautions on seat belt usage . . . . . . .1-20
Precautions on supplemental restraint
system . . . . . . . . . . . . . . . . . . . .1-49
Precautions when starting and driving . . . .5-2

Pre-tensioner seat belt system . . . . . . . . .1-63
Programmable features . . . . . . . . . .4-9, 4-22
Push starting . . . . . . . . . . . . . . . . . . .6-12

R

Radio

Car phone or CB radio . . . . . . . . . .4-115
FM/AM/SAT radio with compact disc
(CD) player . . . . . . . . . . . . . . . . . .4-78
Steering wheel audio control switch . . .4-101

Rain sensor. . . . . . . . . . . . . . . . . . . .2-28
Readiness for inspection maintenance
(I/M) test . . . . . . . . . . . . . . . . . . . . .9-31
Rear power windows . . . . . . . . . . . . . .2-51
RearView Monitor . . . . . . . . . . . . . . . .4-30
Rear window and outside mirror defroster
switch. . . . . . . . . . . . . . . . . . . . . . .2-30
Rear window wiper and washer switches . . .2-29
Recorders

Event data . . . . . . . . . . . . . . . . . .9-31

Refrigerant recommendation . . . . . . . . . . .9-6
Registering your vehicle in another country . . .9-9
Reporting safety defects (US only) . . . . . . .9-30
Resetting the fuel economy . . . . . . . .4-7, 4-19

Roof rack . . . . . . . . . . . . . . . . . . . . .2-49

S

Safety

Child safety rear door lock . . . . . . . . . .3-7
Child seat belts . . . . .1-29, 1-36, 1-41, 1-45
Reporting safety defects (US only) . . . . .9-30

Seat adjustment

Front power seat adjustment . . . . . . . . .1-3
Second row bench seats . . . . . . . .1-5, 1-7

Seatback pockets . . . . . . . . . . . . . . . .2-44
Seat belt

Child safety. . . . . . . . . . . . . . . . . .1-28
Infants and small children . . . . . . . . . .1-28
Injured Person . . . . . . . . . . . . . . . .1-23
Larger children . . . . . . . . . . . . . . . .1-29
Precautions on seat belt usage . . . . . . .1-20
Pregnant women . . . . . . . . . . . . . . .1-23
Pre-tensioner seat belt system . . . . . . .1-63
Seat belt extenders . . . . . . . . . . . . .1-27
Seat belt maintenance. . . . . . . . . . . .1-27
Seat belts. . . . . . . . . . . . . . . . . . .1-20
Three-point type with retractor . . . . . . .1-23

Seat belt warning light. . . . . . . . . . . . . .2-11
Seats

Adjustment. . . . . . . . . . . . . . . . . . .1-2
Automatic drive positioner. . . . . . . . . .3-31
Front seats . . . . . . . . . . . . . . . . . . .1-2
Heated seats . . . . . . . . . .2-35, 2-37, 2-38

Security indicator light. . . . . . . . . . . . . .2-13
Security system

(INFINITI vehicle immobilizer system),
engine start . . . . . . . . . . .2-25, 3-4, 5-13

Self-adjusting brakes . . . . . . . . . . . . . .8-20

Service instruction order form . . . . . . . . . . .9-32
Servicing air conditioner. . . . . . . . . . . . .4-60
Setting button . . . . . . . . . . . . . . .4-9, 4-22
Spark plug replacement . . . . . . . . . . . . .8-17
Speedometer . . . . . . . . . . . . . . . . . . .2-4
SRS warning label . . . . . . . . . . . . . . . .1-64
Starting

Before starting the engine. . . . . . . . . .5-14
Jump starting . . . . . . . . . . . . . . . . .6-10
Precautions when starting and driving . . . .5-2
Push starting . . . . . . . . . . . . . . . . .6-12
Starting the engine . . . . . . . . . . . . .5-14

Steering

Heated steering wheel . . . . . . . . . . .2-39
Power steering fluid . . . . . . . . . . . . .8-12
Power steering system . . . . . . . . . . .5-90

Steering wheel audio control switch . . . . .4-101
Stop light . . . . . . . . . . . . . . . . . . . . .8-27
Storage . . . . . . . . . . . . . . . . . . . . . .2-43
Storage bin . . . . . . . . . . . . . . . . . . . .2-48
Sunglasses case. . . . . . . . . . . . . . . . .2-44
Sunglasses holder . . . . . . . . . . . . . . . .2-44
Sunroof (see Moonroof) . . . . . . . . . . . . .2-52
Sun visors . . . . . . . . . . . . . . . . . . . .3-28
Supplemental air bag warning labels . . . . . .1-64
Supplemental air bag warning light . . .1-64, 2-11
Supplemental front impact air bag system . . .1-57
Supplemental restraint system

Information and warning labels . . . . . . .1-64
Precautions on supplemental restraint
system . . . . . . . . . . . . . . . . . . . .1-49

Supplemental restraint system
(Supplemental air bag system) . . . . . . . . .1-49
Switch

Autolight switch . . . . . . . . . . . . . . .2-31
Automatic power window switch . . . . . .2-51

10-5

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fog light switch . . . . . . . . . . . . . . .2-35
Hazard warning flasher switch . . . . . . . .6-2
Headlight aiming control . . . . . . . . . .2-33
Headlight and turn signal switch . . . . . .2-30
Headlight control switch . . . . . . . . . .2-31
Power door lock switch . . . . . . . . . . . .3-6
Power inverter switch . . . . . . . . . . . .2-41
Rear window and outside mirror defroster
switch. . . . . . . . . . . . . . . . . . . . .2-30
Rear window wiper and washer
switches . . . . . . . . . . . . . . . . . . .2-29
Turn signal switch . . . . . . . . . . . . . .2-34
Vehicle dynamic control (VDC) off
switch. . . . . . . . . . . . . . . . . . . . .2-41
Windshield wiper and washer switch . . .2-26

