Manual adjustment (if equipped)
(Continued)
The front seat can be adjusted by
• Use extreme caution when
using the levers located on the out-
picking up small objects
side of the seat cushion. Before driv-
trapped under the seats or
ing, adjust the seat to the proper
2
between the seat and the cen-
position so that you can easily con-
ter console. Your hands might
trol the steering wheel, foot pedals
be cut or injured by the sharp
and controls on the instrument
edges of the seat mechanism.
panel.
CAUTION
OAE036002
Forward and rearward adjustment
To prevent injury:
To move the seat forward or rearward:
• Do not adjust your seat while
1. Pull up the seat slide adjustment
wearing your seat belt.
lever and hold it.
Moving the seat cushion for-
ward may cause strong pres-
2. Slide the seat to the position you
sure on your abdomen.
desire.
• Do not allow your hands or
3. Release the lever and make sure
fingers to get caught in the
the seat is locked in place. Move
seat mechanisms while the
forward and rearward without
seat is moving.
using the lever. If the seat moves,
it is not locked properly.
2-7
Safety system of your vehicle
Reclining seatback
Seat belts must be snug against your
hips and chest to work properly.
Sitting in a reclined position when
When the seatback is reclined, the
the vehicle is in motion can be dan-
shoulder belt cannot do its job
gerous. Even when buckled up, the
because it will not be snug against
protection of your restraint system
your chest. Instead, it will be in front
(seat belts and air bags) is greatly
of you. During an accident, you could
reduced by reclining your seatback.
be thrown into the seat belt, causing
neck or other injuries.
WARNING
The more the seatback is reclined,
the greater chance the passenger's
NEVER ride with a reclined
OAE036003
hips will slide under the lap belt or
seatback when the vehicle is
the passenger's neck will strike the
Seatback angle
moving.
shoulder belt.
To recline the seatback:
Riding with a reclined seatback
1. Lean forward slightly and lift up
increases your chance of seri-
the seatback lever.
ous or fatal injuries in the event
of a collision or sudden stop.
2. Carefully lean back on the seat
and adjust the seatback to the
Drivers and passengers should
position you desire.
ALWAYS sit well back in their
seats, properly belted, and with
3. Release the lever and make sure
the seatbacks upright.
the seatback is locked in place.
(The lever MUST return to its orig-
inal position for the seatback to
lock.)
2-8
Power adjustment
NOTICE
(for driver's seat, if equipped)
To prevent damage to the seats:
The front seat can be adjusted by
•
Always stop adjusting the seats
using the control switches located on
when the seat has moved as far
2
the outside of the seat cushion. Before
forward or rearward as possible.
driving, adjust the seat to the proper
position so that you can easily control
•
Do not adjust the seats for
the steering wheel, foot pedals and
longer than necessary when the
controls on the instrument panel.
vehicle is turned off. This may
result in unnecessary battery
drain.
WARNING
OAE036004
•
Do not operate two or more
Seat cushion height
NEVER allow children in the
seats at the same time. This may
result in an electrical malfunc-
To change the height of the seat
vehicle unattended. The power
cushion:
seats are operable when the
tion.
vehicle is turned off.
• Push down on the lever several
times, to lower the seat cushion.
• Pull up on the lever several times,
to raise the seat cushion.
2-9
Safety system of your vehicle
Reclining seatback
Sitting in a reclined position when
the vehicle is in motion can be dan-
gerous. Even when buckled up, the
protections of your restraint system
(seat belts and air bags) is greatly
reduced by reclining your seatback.
WARNING
NEVER ride with a reclined seat-
OAE036006
OAE036007
back when the vehicle is moving.
Forward and rearward adjustment
Seatback angle
Riding with a reclined seatback
To move the seat forward or rearward:
To adjust the seatback:
increases your chance of serious
or fatal injuries in the event of a
1. Push the control switch forward or
1. Rotate the top of control switch
collision or sudden stop.
rearward.
forward or rearward.
Driver and passengers should
2. Release the switch once the seat
2. Release the switch once the seat-
ALWAYS sit well back in their
reaches the desired position.
back reaches the desired position.
seats, properly belted, and with
the seatbacks upright.
