Convenient features of your vehicle

Operating Door Locks from

• If the inner door handle of the driv-

With the central door lock

Inside the Vehicle

er door or front passenger door is

switch

pulled when the door lock button is

With the door lock button

■ Driver’s door

■ Front passenger’s door

in the lock position, the button is

unlocked and the door will open.

• The doors cannot be locked if the

smart key is in the vehicle and any

door is open.

Lock

Unlock

i

Information

If a power door lock ever fails to func-

tion while you are in the vehicle try

one or more of the following tech-

niques to exit:

OLF044011N/OLF044480N

OLF044010

• Operate the door unlock feature

When pressing the (

) switch (1), all

repeatedly

(both electronic and

•

To unlock a door, push the door

vehicle doors will lock.

manual) while simultaneously

lock button (1) to the "Unlock" posi-

When pressing the (

) switch (2), all

pulling on the door handle.

tion. The red mark (2) on the door

vehicle doors will unlock.

• Operate the other door locks and

lock button will be visible.

If the smart key is in the vehicle and

handles, front and rear.

•

To lock a door, push the door lock

any door is opened, the doors will

• Lower a front window and use the

button (1) to the "Lock” position. If

not lock even though the lock button

the door is locked properly, the red

mechanical key to unlock the door

(1) of the central door lock switch is

from outside.

mark (2) on the door lock button

pressed.

will not be visible.

•

To open a door, pull the door han-

WARNING

dle (3) outward.

Do not pull the inner door handle

of driver's (or passenger's) door

while the vehicle is moving.

3-10

WARNING

WARNING

CAUTION

The doors should always be

Always secure your vehicle.

Opening a door when something

fully closed and locked while

is approaching may cause dam-

Leaving your vehicle unlocked

the vehicle is in motion. If the

age or injury. Be careful when

increases the potential risk to

doors are unlocked, the risk of

opening doors and watch for

you or others from someone

being thrown from the vehicle in

vehicles, motorcycles, bicycles

hiding in your vehicle.

3

a crash is increased.

or pedestrians approaching the

To secure your vehicle, while

vehicle in the path of the door.

depressing the brake, move the

shift lever to the P (Park) posi-

WARNING

tion, engage the parking brake,

and place engine Start/Stop but-

Do not leave children or animals

ton to the OFF position, close all

unattended in your vehicle. An

windows, lock all doors, and

enclosed vehicle can become

always take the key with you.

extremely hot, causing death or

serious injury to unattended

children or animals who cannot

escape the vehicle. Children

WARNING

might operate features of the

vehicle that could injure them,

If people must spend a longer

or they could encounter other

time in the vehicle while it is

harm, possibly from someone

very hot or cold outside, there

gaining entry to the vehicle.

is rick of injuries or danger to

life. Do not lock the vehicle from

the outside when there are peo-

ple in it.

3-11

Convenient features of your vehicle

Auto Door Lock/Unlock Features

Child-Protector Rear Door locks

To lock the child safety lock, insert a

screwdriver into the hole and turn it

Impact sensing door unlock

to the lock position.

system

To allow a rear door to be opened

All doors will be automatically

from inside the vehicle, unlock the

unlocked when an impact causes the

child safety lock.

air bags to deploy.

WARNING

Shift lever auto door lock

All doors will be automatically locked

If children accidently open the

when shifting the shift lever out of P

rear doors while the vehicle is

(Park) with the engine running.

in motion, they could fall out of

OLF044012

the vehicle. The rear door safety

locks should always be used

You can activate or deactivate the

The child safety lock is provided to

whenever children are in the

Auto Door Lock/Unlock features from

help prevent children seated in the

vehicle.

the User Settings Mode on the LCD

rear from accidentally opening the

display.

rear doors. The rear door safety locks

should be used whenever children

For more information, refer to the

are in the vehicle.

"LCD Display" section in this

The child safety lock is located on

chapter.

the edge of each rear door. When the

child safety lock is in the lock

(1)

position, the rear door will not open if

the inner door handle (2) is pulled.

