Hyundai Sonata Plug-in Hybrid (2017 year). Manual - part 21

Variable EQ

SDVC (Speed Dependent

Voice Recognition Volume

This is a premium sound system fea-

Volume Control)

Press the

SETUP

key Select [Sound]

ture in which the acoustical mode

Press the

SETUP

key Select [Sound]

Select [Voice Recognition Vol.]

can be selected according to musical

Select [Speed Dependent Vol.]

preferences.

Turn the TUNE knob to adjust the

Select [Variable EQ] Set menu

Voice Recognition volume.

through

TUNE knob

• Innocente(Normal)

Natural

sound, sound optimized for driver.

• Forza(Dynamic) : Powerful sound

emphasizing bass, stereo sound.

• Concerto(Concert) : Sound similar

to a concert or live hall

❈ May differ depending on the

The volume level is controlled auto-

selected audio.

matically according to the vehicle

speed. SDVC can be set by selecting

from On / Off.

4-103

Multimedia System

Touch Screen Beep

Blue Link Voice Volume

System Setting

Press the

SETUP

key Select [Sound]

Press the

SETUP

key Select [Sound]

Select [Touch Screen Beep]

Select [Blue Link Voice Vol.]

Memory Information

Press the

SETUP

key Select

Turn the TUNE knob to adjust the

[System] Select [Memory Information]

Blue Link Voice Volume.

❈ Blue Link® may differ depending

on the selected audio.

This feature is used to turn the touch

screen beep on/off.

This feature displays information

related to system memory.

1) Using : Displays capacity currently

in use

2) Capacity : Displays total capacity

4-104

Prompt Feedback

Language

Press the

SETUP

key Select

Press the

SETUP

key Select

[System] Select [Prompt Feedback]

[System] Select [Language]

❈This feature is used to change the

This feature is used to select the

system and voice recognition lan-

desired prompt feedback option from

guage.

ON and OFF.

❈if the language is changed, the

system will restart and apply the

1) ON : When using voice recogni-

selected language.

tion, provides detailed guidance

prompts

2) OFF : When using voice recogni-

tion, omits some guidance

prompts

4-105

Multimedia System

REAR VIEW CAMERA

BLUE LINK® (IF EQUIPPED)

(if equipped)

Hyundai aims to offer differentiated

customer values through a

‘Connected Car Life,’ which is to pro-

•

The system has been equipped

vide consumers with fast and reliable

Hyundai Motor plans to achieve this

with a rear view camera for user

IT technology. As consumers’ lifestyles

by realizing a terminal platform flexi-

safety by allowing a wider rear

become more and more mobile in

ble to changes in IT technology,

thanks to remarkable advances in

cooperating with global IT compa-

range of vision.

smart phones, tablet PCs and overall

nies, creating an eco-system and

•

The rear view camera will automat-

wireless telecommunication, new

providing the latest contents & servic-

ically operate when the ignition key

lifestyle patterns demand seamless

es based on an open environment.

is turned ON and the shift lever is

connection between one’s office,

set to R (Reverse).

home, outdoors and automobiles.

•

The rear view camera will automat-

Automobile companies are now faced

ically stop operating when shift

with the task of shifting their paradigm

lever is set to different position.

from vehicle-centered services to cus-

tomer value-centered services, with

the ultimate goal of securing global

CAUTION

leadership in the field of vehicle IT and

The rear view camera has been

telematics.

equipped with an optical lens to

provide a wider range of vision

and may appear different from

the actual distance. For safety,

directly check the rear and

left/right sides.

4-106

Using the Room Mirror Key

➁

(Blue Link® for POI)

Information

Selecting the room mirror key will

• Blue Link® for Voice command

The Turn by Turn (TBT) feature sup-

allow you to make service required

Starts Blue Link® voice command.

ports the store of ten (10) destinations

inquiries, POI info searches, and

in the TBT destinations directory.

Voice receiving voice guidance,

emergency rescues by connecting to

shortly press the button to convert to

the Blue Link® Center.

voice command mode. Press and

3. Route Preview

Such features can be used only after

hold the button to end voice com-

“Route Preview” VR command allows

subscribing to the Blue Link® service.

mand.

the user to preview the route instruc-

tions

(upcoming maneuver instruc-

• TBT VR Commands

tions) at any time during the route

1. Navigate to

guidance.

“Navigate to” voice command is used

to request the download of route

4. Destinations List

data for a new destination, saved

“Destinations List” VR command

destinations, daily routes and previ-

allows the user to preview and delete

ous destinations.

the stored destinations with their

associated voice tags in the Turn by

2. Save Destination

Turn destinations directory.

