To increase Cruise Control
• Depress the accelerator pedal.
To decrease Cruise Control
speed
When the vehicle attains the
speed
desired speed, push the toggle
switch down (SET-).
OAE056070
OAE056069
5
• Push the toggle switch up (RES+)
• Push the toggle switch down (SET-)
and release it immediately. The
and release it immediately. The
cruising speed will increase
1.0
cruising speed will decrease
1.0
mph (1.6 km/h) each time the tog-
mph (1.6 km/h) each time the toggle
gle switch is operated in this man-
switch is operated in this manner.
ner.
• Push the toggle switch down (SET-)
• Push the toggle switch up (RES+)
and hold it.Your vehicle will gradual-
and hold it, while monitoring the
ly slow down. Release the toggle
SET speed on the instrument clus-
switch at the speed you want to
ter.
maintain.
Release the toggle switch when
• Lightly tap the brake pedal. When
the desired speed is shown and
the vehicle attains the desired
the vehicle will accelerate to that
speed, push the toggle switch
speed.
down (SET-).
5-73
Driving your vehicle
To temporarily accelerate with
Cruise Control will be canceled
• The ESC
(Electronic Stability
the Cruise Control ON
when:
Control) is operating.
Depress the accelerator pedal. When
• Downshifting to 2nd gear when in
you take your foot off the accelerator,
Manual Shift mode.
the vehicle will return to the previ-
ously set speed.
i
Information
If you push the toggle switch down
Each of the above actions will cancel
(SET-) at the increased speed, the
Cruise Control operation (the "SET"
Cruise Control will maintain the
indicator in the instrument cluster will
increased speed.
go off), but only pressing the CRUISE
button will turn the system off. If you
wish to resume Cruise Control opera-
tion, push the toggle switch up (RES+)
located on your steering wheel. You
OAE056071
will return to your previously preset
•
Depressing the brake pedal.
speed, unless the system was turned off
•
Pressing the CANCEL button
using the CRUISE button.
located on the steering wheel.
•
Pressing the CRUISE button. Both
the "
" indicator and the
"SET" indicator will turn OFF.
•
Moving the shift lever into N
(Neutral).
•
Decreasing the vehicle speed to
less than approximately
20 mph
(30 km/h).
5-74
To resume preset Cruising
To turn Cruise Control off
speed
OAE056068
OAE056070
5
• Press the CRUISE button
(the
Push the toggle switch up (RES+). If
cruise (
) indicator light
the vehicle speed is over 20 mph (30
will go off).
km/h), the vehicle will resume the
• Turn the vehicle OFF.
preset speed.
5-75
Driving your vehicle
SMART CRUISE CONTROL SYSTEM (IF EQUIPPED)
■ Type A
■ Type B
The Smart Cruise Control System
WARNING
allows you to program the vehicle to
maintain constant speed and mini-
Take the following precautions :
mum distance between the vehicle
ahead.
•
Always set the vehicle speed
under the speed limit.
The Smart Cruise Control System
will automatically adjust your vehicle
•
If the Smart Cruise Control is
speed to maintain your programmed
left on,
(cruise
(
)
speed and following distance without
indicator light in the instru-
requiring you to depress the acceler-
ment cluster is illuminated)
ator or brake pedals.
the Smart Cruise Control can
OLF054430N/OAE056097N
be activated unintentionally.
Keep the Smart Cruise
➀ Cruise indicator
WARNING
Control System off
(cruise
➁ Set speed
(
) indicator light
For your safety, please read the
➂ Vehicle-to-vehicle distance
OFF) when the Smart Cruise
owner's manual before using the
Control is not in use, to avoid
Smart Cruise Control system.
inadvertently setting a speed.
To see the SCC screen on the LCD
display in the cluster, select SCC/
•
Use the Smart Cruise Control
LKA mode (
) for cluster type A or
System only when traveling
WARNING
ASSIST mode (
) for cluster type
on open highways in good
B. For more information, refer to
weather.
The Smart Cruise Control
"LCD Display Modes" in chapter 3.
System is not a substitute for
(Continued)
safe driving practices, but a
convenience function only. It is
the responsibility of the driver
to always check the speed and
distance to the vehicle ahead.
5-76
Smart Cruise Control Speed
(Continued)
To set Smart Cruise Control
•
Do not use the Smart Cruise
speed
Control when it may not be
safe to keep the vehicle at a
constant speed:
- When driving in heavy traffic
or when traffic conditions
make it difficult to drive at a
constant speed
- When driving on rainy, icy, or
snow-covered roads
OAE056069
- When driving on a steep
3. Push the toggle switch down
downhill or uphill
(SET-). The Set Speed and
5
- When driving in windy areas
Vehicle-to-Vehicle Distance on the
OAE056068
LCD display will illuminate.
