Hyundai Sonata Plug-in Hybrid (2017 year). Manual - part 17

Making a call using the Steering wheel remote

controller

Name

Description

MODE

• Each time this key is pressed, the mode is changed in

order of FM1 ➟ FM2 ➟ AM ➟ XM1 ➟ XM2 ➟ XM3

➟ CD ➟ USB or iPod ➟ AUX ➟ My Music ➟ BT

Audio

• If the media is not connected or a disc is not insert-

ed, corresponding modes will be disabled.

VOL+

VOL-

Raises or lowers speaker volume.

4

key

Places and transfers calls.

key

Ends calls or cancels functions.

• Check call history and making call

- Shortly press (under 0.8 seconds) the

key on

the steering remote controller.

- The call history list will be displayed on the screen.

- Press the

key again to connect a call to the

selected number.

• Redialing the most recently called number

The actual feature in the vehicle may differ from the illus-

tration.

- Press and hold (over 0.8 seconds) the

key on

the steering remote controller.

- The most recently called number is redialed.

4-35

Pairing

PHONE

key /

key

1) Vehicle Name : Name of device as

During the pairing process, make sure

on the Steering Remote

shown when searching from your

that all connection requests on the

Bluetooth® Wireless Technology

phone are accepted for phonebook

Controller

device

download and to allow acceptance of

all future connection requests. Visit

2) Passkey : Passkey used to pair the

When No Devices have been

http://www.hyundaiusa.com/Bluetooth

device

for additional information on pairing

Paired

3. From your Bluetooth® Wireless

your Bluetooth-enabled mobile

1. Press the

PHONE

key or the

Technology device

(i.e. Mobile

phone, and to view a phone compat-

key on the steering remote con-

Phone), search and select your

ibility list.

troller. The following screen is dis-

car audio system.

played.

4

4. After a few moments, a screen is

NOTICE

displayed

6 digits passkey.

Hear, check the passkey on your

Bluetooth® Wireless Technology

device and confirm.

If Bluetooth® Wireless Technology

2. Select

[OK] button to enter the

devices are paired but none are

Pair Phone screen.

currently connected, pressing the

PHONE

key or the

key on the

steering wheel displays the fol-

5. Once pairing is complete, the fol-

lowing screen is displayed.

lowing screen. Select [Pair] button

to pair a new device or select

[Connect] to connect a previously

paired device.

4-37

Multimedia System

Pairing through [PHONE]

(Continued)

(Continued)

Setup

- Operations during a call (Switch to

•

If a connected Bluetooth® Wireless

Private, Switch to call waiting, MIC

Technology device becomes discon-

on/off)

nected due to being out of communi-

Press the

SETUP

key Select

cation range, turning the device

- Downloading Call History

[Phone] Select

[Pair Phone]

OFF, or a Bluetooth® Wireless

- Downloading Mobile Contacts

Select TUNE knob

Technology communication error,

- Bluetooth® Wireless Technology

corresponding Bluetooth® Wireless

device auto connection

Technology devices are automatical-

- Bluetooth Audio Streaming

ly searched and reconnected.

•

Up to five Bluetooth® Wireless

•

If the system becomes unstable due

Technology devices can be paired to

to communication errors between

the Car Handsfree system.

the car Handsfree and the

Bluetooth® Wireless Technology

•

Only one Bluetooth® Wireless

1. The following steps are the same

device, reset the device by turning

Technology device can be connected

as those described in the section

off and back on again. Upon reset-

at a time.

"When No Devices have been

ting Bluetooth® Wireless Technology

•

Other devices cannot be paired

Paired" on the previous page.

device, the system will be restored.

while a Bluetooth® Wireless

•

After pairing is complete, a contacts

Technology device is connected.

download request is sent once to the

i

Information

•

Only

Bluetooth®

Wireless

mobile phone. Some mobile phones

• Bluetooth® Wireless Technology fea-

Technology

Handsfree

and

may require confirmation upon

tures supported within the vehicle

Bluetooth audio related features are

receiving a download request,

are as follows. Some features may

supported.

ensure your mobile phone accepts

not be supported depending on your

•

Bluetooth related operations are

the connection. Refer to your

Bluetooth® Wireless Technology

possible only within devices that

phones user’s manual for additional

device.

support Handsfree or audio fea-

information regarding phone pair-

- Outgoing/Incoming Handsfree calls

tures, such as a Bluetooth® Wireless

ing and connections.

Technology mobile phone or a

(Continued)

Bluetooth audio device.

(Continued)

4-38

Connecting a Device

From the paired phone list, select the

Changing Priority

device you want to connect and

select [Connect].

Press the

SETUP

key Select

What is Priority?

[Phone] Select [Phone List]

It is possible to pair up to five

Bluetooth® Wireless Technology

devices with the car audio system.