➀

(Blue Link® Center)

“Save Destination” VR command is

Makes requests for Blue Link® serv-

used to assign a voice tag to the last

5. Voice Guidance

ice related inquiries and consulta-

downloaded destination and store it

“Voice Guidance” VR command allows

tions.

in a destination directory.

the user to mute/unmute the Turn by

A call is connected to the Blue Link®

Turn(TBT) direction announcements.

service center employee.

Re-pressing the key will end the call.

This feature does not operate when

you are on a Bluetooth® phone call.

4-107

Multimedia System

6. Suspend Route

Information

“Suspend Route” VR command

•

You cannot talk simultaneously on

allows the user to suspend and

the Bluetooth® phone and Blue

pause Turn by Turn(TBT) route guid-

Link® phone.

ance while in the guidance mode.

•

While on a Bluetooth® call, pressing

the

key or

key will dis-

7. Resume Route

play a message indicating that you

“Resume Route” VR command

are currently on a call.

allows the user to resume Turn by

•

A message will be displayed if you

Turn(TBT) route guidance.

receive a Bluetooth® Bluetooth®

Wireless Technology call while already

on a Blue Link® call. At this time,

➂

(Blue Link® for SOS)

press the

key on the steering

In the case of an emergency,

wheel remote controller to accept the

requests for help to the Blue Link®

call. The phone bell will not ring.

center.

Call is connected to the Blue Link®

emergency rescue center. Re-press-

ing the key will end the call.

If already on a Bluetooth® phone call,

the call will end to connect you to the

Blue Link® Emergency Rescue

Center.

4-108

Turn by Turn

4.Next Street name

The Turn by Turn feature can be used

5.Distance to destination

through Blue Link®.

6.Expected Time Arrival

7. Current Street name

❈ For information on specific

Blue Link® operations, please refer

to a separate manual.

1.Direction Indicator Image

2.Remaining distance until next point

3.The Count bar is divided into a

total of 9 levels.

9 Level

0.5mi

8 Level

0.4mi

7 Level

0.3mi

6 Level

0.2mi

5 Level

0.1mi

4 Level

400ft

3 Level

300ft

2 Level

200ft

1 Level

100ft

4-109

Multimedia System

(Continued)

i Information

Sirius, XM and all related marks and

iPod® is a registered trademark of

logos are trademarks of Sirius XM

Apple Inc. iPod® mobile digital device

Radio Inc. Android™ is a trademark

sold separately. The Bluetooth® word

of Google, Inc. BlackBerry is a regis-

mark and logos are registered trade-

tered trademark of Research In

marks owned by Bluetooth® SIG, Inc.

Motion Limited

(RIM). All other

and any use of such marks by

marks, channel names and logos are

Hyundai is under license. SiriusXM

the property of their respective own-

services require a subscription sold

separately, or as a package, by Sirius

XM Radio Inc. If you decide to con-

tinue service after your trial, the sub-

scription plan you choose will auto-

matically renew thereafter and you

will be charged according to your cho-

sen payment method at thencurrent

rates. Fees and taxes apply. To cancel

you must call SiriusXM at 1-866-635-

2349. See SiriusXM Customer

Agreement for complete terms at

www.siriusxm.com. SiriusXM U.S.

satellite and data services are avail-

able only in the 48 contiguous USA,

DC and PR (with coverage limita-

tions). SiriusXM satellite service is

also available in Canada; see www.sir-

iusxm.ca. All fees and programming

subject to change.

(Continued)

4-110

SYSTEM CONTROLLERS AND FUNCTIONS

Audio Head Unit

Name

Description

MEDIA

• Each time the key is pressed, the mode is

changed in order of CD, USB, iPod, AUX, My

Music, BT Audio modes.

❈ In Setup>Display, the media pop up screen

will be displayed when [Mode Pop up] is

turned

When the pop up screen is displayed, use the

TUNE knob or keys

select the desired mode.

PHONE

• Operates Phone Screen

SEEK

• Radio Mode : Automatically searches for

TRACK

broadcast frequencies.

• CD, USB, iPod, My Music modes :

- Shortly press the key : Moves to next or pre vious

song(file)

Name

Description

- Press and hold the key : Rewinds or fast-for

Ejects the disc.

wards the current song(file)

PWR/

•

Power Knob : Turns power On/Off by

RADIO

• Each time the key is pressed, the mode is

VOL knob

pressing the knob

changed in order of FM1 ➟ FM2 ➟ AM ➟

XM1 ➟ XM2 ➟ XM3

•

Volume Knob : Sets volume by turning

❈ In Setup>Display, the radio pop up screen will

the knob left/right

be displayed when [Mode Pop up] is turned

• Radio Mode : Saves frequencies (channels)

or receives saved frequencies (channels)

(Preset)

When the pop up screen is displayed, use the

• CD, USB, iPod, My Music mode

TUNE knob or keys

: Repeat

select the desired mode.