- When driving in parking lots
1. Push the CRUISE button on the
4. Release the accelerator pedal.
- When driving near crash
steering wheel to turn the system
The desired speed will automati-
barriers
on. The cruise (
) indi-
cally be maintained.
- When driving on a sharp
cator will illuminate.
If there is a vehicle in front of you, the
curve
2. Accelerate to the desired speed.
speed may decrease to maintain the
- When driving with limited
The Smart Cruise Control speed
distance to the vehicle ahead.
view (possibly due to bad
can be set as follows:
On a steep grade, the vehicle may
weather, such as fog, snow,
rain or sandstorm)
• 20 - 110 mph (30 -180 km/h) :
slow down or speed up slightly while
going uphill or downhill.
when there is no vehicle in front
- When the vehicle sensing
ability decreases due to
• 5 - 110 mph (10 -180 km/h) :
vehicle modification result-
when there is a vehicle in front
ing level difference of the
vehicle's front and rear
5-77
Driving your vehicle
To increase Smart Cruise
i
Information
CAUTION
Control set speed
Vehicle speed may decrease on an
upward slope and increase on a down-
Check the driving condition
ward slope.
before using the toggle switch.
Driving speed sharply increas-
es, when you push up and hold
CAUTION
the toggle switch.
When vehicle speed is under 5
mph (10 km/h), the Smart Cruise
Control is canceled. The driver
must adjust the vehicle speed
by depressing the accelerator
or brake pedal according to the
OAE056070
road condition ahead and driv-
ing condition.
Follow either of these procedures:
• Push the toggle switch up (RES+),
and release it immediately. The
cruising speed will increase by
1 mph (1 km/h) each time you
move the toggle switch up in this
manner.
• Push the toggle switch up (RES+),
and hold it. Your vehicle set speed
will increase by 5 mph (10 km/h).
Release the toggle switch at the
speed you want.
5-78
To decrease the Smart Cruise
To temporarily accelerate with
Smart Cruise Control set speed
Control set speed
the Smart Cruise Control on
will be temporarily canceled
If you want to speed up temporarily
when:
when the Smart Cruise Control is on,
depress the accelerator pedal.
Increased speed will not interfere
with Smart Cruise Control operation
or change the set speed.
To return to the set speed, take your
foot off the accelerator pedal.
If you push the toggle switch down
(SET-) at increased speed, the cruis-
ing speed will be set again pedal.
OAE056069
5
Follow either of these procedures:
i
Information
OAE056071
• Push the toggle switch down
Be careful when accelerating tem-
Canceled manually
(SET-), and release it immediately.
porarily, because the speed is not con-
• Depressing the brake pedal.
The cruising speed will decrease
trolled automatically at this time even
• Pressing the CANCEL button
by 1 mph (1 km/h) each time you
if there is a vehicle in front of you.
located on the steering wheel.
move the toggle switch down in
this manner.
• Depress the brake pedal and press
the CANCEL button at the same
• Push the toggle switch down
time, when the vehicle is at a stand-
(SET-), and hold it. Your vehicle set
still.
speed will decrease by 5 mph (10
km/h). Release the toggle switch
at the speed you want.
• You can set the speed to 20 mph
(30 km/h).
5-79
Driving your vehicle
The Smart Cruise Control turns off
Canceled automatically
Each of these actions will cancel
temporarily when the Set Speed and
the Smart Cruise Control opera-
•
The driver's door is opened.
Vehicle-to-Vehicle Distance indicator
tion. The Set Speed and Vehicle-to-
•
The vehicle is shifted to N
on the LCD display turns off.
Vehicle Distance on the LCD dis-
(Neutral), R (Reverse) or P (Park).
play will go off.
The cruise (
) indicator is
•
The vehicle speed is over 120 mph
illuminated continuously.
In a condition the Smart Cruise
(190 km/h).
Control is canceled automatically,
•
The ESC
(Electronic Stability
the Smart Cruise Control will not
Control), TCS
(Traction Control
resume even though the RES+ or
System) or ABS is operating.
SET- toggle switch is pushed.
•
The ESC is turned off.
•
The sensor or the cover is dirty or
i
Information
blocked with foreign matter.
If the Smart Cruise Control is canceled
•
The accelerator pedal is continu-
by other than the reasons mentioned,
ously depressed for more than one
have the system checked by an author-
minute.
ized HYUNDAI dealer.
•
The SCC system has malfunc-
tioned.
•
The engine RPM enters the red
zone.
•
The FCA is activated.
5-80
To resume Smart Cruise Control
To turn Cruise Control off
set speed
If any method other than the cruise
toggle switch was used to cancel
cruising speed and the system is still
activated, the cruising speed will
automatically resume when you
push the toggle switch up (RES+) or
down (SET-).