The "Change Priority" feature is used

to set the connection priority of

paired phones.

4

Press the

SETUP

key Select

1) Connected Phone : Device that is

[Phone] Select [Phone List]

currently connected

2) Paired Phone

: Device that is

paired but not connected

4-39

Multimedia System

From the paired phone list, select

NOTICE

Disconnecting a Device

the phone you want to switch to the

highest priority, then select [Change

Priority icon will be displayed when

Priority] button from the Menu. The

the selected phone is set as a pri-

Press the

SETUP

key Select

selected device will be changed to

ority phone.

[Phone] Select [Phone List]

the highest priority.

From the paired phone list, select the

currently connected device and

select [Disconnect] button.

4-40

Deleting a Device

Pairing a New Device

i

Information

Press the

SETUP

key Select

•

When deleting the currently con-

[Phone] Select [Pair Phone]

Press the

SETUP

key Select

nected device, the device will auto-

matically be disconnected to pro-

[Phone] Select [Phone List]

ceed with the deleting process.

•

If a paired Bluetooth® Wireless

Technology device is deleted, the

device’s call history and contacts

data will also be deleted.

•

To re-use a deleted device, you must

pair the device again.

Bluetooth® Wireless Technology

4

devices can be paired with the audio

From the paired phone list, select the

system.

device you want to delete and select

For more information, refer to the

[Delete] button.

"Pairing through Phone Setup" sec-

tion within Bluetooth® Wireless

Technology.

4-41

Multimedia System

Viewing Paired Phone List

1) Connect/Disconnect Phone

:

i

Information - Before down

Press the

SETUP

key Select

Connect/disconnects currently

loading contacts

selected phone

[Phone] Select [Phone List]

• Only contacts within connected

2) Change Priority

: Sets currently

phones can be downloaded. Also

selected phone to highest connec-

check to see that your mobile phone

tion priority

supports the download feature.

3) Delete

: Deletes the currently

• To learn more about whether your

selected phone

mobile phone supports contacts

4) Return : Moves to the previous

downloads, refer to your mobile

screen

phone user's manual.

• The contacts for only the connected

phone can be downloaded.

This feature is used to view mobile

phones that have been paired with

the audio system. Upon selecting a

paired phone, the setup menu is dis-

played.

For more information, refer to the

"Setting

Bluetooth®

Wireless

Technology Connection" section with-

in Bluetooth® Wireless Technology.

4-42

Downloading Contacts

Outgoing Volume

Turning Bluetooth System Off

Press the

SETUP

key Select

Press the

SETUP

key Select

Press the

SETUP

key Select

[Phone] Select [Contacts Download]

[Phone] Select [Outgoing Volume]

[Phone] Select

[Bluetooth System

Off]

Use TUNE knob to adjust the out-

going volume level.

Once

Bluetooth®

Wireless

Technology is turned off, Bluetooth®

Wireless Technology related features

will not be supported within the audio

system.

4

As the contacts are downloaded

from the mobile phone, a download

progress bar is displayed.

i

Information

While on a call, the volume can be

changed by using the

SEEK

key.

i

Information

TRACK

• Upon downloading phone contacts,

the previous corresponding data is

deleted.

• This feature may not be supported

in some mobile phones.

• Voice Recognition may not operate

while contacts are being down-

i

Information

loaded.

To turn Bluetooth®

Wireless

Technology back on, go to

SETUP

[Phone] and select “Yes”.

4-43

Multimedia System

Phone Menu Screen

Answering Calls

i

Information

•

If you select the [Call History] but-

Phone Menus

ton but there is no call history data,

Answering a Call

a prompt is displayed which asks to

With a Bluetooth® Wireless

Answering a call with a Bluetooth®

download call history data.

Technology device connected, press

Wireless Technology device connect-

the

PHONE

key to display the Phone

•

If you select the [Contacts] button

ed will display the following screen.

menu screen.

but there is no contacts data stored,

To accept the call, press

key on

a prompt is displayed which asks to

the steering wheel while the call is

download contacts data.

incoming.

•

This feature may not be supported

in some mobile phones. For more

information on download support,

refer to your mobile phone user’s

manual.

1) Favorite : Up to 20 frequently used

contacts saved for easy access

2) Call History : Displays the call his-

1) Caller : Displays the other party’s

tory list screen

name when the incoming caller is

saved within your contacts

3) Contacts : Displays the Contacts

list screen

2) Incoming Number : Displays the

incoming number

4) Setup

: Displays Phone related

settings.

4-44

Favorites

Call History

i

Information

Press the

PHONE

key

Select

Press the

PHONE

key Select [Call

• When an incoming call pop-up is

[Favorites]

History]

displayed, most Audio and SETUP

mode features are disabled. Only

the call volume will operate.

• The telephone number may not be

properly displayed in some mobile

phones.