3-12

THEFT-ALARM SYSTEM

This system helps to protect your

Once the security system is set,

i

Information

vehicle and valuables. The horn will

opening any door, the trunk, or the

sound and the hazard warning lights

hood without using the smart key will

•

Do not lock the doors until all pas-

will blink continuously if any of the

cause the alarm to activate.

sengers have left the vehicle. If the

following occurs:

remaining passenger leaves the

The Theft Alarm System will not set if

vehicle when the system is armed,

- A door is opened without using the

the hood, the trunk, or any door is

the alarm will be activated.

smart key.

not fully closed. If the system will not

set, check the hood, the trunk, or the

•

If the vehicle is not disarmed with the

- The trunk is opened without using

3

doors are fully closed.

smart key, open the doors by using

the smart key.

the mechanical key and start hybrid

- The hood is opened.

Do not attempt to alter this system or

system by directly pressing the

add other devices to it.

The alarm continues for 30 seconds,

switch with the smart key.

then the system resets. To turn off

•

If the system is disarmed by unlock-

the alarm, unlock the doors with

ing the vehicle, but neither a door or

smart key.

the trunk is opened within 30 sec-

The Theft Alarm System automati-

onds, the doors will relock and the

cally sets 30 seconds after you lock

system will rearm automatically.

the doors and the trunk. For the sys-

tem to activate, you must lock the

doors and the trunk from outside the

vehicle with the smart key or by

pressing the button on the outside of

the door handle with the smart key in

your possession.

The hazard warning lights will blink

and the chime will sound once to

indicate the system is armed.

3-13

Convenient features of your vehicle

DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED)

Storing Positions into Memory

WARNING

1. Check that the shift lever is in P

(Park) while the engine Start/Stop

Never attempt to operate the driv-

er position memory system while

button is in the ON position.

the vehicle is moving.

2. Adjust the driver's seat position,

This could result in loss of con-

outside rearview mirror position

and instrument panel illumination

trol, and an accident causing

death, serious injury, or property

intensity to positions comfortable

for the driver.

damage.

3. Press the SET button. The system

will beep once and notify you

OLF044013

"Press button to save settings" on

The Driver Position Memory System

the LCD display.

is provided to store and recall the fol-

4. Press one of the memory buttons

lowing memory settings with a sim-

(1 or 2) within 5 seconds. The sys-

ple button operation.

tem will beep twice when the mem-

- Driver's seat position

ory has been successfully stored.

- Outside rearview mirror position

5.

- Instrument panel illumination intensity

If the battery is disconnected, the

position memory will be lost and the

driving positions must be stored in

the system again.

If

the Driver Position Memory

System does not operate normally,

OLF044403N/OLF044404N

have the system checked by an

authorized HYUNDAI dealer.

"Driver 1 (or 2) settings saved" will

appear on the LCD display.

3-14

Recalling positions from memory

NOTICE

Easy Access Function

1. Check that the shift lever is in P

When exiting the vehicle the driver’s

•

While recalling the "1" memory

(Park) while the engine Start/Stop

seat will move rearward when the

position, pressing the SET or 1

button is in the ON position.

engine is turned off and the shift lever

button temporarily stops the

2. Press the desired memory button

in P (Park).

adjustment of the recalled memo-

(1 or 2). The system will beep once,

ry position. Pressing the 2 button

When entering the vehicle the dri-

and then the driver's seat position,

recalls the "2" memory position.

ver's seat will move forward when

outside rearview mirror position

3

engine Start/Stop button is in the

•

While recalling the "2" memory

and instrument panel illumination

ACC position.

position, pressing the SET or 2

intensity will automatically adjust to

button temporarily stops the

You can activate or deactivate the

the stored positions.

adjustment of the recalled memo-

Easy Access Function from the User

3.

ry position. Pressing the 1 button

Settings Mode on the LCD display.

recalls the "1" memory position.

For more information, refer to the

•

While recalling the stored posi-

"LCD Display" section in this

tions, pressing one of the con-

chapter.

trol buttons for the driver’s seat,

outside rearview mirror or

instrument panel illumination

will cause the movement of that

OLF044401N/OLF044402N

component to stop and move in

"Driver 1(or 2) settings is applied" will

the direction that the control

appear on the LCD display.

button is pressed.

