Hyundai Ioniq Hybrid (2019 year). Manual - part 9
Convenient features of your vehicle
Instrument Cluster Control
Gauges and Meters
WARNING
Instrument panel illumination
Speedometer
Never adjust the instrument
■ Type A
cluster while driving. This could
result in loss of control and lead
to an accident that may cause
death, serious injury, or property
damage.
■ Type A
■ Type B
OAE046401N
OAE046102N
■ Type B
When the vehicle's position lights or
• ECO mode selected
headlights are on, press the illumina-
tion control button to adjust the
brightness of the instrument panel
illumination.
When pressing the illumination con-
trol button, the interior switch illumi-
OAE046167L/OAE046113L
nation intensity is also adjusted.
• The brightness of the instrument
panel illumination is displayed.
• If the brightness reaches to the
OAE046103N
maximum or minimum level, a
chime will sound.
3-56
■ Type B
Tachometer
Power gauge
• SPORT mode selected
■ Type B
• SPORT mode selected
3
OAE046104N
The speedometer indicates the
OAE046106N
OAEQ046008
speed of the vehicle and is calibrated
in miles per hour (MPH) and/or kilo-
The tachometer indicates the approx-
The power gauge indicates whether
imate number of engine revolutions
the current driving condition is fuel
meters per hour (km/h).
per minute (rpm).
efficient or not.
The speedometer for cluster type B
is displayed differently according to
Use the tachometer to select the cor-
• CHARGE :
the mode selected, ECO or SPORT.
rect shift points and to prevent lug-
Shows that the energy made by the
If the shift lever is in S
(Sport),
ging and/or over-revving the engine.
vehicle is being converted to elec-
SPORT mode is selected and if the
trical energy. (Regenerated energy)
shift lever is in D (Drive), ECO mode
NOTICE
• ECO :
is selected.
Do not operate the engine within
Shows that the vehicle is being
the tachometer's RED ZONE. This
driven in an Eco-friendly manner.
For more information, refer to
may cause severe engine damage.
"Dual Clutch Transmission" in
• POWER :
chapter 5.
Shows that the vehicle is exceed-
ing the Eco-friendly range.
3-57
Convenient features of your vehicle
Fuel gauge
i
Information
WARNING
■ Type A
■ Type B
Accordance to the power gauge area
the "EV" indicator comes on or off.
Running out of fuel can expose
vehicle occupants to danger.
- "EV" indicator ON : Vehicle is driv-
en using the electric motor or the
You must stop and obtain addi-
gasoline engine is stopped.
tional fuel as soon as possible
after the warning light comes
- "EV" indicator OFF : Vehicle is
on or when the gauge indicator
driven using the gasoline engine.
comes close to the "E (Empty)"
level.
NOTICE
OAE046107/OAE046108
This gauge indicates the approxi-
Avoid driving with an extremely
mate amount of fuel remaining in the
low fuel level. Running out of fuel
fuel tank.
could cause the engine to misfire
damaging the catalytic converter.
i
Information
• The fuel tank capacity is given in
chapter 8.
• The fuel gauge is supplemented by a
low fuel warning light, which will
illuminate when the fuel tank is
nearly empty.
• On inclines or curves, the fuel gauge
pointer may fluctuate or the low fuel
warning light may come on earlier
than usual due to the movement of
fuel in the tank.
3-58
Hybrid battery SOC
NOTICE
Plug-in hybrid mode indicator
(State of Charge) gauge
■ CD (Charge Depleting, Electric)
Never try to start the vehicle if the
■ Hybrid vehicle
■ Plug-in hybrid vehicle
fuel tank is empty. In this condi-
tion, the engine cannot charge the
high voltage battery of the hybrid
system. If you try to start the vehi-
cle when the fuel is empty, the
OAEPH047519N
■ CS (Charge Sustaining, Hybrid)
3
high voltage battery will become
discharged and be damaged.
OAEPH047520N
OAEQ046009/OAEPH046522
• CD
(Charge Depleting, Electric)
This gauge indicates the remaining
mode : The high-voltage (hybrid)
hybrid battery power. If the SOC is
battery is used to drive the vehicle.
near the "L (Low)" level, the vehicle
• CS
(Charge Sustaining, Hybrid)
automatically operates the engine to
mode : The high-voltage (hybrid)
charge the battery. However, if the
battery and gasoline engine is
Service Indicator
(
)
and
used to drive the vehicle.
Malfunction Indicator Lamp
(MIL)
(
) turn on when the SOC gauge
i
Information
is near the "L (Low)" level, have the
vehicle be checked by an authorized
Even when the battery charging rate
HYUNDAI dealer.
is high and driving in electric mode is
possible, engine may turn on in some
areas to protect the system.
3-59
Convenient features of your vehicle
Outside temperature gauge
To change the temperature unit from
Odometer
°F to °C or °C to °F:
■ Type A
■ Type B
■ Type A
■ Type B
- Go to User Settings Mode ➝ Other
(Features) ➝ Temperature Unit.
