• The input clutch gets engaged and connects the mid internal gear with the rear carrier.
• The direct clutch gets engaged and connects the rear sun gear with the rear carrier.
• The high and low reverse clutch gets engaged and connects the rear sun gear with the mid sun gear.
• Each planetary gear enters the state described below.