3-15

Convenient features of your vehicle

STEERING WHEEL

Electric Power Steering (EPS)

i

Information

CAUTION

The system assists you with steering

The following symptoms may occur

the vehicle. If the engine is turned off

If the Electric Power Steering

during normal vehicle operation:

or if the power steering system

System does not operate nor-

•

The steering effort may be high

becomes inoperative, you may still

mally, the warning light (

) will

immediately after placing the engine

steer the vehicle, but it will require

illuminate on the instrument

Start/Stop button is in the ON posi-

increased steering effort.

cluster. You may steer the vehi-

tion.

Should you notice any change in the

cle, but it will require increased

This happens as the system per-

effort required to steer during normal

steering efforts. Take your vehi-

forms the EPS system diagnostics.

vehicle operation, have the system

cle to an authorized HYUNDAI

When the diagnostics are completed,

checked by an authorized HYUNDAI

dealer and have the system

the steering wheel will return to its

dealer.

checked as soon as possible.

normal condition.

•

A click noise may be heard from the

EPS relay after the engine Start/Stop

button is in the ON/OFF position.

•

Motor noise may be heard when the

vehicle is at a stop or at a low driving

speed.

•

If the outside ambient temperature

is low, when you operate the steer-

ing wheel a noise from the electric

power steering may occur. As the

temperature increases, the noise will

disappear.

3-16

Tilt Steering / Telescope Steering

i

Information

When adjusting the steering wheel to

Sometimes the lock release lever may

a comfortable position, adjust the

not engage completely. This may

steering wheel so that it points

occur when the gears of the locking

toward your chest, not toward your

mechanism do not completely mesh.

face. Make sure you can see the

If this occurs, pull down on the lock-

instrument panel warning lights and

release lever, readjust the steering

gauges. After adjusting, push the

3

wheel again, and then pull back up on

steering wheel both up and down to

the release lever to lock the steering

be certain it is locked in position.

wheel in place.

Always adjust the position of the

steering wheel before driving.

OLF044015

To adjust the steering wheel angle

and height:

WARNING

1. Pull down the lock-release lever (1).

NEVER adjust the steering

2. Adjust the steering wheel to the

wheel while driving. This may

desired angle (2) and height (3).

cause loss of vehicle control

3. Pull up the lock-release lever to

resulting in an accident.

lock the steering wheel in place.

3-17

Convenient features of your vehicle

Heated Steering Wheel

NOTICE

Horn

(if equipped)

Do not install any cover or acces-

sory on the steering wheel. The

cover or accessory could cause

damage to the heated steering

wheel system.

OLF044018

OLFP045579N

To sound the horn, press the area

When the engine Start/Stop button is

indicated by the horn symbol on your

in the ON/OFF position or when the

steering wheel (see illustration). The

engine is running, press the heated

horn will operate only when this area

steering wheel button to warm the

is pressed.

steering wheel. The indicator on the

button will illuminate.

NOTICE

To turn the heated steering wheel off,

Do not strike the horn severely to

press the button again. The indicator

operate it, or hit it with your fist.

on the button will turn off.

Do not press on the horn with a

The heated steering wheel will auto-

sharp-pointed object.

matically turn off after approximately

30 minutes.

3-18

MIRRORS

Inside Rearview Mirror

Day/night rearview mirror

WARNING

(if equipped)

Before you start driving, adjust the

rearview mirror to center on the view

NEVER adjust the mirror while

■ Type A

through the rear window.

driving. This may cause loss of

vehicle control resulting in an

accident.

Night

WARNING

3

Make sure your line of sight is

NOTICE

not obstructed. Do not place

objects in the rear seat, cargo

When cleaning the mirror, use a

area, or behind the rear head-

paper towel or similar material

rests which could interfere with

dampened with glass cleaner. Do

Day

your vision through the rear

not spray glass cleaner directly on

OLF044019

■ Type B

window.

the mirror as this may cause the

liquid cleaner to enter the mirror

housing.