2-10
Seat belts must be snug against your
hips and chest to work properly.
When the seatback is reclined, the
shoulder belt cannot do its job
because it will not be snug against
2
your chest. Instead, it will be in front
of you. During an accident, you could
be thrown into the seat belt, causing
neck or other injuries.
The more the seatback is reclined,
the greater chance the passenger’s
hips will slide under the lap belt or
OAE036008
OAE036005
the passenger's neck will strike the
Seat cushion height
Lumbar support
shoulder belt.
To change the height of the seat
(for driver's seat, if equipped)
cushion:
To adjust the lumbar support:
1. • Push the front portion of the con-
1. Press the front portion of the
trol switch up to raise or down to
switch (1) to increase support or
lower the front part of the seat
the rear portion of the switch (2) to
cushion.
decrease support.
• Push the rear portion of the con-
2. Release the switch once it reach-
trol switch up to raise or down to
es the desired position.
lower the height of the seat cush-
ion.
2. Release the switch once the seat
reaches the desired position.
2-11
Safety system of your vehicle
Seatback pocket
Rear Seats
CAUTION
Folding the rear seat
Do not put heavy or sharp
The rear seatbacks can be folded to
objects in the seatback pockets.
facilitate carrying long items or to
In an accident they could come
increase the luggage capacity of the
loose from the pocket and
vehicle.
injure occupants.
WARNING
•
Never allow passengers to sit
on top of the folded down
seatback while the vehicle is
OAD035017
moving. This is not a proper
The seatback pocket is provided on
seating position and no seat
the back of the front passenger's
belts are available for use.
seatback.
This could result in serious
injury or death in case of an
WARNING
accident or sudden stop.
•
Objects carried on the folded
To prevent the Occupant
down seatback should not
Classification System from mal-
extend higher than the top of
functioning:
the front seatbacks. This
Do not hang onto the front pas-
could allow cargo to slide for-
senger's seatback.
ward and cause injury or dam-
age during sudden stops.
2-12
To fold down the rear seatback:
1. Set the front seatback to the
upright position and if necessary,
slide the front seat forward.
2
OAE036065L
OAE036020
5. Pull on the seatback folding lever
(1).
OAE036018
2. Lower the rear head restraints to
the lowest position by pushing and
holding the release button (1) and
OAE036019
pushing down on the headrest (2).
3. Insert the rear seat belt buckle in
the pocket between the rear seat-
back and cushion.
4. Locate the seatbelt toward the
outboard position before folding
down the seatback. If not, the
seatbelt system may be interfered
by the seatback.
2-13
Safety system of your vehicle
WARNING
When returning the rear seat-
back from a folded to an upright
position, hold the seatback and
return it slowly. Ensure that the
seatback is completely locked
into its upright position by
pushing on the top of the seat-
back. In an accident or sudden
stop, the unlocked seatback
OAE036021
OAE036066L
could allow cargo to move for-
6. Fold the seatback toward the front
7. To use the rear seat, lift and unfold
ward with great force and enter
of the vehicle.
the seatback to the upright posi-
the passenger compartment,
tion. Push the seatback firmly until
which could result in serious
it clicks into place. Make sure the
injury or death.
seatback is locked in place.
When you return the seatback to
its upright position, always be sure
it has locked into position by push-
ing on the top of the seatback.
2-14
Armrest (if equipped)
WARNING
CAUTION
Do not place objects in the rear
•
Be careful when loading
seats, since they cannot be
cargo through the rear pas-
2
properly secured and may hit
senger seats to prevent dam-
vehicle occupants in a collision
age to the vehicle interior.
causing serious injury or death.
•
When cargo is loaded through
the rear passenger seats,
ensure the cargo is properly
WARNING
secured to prevent it from
moving while driving.
Make sure the vehicle is off, the
•
Unsecured cargo in the pas-
shift lever is in P (Park), and the
OAE036022
senger compartment can
parking brake is securely applied
The armrest is located in the center
cause damage to the vehicle
whenever loading or unloading
of the rear seat. Use the strap in the
or injury to it's occupants.
cargo. Failure to take these steps
center of the armrest to pull it down.
may allow the vehicle to move if
the shift lever is inadvertently
moved to another position.