T

Tachometer . . . . . . . . . . . . . . . . . . . .2-5
Temperature gauge

Engine coolant temperature gauge . . . . .2-5

Theft

(INFINITI vehicle immobilizer system),
engine start . . . . . . . . . . .2-25, 3-4, 5-13

Three-way catalyst . . . . . . . . . . . . . . . .5-2
Tire

Flat tire . . . . . . . . . . . . . . . . . . . . .6-3
Spare tire . . . . . . . . . . . . . . . . . . .6-5
Tire and Loading Information label . . . . .9-11
Tire chains . . . . . . . . . . . . . . . . . .8-38
Tire placard. . . . . . . . . . . . . . . . . .9-11
Tire pressure . . . . . . . . . . . . . . . . .8-31
Tire rotation. . . . . . . . . . . . . . . . . .8-38
Types of tires . . . . . . . . . . . . . . . . .8-37
Uniform tire quality grading . . . . . . . . .9-28

Wheels and tires . . . . . . . . . . . . . . .8-31
Wheel/tire size. . . . . . . . . . . . . . . . .9-8

Tire pressure

Low tire pressure warning light. . . . . . . .2-8

Tire Pressure Monitoring System (TPMS) . . . .5-3
Top tether strap child restraint . . . . . . . . .1-33
Towing

Flat towing . . . . . . . . . . . . . . . . . .9-28
Towing load/specification . . . . . . . . . .9-21
Tow truck towing. . . . . . . . . . . . . . .6-13
Trailer towing . . . . . . . . . . . . . . . . .9-17

Transceiver

HomeLink® Universal Transceiver . .2-57, 2-61

Transmission

Continuously Variable Transmission
(CVT) fluid . . . . . . . . . . . . . . . . . .8-11
Driving with Continuously Variable
Transmission (CVT) . . . . . . . . . . . . .5-15

Travel (See registering your vehicle in another
country) . . . . . . . . . . . . . . . . . . . . . .9-9
Trip odometer . . . . . . . . . . . . . . . . . . .2-4
Turn signal switch . . . . . . . . . . . . . . . .2-34

U

Uniform tire quality grading . . . . . . . . . . .9-28
USB interface

Audio file operation . . . . . . . . . . . . .4-90
Video file operation . . . . . . . . . . . . .4-91

V

Vanity mirror . . . . . . . . . . . . . . . . . . .3-28
Variable voltage control system . . . . . . . . .8-16

Vehicle dimensions and weights . . . . . . . . .9-8
Vehicle dynamic control (VDC) off switch . . .2-41
Vehicle dynamic control (VDC) system. . . . .5-92
Vehicle identification . . . . . . . . . . . . . . .9-9
Vehicle identification number (VIN)
(Chassis number) . . . . . . . . . . . . . . . . .9-9
Vehicle identification number (VIN) plate . . . .9-9
Vehicle loading information . . . . . . . . . . .9-13
Vehicle recovery. . . . . . . . . . . . . .6-15, 6-16
Vehicle security system . . . . . . . . . . . . .2-24

(INFINITI vehicle immobilizer system),
engine start . . . . . . . . . . .2-25, 3-4, 5-13

Ventilators . . . . . . . . . . . . . . . . . . . .4-53
Visors . . . . . . . . . . . . . . . . . . . . . . .3-28
Voice recognition system . . . . . . . . . . .4-140

W

Warning

Air bag warning light . . . . . . . . .1-64, 2-11
Anti-lock brake warning light . . . . . . . . .2-7
Battery charge warning light . . . . . . . . .2-8
Brake warning light . . . . . . . . . . . . . .2-8
Hazard warning flasher switch . . . . . . . .6-2
Low fuel warning light . . . . . . . .2-10, 2-22
Low tire pressure warning light. . . . . . . .2-8
Low windshield-washer fluid warning
light . . . . . . . . . . . . . . . . . . . . . .2-23
Passenger air bag and status light . . . . .1-58
Seat belt warning light. . . . . . . . . . . .2-11
Vehicle security system . . . . . . . . . . .2-24
Warning/indicator lights and audible
reminders . . . . . . . . . . . . . . . . . . .2-7
Warning labels (for SRS) . . . . . . . . . .1-64

Warning lights . . . . . . . . . . . . . . . . . . .2-7

10-6

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Washer switch

Rear window wiper and washer
switches . . . . . . . . . . . . . . . . . . .2-29
Windshield wiper and washer switch . . .2-26

Weights (See dimensions and weights) . . . . .9-8
Wheels and tires . . . . . . . . . . . . . . . . .8-31
Wheel/tire size. . . . . . . . . . . . . . . . . . .9-8
When traveling or registering your vehicle in
another country . . . . . . . . . . . . . . . . . .9-9
Windows

Locking passengers’ windows . . . . . . .2-50
Power rear windows . . . . . . . . . . . . .2-51
Power windows . . . . . . . . . . . . . . .2-50
Rear power windows . . . . . . . . . . . .2-51

Windshield-washer fluid. . . . . . . . . . . . .8-13
Windshield wiper and washer switch . . . . .2-26
Wiper

Rear window wiper and washer
switches . . . . . . . . . . . . . . . . . . .2-29
Windshield wiper and washer switch . . .2-26
Wiper blades. . . . . . . . . . . . . . . . .8-18

10-7

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     32      33      34