WARNING

To prevent serious injury during

an accident or deployment of

the air bag, do not modify the

rearview mirror and do not

install a wide mirror.

OLF044474N

Make this adjustment before you

start driving and while the day/night

lever is in the day position.

3-19

Convenient features of your vehicle

Pull the day/night lever toward you to

Blue Link® center (if equipped)

Electric chromic mirror (ECM)

reduce glare from the headlamps of

with HomeLink® system,

the vehicles behind you during night

compass and Blue Link®

driving.

(for U.S.A)

Remember that you lose some

Your vehicle may be equipped with a

rearview clarity in the night position.

Gentex Automatic-Dimming Mirror

with a Z-Nav™ Electronic Compass

Display and an Integrated HomeLink®

Wireless Control System. During

nighttime driving, this feature will

automatically detect and reduce

rearview mirror glare while the com-

pass indicates the direction the vehi-

OLF044021

cle is pointed. The HomeLink®

For details, refer to the Blue Link®

Universal Transceiver allows you to

Owner's Guide, Navigation Manual

activate your garage door(s), electric

or Audio Manual.

gate, home lighting, etc.

3-20

Automatic-Dimming Night Vision

Your mirror will automatically dim

Safety™ (NVS®) Mirror

upon detecting glare from the vehi-

(if equipped)

cles traveling behind you. The auto-

dimming function can be controlled

The NVS® Mirror automatically

by pressing the Dimming ON/OFF

reduces glare by monitoring light lev-

button:

els in the front and the rear of the

vehicle. Any object that obstructs

either light sensor will degrade the

1. Pressing and holding the button

3

automatic dimming control feature.

for 3 seconds turns the auto-dim-

ming function OFF which is indi-

For more information regarding

cated by the green Status

OLF044475N

NVS® mirrors and other applica-

Indicator LED turning off.

(1) Telematics button

tions, please refer to the Gentex

2. Pressing and holding the button

website:

for

3 seconds again turns the

(2) Telematics button

www.gentex.com

auto-dimming function ON which

(3) Telematics button

is indicated by the green Status

(4) Compass control button &

Indicator LED turning on.

Dimming ON/OFF button

The mirror defaults to the ON posi-

(5) Status indicator LED

tion each time the vehicle is started.

(6) Channel 1 button

(7) Channel 2 button

Z-Nav™ Compass Display

(8) Channel 3 button

The NVS™ Mirror in your vehicle is

(9) Compass display

also equipped with a Z-Nav™

Compass that shows the vehicle

(10) Rear light sensor

Compass heading in the Display

Window using the 8 basic cardinal

headings (N, NE, E, SE, etc.).

3-21

Convenient features of your vehicle

Compass function

The Compass can be turned ON and

OFF and will remember the last state

when hybrid system is cycled. To turn

the display feature ON/OFF:

1. Press and release the

button

within 1 second to turn the display

feature OFF.

2. Press and release the

button

again within 1 second to turn the

display back ON.

Additional options can be set with

press and hold sequences of the

button and are detailed below.

There is a difference between mag-

netic north and true north. To com-

pensate for this difference you will

need to adjust the Zone setting based

on where you live.

B520C05NF

3-22

To adjust the Zone setting:

If you need to recalibrate the com-

Integrated HomeLink® Wireless

pass:

Control System

1. Determine the desired Zone

Number based upon your current

1. Press and hold the

button for

The HomeLink® Wireless Control

location on the Zone Map.

more than 9 seconds. When the

System can replace up to three

compass memory is cleared a "C"

hand-held radio-frequency

(RF)

2. Press and hold the button for 6

will appear in the display.

transmitters with a single built-in

seconds, the current Zone

Number will appear on the display.