2-15
Safety system of your vehicle
Head Restraints
NOTICE
(Continued)
The vehicle's front and rear seats
•
To prevent damage, NEVER hit or
have adjustable head restraints. The
pull on the head restraints.
head restraints provide comfort for
passengers, but more importantly
they are designed to help protect
passengers from whiplash and other
neck and spinal injuries during an
accident, especially in a rear impact
collision.
OLF034072N
WARNING
Adjust the head restraints so
the middle of the head
To reduce the risk of serious
restraint is at the same height
injury or death in an accident,
as the height of the top of the
take the following precautions
eyes.
when adjusting your head
•
NEVER adjust the head
restraints:
restraint position of the dri-
• Always properly adjust the
ver's seat when the vehicle is
head restraints for all passen-
in motion.
gers BEFORE starting the
•
Adjust the head restraint as
vehicle.
close to the passenger's head
• NEVER let anyone ride in a
as possible. Do not use a seat
seat with the head restraints
cushion that holds the body
removed.
away from the seatback.
(Continued)
•
Make sure the head restraint
locks into position after adjust-
ing it.
2-16
Front seat head restraints
2
OAE036010
OLF034015
OPDE036068
Adjusting the height up and down
NOTICE
To raise the head restraint:
The vehicle's front and passenger's
If you recline the seatback towards
seats are equipped with adjustable
1. Pull it up to the desired position (1).
the front with the head restraint
head restraints for the passengers
and seat cushion raised, the head
safety and comfort.
restraint may come in contact with
To lower the head restraint:
the sunvisor or other parts of the
1. Push and hold the release button
vehicle.
(2) on the head restraint support.
2. Lower the head restraint to the
desired position (3).
2-17
Safety system of your vehicle
■ Type A
3. Press the head restraint release
■ Type A
button (3) while pulling the head
restraint up (4).
OAE036012
OAE036014
■ Type B
■ Type B
OAE036011
OAE036013
Removal/Reinstallation
To reinstall the head restraint:
To remove the head restraint:
1. Put the head restraint poles (2)
into the holes while pressing the
1. Recline the seatback (2) rearward
release button (1).
using the seatback angle lever/
switch (1).
2. Adjust the head restraint to the
appropriate height.
2. Raise the head restraint as far as
it can go.
3. Adjust the seatback
(4) forward
using the seatback angle lever/
switch (3).
2-18
Rear seat head restraints
2
OAE036017
OAE036072L
Adjusting the height up and down
Removal/Reinstallation
OPDE036069
To raise the head restraint:
To remove the head restraint:
The rear seats are equipped with
head restraints in all the seating
1. Pull it up to the desired position (1).
1. Raise the head restraint as far as
positions for the passenger's safety
it can go.
and comfort.
To lower the head restraint:
2. Press the head restraint release
button (1) while pulling the head
1. Push and hold the release button
(2) on the head restraint support.
restraint up (2).
2. Lower the head restraint to the
desired position (3).
To reinstall the head restraint:
1. Put the head restraint poles into
the holes (3) while pressing the
release button (1).
2. Adjust the head restraint to the
appropriate height.
2-19
Safety system of your vehicle
Seat warmers
(Continued)
WARNING
Front seat warmers (if equipped)
People who cannot detect tem-
Seat warmers are provided to warm
perature change or pain to the
NEVER place anything on the
the seats during cold weather.
skin should use extreme cau-
seat that insulates against heat
tion, especially the following
when the seat warmer is in oper-
types of passengers:
ation, such as a blanket or seat
WARNING
cushion. This may cause the
•
Infants, children, elderly or
seat warmer to overheat, caus-
The seat warmers can cause a
disabled persons, or hospital
ing a burn or damage to the seat.
SERIOUS BURN, even at low
outpatients.
temperatures and especially if
•
People with sensitive skin or
used for long periods of time.
who burn easily.
NOTICE
Passengers must be able to feel
•
Fatigued individuals.
To prevent damage to the seat
if the seat is becoming too warm
•
Intoxicated individuals.
warmers and seats:
so they can turn it off, if needed.