4

1) Saved favorite contact : Connects

A list of incoming, outgoing and

call upon selection

missed calls is displayed.

•

Call history may not be saved in the

2) To add favorite : Downloaded con-

call history list in some mobile

tacts be saved as favorite.

phones.

•

Calls received with hidden caller ID

i

Information

will not be saved in the call history

• To save Favorite, contacts should be

list.

downloaded.

•

Calling through the call history is not

• Contact saved in Favorites will not

possible when there is no call histo-

be automatically updated if the con-

ry stored or a Bluetooth® Wireless

tact has been updated in the phone.

Technology phone is not connected.

To update Favorites, delete the

Favorite and create a new Favorite.

•

Up to

50 received, dialed and

missed calls are stored in Call

History.

•

Time of received/dialed calls and

call time information are not saved.

4-45

Multimedia System

Contacts

(Continued)

i

Information

Press the

PHONE

key Select

•

It is not possible to begin download-

•

Up to 1,000 contacts saved in your

[Contacts]

ing a contact list when the contact

Bluetooth® Wireless Technology

download feature has been turned off

phone can be downloaded into the

within the Bluetooth® Wireless

car contacts. Contacts that have been

Technology device. In addition, some

downloaded to the car cannot be edit-

devices may require device authori-

ed or deleted on the phone.

zation upon attempting to download

•

Mobile phone contacts are managed

contacts. If downloading does not

separately for each paired Bluetooth®

normally occur, check the Bluetooth®

Wireless Technology device (max 5

Wireless Technology device settings

The list of saved phone book entries

devices x

1,000 contacts each).

or the screen state.

is displayed.

Previously downloaded data is main-

•

The contacts download feature may

tained even if the Bluetooth® Wireless

not be supported in some mobile

Technology device has been discon-

NOTE:

phones. For more information of sup-

nected.

ported Bluetooth® devices and func-

Find a contact in an alphabetical

(However, the contacts and call histo-

tion support, refer to your phone’s

order, press the

MENU

key.

ry saved to the phone will be deleted

user manual.

if a paired phone is deleted.)

•

It is possible to download contacts

during Bluetooth streaming audio.

•

When downloading contacts, the icon

will be displayed within the status

bar.

(Continued)

4-46

Skipping Prompt Messages

VOICE RECOGNITION

i

Information

While prompt message is being stat-

For proper recognition, say the com-

ed Shortly press the

key on the

mand after the voice instruction and

Using Voice Recognition

steering remote controller

beep tone.

The prompt message is immediately

ended and the beep tone will sound.

Starting Voice Recognition

Contact List Best Practices

After the “beep”, say the voice com-

Shortly press the

key on the

1) Do not store single-name entries

mand.

steering wheel. Say a command.

(e.g.,

“Bob”, “Mom”, “Kim”, etc.).

Instead, always use full names

Re-starting Voice Recognition

(including first and last names) for

4

While system waits for a command

all contacts

(e.g., use

“Jacob

Shortly press the

key on the

Stevenson” instead of “Dad”).

steering remote controller

2) Do not use abbreviations (i.e., use

The command wait state is immedi-

“Lieutenant” instead of

“Lt.” or

ately ended and the beep tone will

“Sergeant” instead of “Sgt.”).

sound. After the “beep”, say the voice

3) Do not use acronyms (i.e., use

command.

If prompt feedback is in [ON], then

“County Finance Department”

the system will say "Please say a

instead of “CFD”).

command after the beep (BEEP)"

4) Do not use special characters

• If prompt feedback is in

[OFF]

(e.g., “@”, “hyphen -”, “asterisk *”,

mode, then the system will only

“ampersand &”).

say "(BEEP)"

5) If a name is not recognized from

• To change Prompt Feedback

[On]/[Off], go to

SETUP

[System]

the contact list, change it to a

[Prompt Feedback]

more descriptive name (e.g., use

“Grandpa Joseph” instead of “Pa

Joe”).

4-47

Multimedia System

ENDING VOICE RECOGNITION

Voice Recognition and Phone

Contact Tips:

The Hyundai Voice Recognition

While Voice Recognition is operating

System may have difficulty under-

Press and hold the

key on the

standing some accents or uncom-

steering remote controller

mon names.

When using Voice Recognition to

i

Information

place a call, speak in a moderate

•

While using voice command, press-

tone, with clear pronunciation To

ing any steering wheel control or a

maximize the use of Voice

different key will end voice com-

Recognition, consider these guide-

mand.

lines when storing contacts:

•

When the system is waiting for a

• Do not store single-name entries

voice command, say "cancel" or

(e.g.,

“Bob”, “Mom”, etc.). Instead,

"end" to end voice command.

always use full names (including first

•

When the system is waiting for a

and last names) for these contacts

voice command, press and hold the

• Do not use special characters

key on the steering wheel to end

(e.g., '@', '-', '*', '&', etc.)

voice command.