: Random

4-111

Multimedia System

Name

Description

SCAN

• Radio Mode

- Shortly press the key : Previews each broad

cast for 5 seconds each

- Press and hold the key : Previews the broadcasts

saved in Preset

for 5 seconds

each.

❈ Press the

SCAN

key again to continue

listening to the current frequency.

• XM™ Radio Mode

- Press and hold the key : Previews all

receivable broadcasts for 10 seconds each

• CD, USB, iPod mode

- Shortly press the key : Previews each song

(file) for 10 seconds each

❈ Press the

SCAN

key again to continue

listening to the current song (file).

SETUP

• Shortly press the key : Moves to the Display,

Sound, Phone, System setting modes

• Displays menus for the current mode.

CAT

• Radio Mode

FOLDER

Name

Description

- XM™ RADIO : Category Search

• MP3, CD, USB mode : Folder Search

DISP

• Each time the button is shortly pressed, it

❈ May differ depending on the selected audio

sets the screen Off ➟ Screen On ➟ Screen

TUNE

• Radio mode : Changes frequency by turning

Off

❈ Audio operation is maintained and only the

knob

the knob left/right

screen will be turned Off. In the screen Off

• XM™ Radio mode : Changes channel by

state, press any key to turn the screen On

turning the knob left/right

again.

• CD, USB, iPod mode: Searches songs (files)

by turning the knob left/right

❈ When the desired song is displayed, press

the knob to play the song.

4-112

SETUP

Mode Pop up

Media Display

[Mode Pop up] Changes

Off

When playing an MP3 file, select the

selection mode

desired display info from ‘Folder/File’

Display Settings

or ‘Album/Artist/Song’.

• During On state, press the

RADIO

MEDIA

key to display the mode

Press the

SETUP

key Select

change pop up screen.

[Display] through

TUNE knob or

key

4-113

Multimedia System

Sound Settings

Speed Dependent Volume Control

This menu allows you to set the

This feature is used to automatically

‘Bass, Middle, Treble’ and the Sound

control the volume level according to

Press the

SETUP

key Select

Fader and Balance.

the speed of the vehicle.

[Sound] through

TUNE knob or

Select

[Sound Settings] Select

Select

[SDVC] Turn SDVC On/Off

key

menu through TUNE knob Turn

by pressing the Tune knob.

TUNE knob left/right to set

• Bass, Middle, Treble : Selects the

Voice Recognition Volume

sound tone.

Adjusts voice recognition volume.

• Fader, Balance : Moves the sound

fader and balance.

Select [Voice Recognition Vol.] Set

volume of TUNE knob

• Default : Restores default settings.

❈ Return : While adjusting values,

pressing the

TUNE knob will

restore the parent menu.

4-114

System Settings

Memory Information

Language

Displays currently used memory and

This menu is used to set the display

total system memory.

and voice recognition language.

Press the

SETUP

key Select [System]

through tune knob or

key

Select [Memory Information] OK

Select [Language] Set through TUNE

The currently used memory is dis-

knob

played on the left side while the total

system memory is displayed on the

right side.

Prompt Feedback

This feature is used to change voice

command feedback between Normal

❈The system will reboot after the

and Expert modes.

language is changed.

Select

[Prompt Feedback] Set

❈Language support by region

through TUNE knob

• Normal(On)

: This mode is for

beginner users and provides

detailed instructions during voice

command operation.

• Expert(Off) : This mode is for expert

users and omits some information

during voice command operation.

(When using Expert mode, guid-

ance instructions can be heard

through the [Help] or [Menu] com-

mands.

4-115

Multimedia System

RADIO : FM, AM

Preset SEEK

Selecting through manual

Press the

key

Turn the

TUNE knob left/right to

• Shortly pressing the key : Plays the

adjust the frequency.

frequency saved in the correspon-

ding key.

• FM : Changes by 200KHz

• Pressing and holding the key

• AM : Changes by 9 (Only GUAM),

Pressing and holding the desired

10KHz

key from

will save the

currently playing broadcast to the

selected key and sound a BEEP.

SEEK

Press the

key Select

[

SEEK

Auto Store] through the TUNE knob

Press the

TRACK

key

SCAN

key

•

Shortly pressing the key : Changes

Press the

SCAN

key

the frequency.

• Shortly pressing the key

: The

•

Pressing and holding the key

broadcast frequency increases

Automatically searches for the next

and previews each broadcast for 5

frequency.

seconds each. After scanning all

frequencies, returns and plays the

current broadcast frequency.

A.Store

• Pressing and holding the key

Press the

key Set [A.Store]

Previews the broadcasts saved in

through TUNE knob or

key

Preset

for 5 seconds

each.

Saves broadcasts with superior

reception to

keys. If no

frequencies are received, then the

most recently received frequency will

be broadcast.

4-116

XMTM RADIO

SEEK