•
People taking medication that
• Never use a solvent such as
(Continued)
can cause drowsiness or
paint thinner, benzene, alcohol
sleepiness.
or gasoline to clean the seats.
• Do not place heavy or sharp
objects on seats equipped with
seat warmers.
• Do not change the seat cover. It
may damage the seat warmer.
2-20
• Each time you push the switch, the
Rear seat warmers (if equipped)
temperature setting of the seat is
changed as follows :
OFF
→
HIGH (
)
2
LOW (
)
MIDDLE (
)
• When pressing the switch for more
than
1.5 seconds with the seat
warmer operating, the seat warmer
OAE036015N
will turn OFF.
While the vehicle is in the ready
• The seat warmer defaults to the
OAE036023
(
) mode, push either of the
OFF position whenever the Engine
While the vehicle is in the ready
switches to warm the driver's seat or
Start/Stop button is in the ON posi-
(
) mode, push either of the
front passenger's seat.
tion.
switches to warm the rear seat.
During mild weather or under condi-
During mild weather or under condi-
tions where the operation of the seat
i
Information
tions where the operation of the seat
warmer is not needed, keep the
With the seat warmer switch in the
warmer is not needed, keep the
switches in the OFF position.
ON position, the heating system in the
switches in the OFF position.
seat turns off or on automatically
depending on the seat temperature.
2-21
Safety system of your vehicle
Each time you push the switch, the
Battery cooling duct
When the high voltage battery cool-
temperature setting of the seat is
ing duct is blocked, the high voltage
■ Hybrid vehicle
changed as follows :
battery may be overheated. Do not
obstruct the cooling duct with any
OFF → HIGH (
)
→ LOW (
)
other objects.
The seat warmer defaults to the OFF
position whenever the Engine Start/
Stop button is placed in the ON posi-
tion.
i
Information
OAE036024
With the seat warmer switch in the
■ Plug-in hybrid vehicle
ON position, the heating system in the
seat turns off or on automatically
depending on the seat temperature.
OAEPH036024
The high voltage battery cooling duct
is located on the left side of the rear
seats. The cooling duct cools down
the high voltage battery.
2-22
SEAT BELTS
This section describes how to use the
(Continued)
(Continued)
seat belts properly. It also describes
some of the things not to do when
•
NEVER allow children to ride
•
Do not use a seat belt if the
using seat belts.
in the front passenger seat. If
webbing or hardware is dam-
a child age 13 or older must be
aged.
2
seated in the front seat, move
•
Do not latch the seat belt into
Seat Belt Safety Precautions
the seat as far back as possi-
the buckles of other seats.
Always fasten your seat belt and
ble and properly restrain them
•
NEVER unfasten the seat belt
make sure all passengers have fas-
in the seat.
while driving. This may cause
tened their seat belts before starting
•
NEVER allow an infant or child
loss of vehicle control result-
any trip. Air bags are designed to
to be carried on an occupant’s
ing in an accident.
supplement the seat belt as an addi-
lap.
•
Make sure there is nothing in
tional safety device, but they are not a
•
NEVER ride with the seatback
the buckle interfering with the
substitute. Most states require all
reclined when the vehicle is
seat belt latch mechanism.
occupants of a vehicle to wear seat
moving.
This may prevent the seat belt
belts.
•
Do not allow children to share
from fastening securely.
a seat or seat belt.
•
No modifications or additions
WARNING
•
Do not wear the shoulder belt
should be made by the user
under your arm or behind your
which will either prevent the
Seat belts must be used by ALL
back.
seat belt adjusting devices
passengers whenever the vehi-
•
Always wear both the shoul-
from operating to remove
cle is moving. Take the following
slack, or prevent the seat belt
precautions when adjusting and
der portion and lap portion of
the lap/shoulder belt.
assembly from being adjusted
wearing seat belts:
to remove slack.
• ALWAYS properly restrain
•
Do not use the seat belt if it is
children under age 13 in the
twisted. A twisted seat belt
rear seats.
will not protect you properly
in an accident.
(Continued)
(Continued)
2-23