• Do not use abbreviations (i.e., use

"Lieutenant" instead of "Lt.") or

acronyms (i.e., use "County Finance

Department" instead of "C. F. D."; Be

sure to say the name exactly as it is

entered in the contacts list

4-48

Illustration on using voice commands

More Help

•

Starting voice command.

Here are some examples of mode commands.

Shortly pressing the

key (under 0.8 seconds):

You can say a radio type like 'FM', 'AM', or 'Satellite'.

You can also say a media source like 'USB', 'My

Please say a command after

Music', or 'iPod'.

the beep or say "help" for more

Beep~

Additionally, there are phone commands like

information.

"Contacts', 'Call History', or 'Dial Number".

More Help

You can find more detailed commands in the user's

manual.

Please say a command after the beep.

More Help

4

Here are some examples of mode commands.

You can say a radio type like 'FM', 'AM', or 'Satellite'.

•

Ending voice command.

You can also say a media source like 'USB', 'My

Music', or 'iPod'.

Shortly pressing the

key (under 0.8 seconds):

Additionally, there are phone commands like

"Contacts', 'Call History', or 'Dial Number".

Please say a command

after the beep or say "help"

You can find more detailed commands in the user's

for more information.

Contacts

manual.

Please say a command after the beep.

Please say the contact name you want to call.

•

Skipping Voice Recognition

Shortly pressing the

key (under 0.8 seconds):

Cancel

Please say a...

while guidance message is being stated

Shortly pressing the

key (under 0.8 seconds):

(BEEP)

More Help

4-49

Multimedia System

Voice Command List

•

Common Commands: These commands can be used in most operations. (However a few commands may not be

available during certain operations)

Command

Function

Command

Function

More Help

Provides guidance on commands that can be

Contacts

Displays the Contacts screen. After saying

used anywhere in the system.

(Call by Name)

this command, say the name of a contact

saved in the Contacts to automatically con-

Help

Provides guidance on commands that can be

nect the call.

used within the current mode.

Call<Name>

Calls <Name> saved in Contacts

Dial Number

Displays the Dial number screen. After saying

this command, you can say the number that

Ex) Call “John Smith”

you want to call.

Call <Name>

Calls <Name> to the number that is saved as

Redial

Connects the last dialed call number.

on Mobile

"Mobile" in Contacts

Ex) Call "John Smith" on Mobile

Tutorial

Provides guidance on how to use voice

recognition and Bluetooth® connections.

Call <Name>

Calls <Name> to the number that is saved as

in Office

"Office" in Contacts

• When listening to the radio, displays the

Ex) Call "John Smith" in Office

next radio screen. (FM1➟FM2➟AM➟XM1➟

Call <Name>

Calls <Name> to the number that is saved as

XM2➟XM3➟FM1)

at Home

"Home" in Contacts

Radio

• When listening to a different mode, displays

Ex) Call "John Smith" at Home

the most recently played radio screen.

Call <Name>

Calls <Name> to the number that is saved as

• When currently listening to the FM radio,

on Other

"Other" in Contacts

maintains the current state.

Ex) Call "John Smith" on Other

• When listening to a different mode, displays

Phone

Provides guidance on Phone related com-

the most recently played FM screen.

mands. After saying this command, say

FM1(FM One)

Displays the FM1 screen.

“Favorites”,“Call History”, “Contacts” or ”Dial

FM2(FM Two)

Displays the FM2 screen.

Number” execute corresponding functions.

AM

Displays the AM screen.

Favorites

Displays the Favorite screen.

Call History

Displays the Call History screen.

4-50

Command

Function

Command

Function

FM Preset 1~6

Plays the most recently played broadcast

Cancel (Exit)

Ends voice command.

saved in FM Preset 1~6.

AM Preset 1~6

Plays the broadcast saved in AM Preset 1~6.

FM 87.5~107.9

Plays the FM broadcast of the corresponding

frequency.

AM 530~1701

Plays the AM broadcast of the corresponding

frequency.

XM (Satellite)

• When currently listening to the SiriusXM®,

4

maintains the current state.

• When listening to a different mode, displays

the most recently played SiriusXM® screen.

XM (Satellite) 1~3

Displays the selected SiriusXM® screen.

XM

Plays the selected SiriusXM® channel.

Channel 0~223

Media

Moves to the most recently played media

screen.

CD

Plays the music saved in the CD.

USB

Plays USB music.

iPod®

Plays iPod music.

My Music

Plays the music saved in My Music.

AUX (Auxiliary)

Plays the connected external device.

Bluetooth® Audio

Plays the music saved in connected Bluetooth®

device.

Mute

Mutes the sound

4-51

Content   ..  15  16  17  18   ..