2. Drive the vehicle in 2 complete cir-

device. This innovative feature will

learn the radio frequency codes of

3

3. Pressing and holding the button

cles at less than 5 mph (8 km/h).

most current transmitters to operate

again will cause the numbers to

devices such as gate operators,

increment (Note: they will repeat

garage door openers, entry door

…13, 14, 15, 1, 2, …). Releasing

locks, security systems, even home

the button when the desired Zone

lighting. Both standard and rolling

Number appears on the display

code-equipped transmitters can be

will set the new Zone.

programmed by following the out-

4. Within about 5 seconds the com-

lined procedures.

pass will start displaying a com-

Additional HomeLink® information

pass heading again.

can be found at: www.homelink.com

or by calling 1-800-355-3515.

There are some conditions that can

Retain the original transmitter of the

cause changes to the vehicle mag-

RF device you are programming for

nets, such as installing a ski rack or

use in other vehicles as well as for

a CB antenna. Body repair work on

future HomeLink® programming. It is

the vehicle can also cause changes

also suggested that upon the sale of

to the vehicle’s magnetic field. In

the vehicle, the programmed

these situations, the compass will

HomeLink® buttons be erased for

need to be re-calibrated to quickly

security purposes.

correct these changes.

3-23

Convenient features of your vehicle

Programming HomeLink®

Programming

WARNING

Please note the following:

Flashing

Before programming HomeLink®

•

When programming a garage door

to a garage door opener or gate

opener, it is advised to park the

operator, make sure people and

vehicle outside of the garage.

objects are out of the way of the

•

It is recommended that a new bat-

device to prevent potential harm

tery be placed in the hand-held

or damage. Do not use the

transmitter of the device being pro-

HomeLink® with any garage door

grammed to HomeLink® for quicker

opener that lacks the safety stop

training and accurate transmission

and reverse features required by

of the radio-frequency signal.

U.S. federal safety standards (this

•

Some vehicles may require the

includes any garage door opener

ODH044413N

engine Start/Stop button to be

model manufactured before April

placed in the ACC position for pro-

To train most devices, follow these

1, 1982). A garage door that can-

gramming and/or operation of

instructions:

not detect an object - signaling

HomeLink®.

the door to stop and reverse -

1. For first-time programming, press

•

In the event that there are still pro-

does not meet current U.S. feder-

and hold the two outside buttons

gramming difficulties or questions

(

), HomeLink® Channel

1

al safety standards. Using a

,

garage door opener without

after following the programming

and Channel 3, until the indicator

steps listed below, contact

light begins to flash (after 10 sec-

these features increases the risk

of serious injury or death.

HomeLink®homelwww.homelink.com

onds). Release both buttons. Do

or by calling 1-800-355-3515.

not hold the buttons for longer

than 20 seconds.

3-24

4. Firmly press, hold for 5 seconds and

Flashing

i

Information

release

the

programmed

Some devices may require you to

HomeLink® button up to two sepa-

replace this Programming step 3 with

rate times to activate the door. If the

procedures noted in the "Gate

door does not activate, press and

Operator/Canadian Programming"

hold the just-trained HomeLink® but-

chapter. If the HomeLink® indicator

ton and observe the indicator light.

light does not change to a rapidly

• If the indicator light stays on con-

3

blinking light after performing these

stantly, programming is complete

steps,

contact HomeLink®

at

and your device should activate

www.homelink.com.

when the HomeLink® button is

ODH044414N

pressed and released.

2. Position the end of your hand-held

• If the indicator light blinks rapidly

transmitter

1-3 inches

(2-8 cm)

for 2 seconds and then turns to a

away from the HomeLink® button

constant light, continue with

you wish to program while keeping

"Programming" steps 5-7 to com-

the indicator light in view.

plete the programming of a rolling

code equipped device (most com-

3. Simultaneously press and hold

monly a garage door opener).

both the HomeLink® and hand-

held transmitter buttons until the

5. At the garage door opener receiv-

HomeLink® indicator light changes

er (motor-head unit) in the garage,

from a slow to a rapid blinking

locate the "learn" or "smart" but-

light. Now you may release both

ton. This can usually be found

the HomeLink® and hand-held

where the hanging antenna wire is

transmitter buttons.

attached to the motor-head unit.

3-25

Content   ..  4  5  6  7   ..