If you push the toggle switch up
(RES+), the speed will resume to the
OAEE056165N
recently set speed. However, if vehi-
Smart Cruise Control canceled
cle speed drops below 20 mph (30
OAE056068
km/h), it will resume when there is a
If the system is canceled, the warn-
5
•
Press the CRUISE button
(the
vehicle in front of your vehicle.
ing chime will sound and a message
cruise (
) indicator light
will appear for a few seconds.
will go off).
i
Information
You must adjust the vehicle speed by
depressing the accelerator or brake
Always check the road conditions
pedal according to the road condition
when you push the toggle switch up
ahead and driving condition.
(RES+) to resume speed.
Always check the road conditions.
Do not rely on the warning chime.
5-81
Driving your vehicle
Smart Cruise Control Vehicle-
For example, if you drive at 56 mph
When the lane ahead is clear:
to-Vehicle Distance
(90 km/h), the distance is maintained
■ Type A
■ Type B
as follows:
To set Vehicle-to-Vehicle
Distance
Distance 4 - approximately 172 feet
Distance 3 - approximately 130 feet
Distance 2 - approximately 106 feet
Distance 1 - approximately 82 feet
i
Information
The distance is set to the last set dis-
OAE056178N/OAE056177N
tance when the system is used for the
first time after the vehicle is in the
The vehicle speed will maintain the
ready (
) mode.
set speed.
OAE056076
When the Smart Cruise Control
System is ON, you can set and main-
tain the distance from the vehicle
ahead of you without pressing the
accelerator or brake pedal.
Each time the button is pressed, the
vehicle to vehicle distance changes
as follows:
Distance 4
Distance 3
Distance 2
Distance 1
5-82
When there is a vehicle ahead of you in your lane:
WARNING
■ Type A
■ Type B
Distance 4
Distance 3
Distance 4
Distance 3
Distance 2
Distance 1
Distance 2
Distance 1
OAEE056140R
OAE056180N/OAE056179N/OAE056182N/OAE056181N
When using the Smart Cruise
OAE056184N/OAE056183N/OAE056186N/OAE056185N
5
Control System:
•
Your vehicle speed will slow down or speed up to maintain the selected
• The warning chime sounds
distance.
and the Vehicle-to Vehicle
•
If the vehicle ahead speeds up, your vehicle will travel at a steady cruis-
Distance indicator blinks if
ing speed after accelerating to the set speed.
the vehicle is unable to main-
tain the selected distance
from the vehicle ahead.
• If the warning chime sounds,
depress the brake pedal or
use the steering wheel toggle
switch to actively adjust the
vehicle speed, and the dis-
tance to the vehicle ahead.
(Continued)
5-83
Driving your vehicle
Sensor to Detect Distance to
(Continued)
CAUTION
the Vehicle Ahead
• Even if the warning chime is
not activated, always pay
attention to the driving condi-
tions to prevent dangerous
situations from occurring.
• Playing the vehicle audio sys-
tem at high volume may offset
the system warning sounds.
OAE056168L
If the vehicle ahead
(vehicle
OAE056028N
speed: less than 20 mph (30
The Smart Cruise Control uses a
km/h)) disappears to the next
sensor to detect distance to the vehi-
lane, the warning chime will
cle ahead.
sound and a message "Watch
for surrounding vehicles" will
appear. Adjust your vehicle
speed for vehicles or objects
that can suddenly appear in
front of you by depressing the
brake pedal.
Always pay attention to the road
condition ahead.
5-84
Warning message
CAUTION
(Continued)
•
If the front bumper becomes
•
Do not apply license plate
damaged in the area around
frame or foreign objects such
the radar sensor, the Smart
as a bumper sticker or a
Cruise Control System may
bumper guard near the radar
not operate properly. Have the
sensor. Doing so may
vehicle inspected by an
adversely affect the sensing
authorized HYUNDAI dealer.
performance of the radar.
•
Use only genuine HYUNDAI
•
Always keep the radar sensor
parts to repair or replace a
and lens cover clean and free
damaged sensor or sensor
of dirt and debris.
cover. Do not apply paint to
OAE056166L
the sensor cover.
•
Use only a soft cloth to wash
5
Smart Cruise Control disabled.
the vehicle. Do not spray pres-
Radar blocked
surized water directly on the
When the sensor lens cover is
sensor or sensor cover.
blocked with dirt, snow, or debris, the
•
Be careful not to apply unnec-
Smart Cruise Control System opera-
essary force on the radar sen-
tion may stop temporarily. If this
sor or sensor cover. If the sen-
occurs, a warning message will
sor is forcibly moved out of
appear on the LCD display. Remove
proper alignment, the Smart
any dirt, snow, or debris and clean
Cruise Control System may
the radar sensor lens cover before
not operate correctly. In this
operating the Smart Cruise Control
case, a warning message may
System. The Smart Cruise Control
not be displayed. Have the
system may not properly activate, if
vehicle inspected by an
the radar is totally contaminated, or if
authorized HYUNDAI dealer.
any substance is not detected after
(Continued)
the vehicle is in the ready
(
)
mode (e.g. in an open terrain).
5-85
Driving your vehicle
To Adjust the Sensitivity of
• Fast:
Smart Cruise Control
Vehicle speed following the front
vehicle to maintain the set distance
■ Type A
■ Type B
is faster than normal speed.
• Normal:
Vehicle speed following the front
vehicle to maintain the set distance
is normal.
• Slow:
Vehicle speed following the front
OAE056167L
vehicle to maintain the set distance
is slower than normal speed.
Check Smart Cruise Control System
The message will appear when the
OAE058099L/OAE058267L
vehicle to vehicle distance control
i
Information
The sensitivity of vehicle speed
system is not functioning normally.
The last selected speed sensitivity of
when following the front vehicle to
Take your vehicle to an authorized
the smart cruise control is remained in
maintain the set distance can be
HYUNDAI dealer and have the sys-
the system.
adjusted on the LCD display.
tem checked.
Cluster type A
'User Settings → Driver Assistance
→ Smart Cruise Control
→
Response → Fast/Normal/Slow'
Cluster type B
'User Settings → Driver Assistance
→ SCC reaction → Fast/Normal/
Slow'
You may select one of the three
stages you prefer.
5-86
To Convert to Cruise Control
Limitations of the System
WARNING
Mode
The Smart Cruise Control System
The driver may choose to switch to
may have limits to its ability to detect
When using the conventional
use the conventional Cruise Control
Cruise Control mode, you must
distance to the vehicle ahead due to
mode (speed only control function)
road and traffic conditions.
manually adjust the distance to
by following these steps:
other vehicles by depressing
1. Push the CRUISE button on the
the accelerator or brake pedal.
On curves
steering wheel to turn the system
The system does not automati-
on. The cruise (
) indi-
cally adjust the distance to vehi-
cator will illuminate.
cles in front of you.
2. Push and hold the Vehicle-to-
Vehicle Distance button for more
than 2 seconds.
5
3. Choose between "SCC Mode
(Smart Cruise Control)" and "CC
Mode (Cruise Control)".
When the system is canceled using
the CRUISE button or the CRUISE
button is used after the vehicle is in
OAE056100
the ready
(
) mode, the Smart
•
The Smart Cruise Control System
Cruise Control mode will turn on.
may not detect a moving vehicle in
your lane, and then your vehicle
could accelerate to the set speed.
Also, the vehicle speed will
decrease when the vehicle ahead
is recognized suddenly.
•
Select the appropriate set speed
on curves and apply the brakes or
accelerator pedal if necessary.
5-87
Driving your vehicle
On inclines
Lane changing
OAE056101
Your vehicle speed can be reduced
OAE056102
OAE056103
due to a vehicle in the adjacent lane.
•
During uphill or downhill driving,
•
A vehicle which moves into your
Apply the accelerator pedal and
the Smart Cruise Control System
lane from an adjacent lane cannot
select the appropriate set speed.
may not detect a moving vehicle in
be recognized by the sensor until it
Check to be sure that the road con-
your lane, and cause your vehicle
is in the sensor's detection range.
ditions permit safe operation of the
to accelerate to the set speed.
•
The radar may not detect immedi-
Smart Cruise Control.
Also, the vehicle speed will rapidly
ately when a vehicle cuts in sud-
decrease when the vehicle ahead
denly. Always pay attention to the
is recognized suddenly.
traffic, road and driving conditions.
•
Select the appropriate set speed
•
If a slower vehicle moves into your
on inclines and apply the brake or
lane, your speed may decrease to
accelerator pedal if necessary.
maintain the distance to the vehicle
ahead.
•
If a faster vehicle which moves into
your lane, your vehicle will acceler-
ate to the set speed.
5-88
Detecting vehicles
A vehicle ahead cannot be recog-
nized correctly by the sensor if any of
following occurs:
- When the vehicle is pointing
upwards due to overloading in the
luggage compartment
- While the steering wheel is operat-
ing
- When driving to one side of the lane
- When driving on narrow lanes or on
curves
OAE056108
Apply the brake or accelerator pedal
•
Your vehicle may accelerate when
OAE056104
if necessary.
a vehicle ahead of you disappears.
5
Some vehicles in your lane cannot
•
When you are warned that the
be recognized by the sensor:
vehicle ahead of you is not detect-
- Narrow vehicles such as motorcy-
ed, drive with caution.
cles or bicycles
- Vehicles offset to one side
- Slow-moving vehicles or sudden-
decelerating vehicles
- Stopped vehicles
- Vehicles with small rear profile such
as trailers with no loads
5-89