For vehicles equipped with Automatic
Climate Control, you can also:
- Press and hold the AUTO and OFF
buttons on the climate control unit
for 3 seconds
Both the temperature unit on the
OAE046135N/OAEE046502N
OAE046138N/OAE046112N
cluster LCD display and climate con-
This gauge indicates the current out-
The odometer indicates the total dis-
trol screen will change.
side air temperatures by 1°F (1°C).
tance that the vehicle has been driv-
- Temperature range : -40°F ~ 140°F
en and should be used to determine
when periodic maintenance should
(-40°C ~ 60°C)
be performed.
The outside temperature on the dis-
play may not change immediately
like a general thermometer (to avoid
distracting the driver).
3-60
Range
• The Range for cluster type A is
Dual clutch transmission shift
mentioned in "Trip Computer" in
indicator
■ Type A
■ Type B
this chapter.
■ Type A
■ Type B
i
Information
•
If the vehicle is not on level ground
or the battery power has been inter-
3
rupted, the range function may not
operate correctly.
•
The range may differ from the actu-
al driving distance as it is an esti-
mate of the available driving dis-
OAE046475N/OAE046126N
tance.
OAE046136L/OAE046110L
•
The range is the estimated dis-
•
The trip computer may not register
tance the vehicle can be driven
additional fuel if less than 1.6 gallon
This indicator displays which shift
with the remaining fuel.
(6 liters) of fuel are added to the
lever position is selected.
•
If the estimated distance is below
vehicle.
1 mi. (1 km), the trip computer will
•
The range may vary significantly
display "----" as range.
based on driving conditions, driving
•
The Range for cluster type B is dis-
habits, and condition of the vehicle.
played differently according to the
mode selected, ECO or SPORT. If
the shift lever is in S
(Sport),
SPORT mode is selected and if the
shift lever is in D
(Drive), ECO
mode is selected.
For more information, refer to
"Dual Clutch Transmission" in
chapter 5.
3-61
Convenient features of your vehicle
■ Type A
■ Type B
Warning and Indicator Lights
EV Mode Indicator
EV
i
Information
Make sure that all warning lights are
OFF after starting the engine. If any
This indicator illuminates when the
light is still ON, this indicates a situa-
vehicle is driven by the electric motor.
tion that needs attention.
Service Warning Light
Ready Indicator
OAE046137/OAE046111
Shift indicator pop-up (if equipped)
This indicator illuminates :
This warning light illuminates :
The pop-up indicates the current
When the vehicle is ready to be driven.
• When you place the Engine Start/
gear position displayed in the cluster
Stop button to the ON position.
for about 2 seconds when shifting
- ON : Normal driving is possible.
into other positions (P/R/N/D).
- OFF : Normal driving is not possible,
- It illuminates for approximately 3
seconds and then goes off.
or a problem has occurred.
• When there is a problem with the
- Blinking : Emergency driving.
hybrid vehicle control system or
hardware.
When the ready indicator goes OFF
or blinks, there is a problem with the
When the warning light illuminates
system. In this case, have your vehi-
while driving, or does not go OFF
cle inspected by an authorized
after starting the vehicle, have your
HYUNDAI dealer.
vehicle inspected by an authorized
HYUNDAI dealer.
3-62
Charging Cable
Seat Belt Warning Light
• When the regenerative brake does
Connection Indicator
not operate.
(Plug-in hybrid)
If the brake fluid level in the reser-
voir is low:
This indicator illuminates in red when
This warning light informs the driver
1. Drive carefully to the nearest safe
the charging cable is connected.
that the seat belt is not fastened.
location and stop your vehicle.
2. With the engine stopped, check the
3
For more details, refer to the "Seat
Air Bag Warning Light
brake fluid level immediately and
Belts" in chapter 2.
add fluid as required (For more
details, refer to "Brake Fluid" in
Parking Brake & Brake
chapter
7). After adding brake
Fluid Warning Light
fluid, check all brake components
This warning light illuminates:
for fluid leaks. If a brake fluid leak is
•
When you place the Engine Start/
found, or if the warning light
Stop button to the ON position.
remains on, or if the brakes do not
This warning light illuminates:
- It illuminates for approximately 6
operate properly, do not drive the
seconds and then goes off.
• When you place the Engine Start/
vehicle. Have the vehicle inspected
Stop button to the ON position.
by an authorized HYUNDAI dealer.
•
When there is a malfunction with
the SRS.
- It illuminates for approximately 3
seconds.
Dual-diagonal braking system
In this case, have the vehicle
inspected by an authorized
- It remains on if the parking brake
Your vehicle is equipped with dual-
is applied.
diagonal braking systems. This
HYUNDAI dealer.
means you still have braking on two
• When the parking brake is applied.
wheels even if one of the dual sys-
• When the brake fluid level in the
tems should fail.
reservoir is low.
With only one of the dual systems
- If the warning light illuminates
working, more than normal pedal
with the parking brake released, it
travel and greater pedal pressure is
indicates the brake fluid level in
required to stop the vehicle.
the reservoir is low.
3-63
Convenient features of your vehicle
Also, the vehicle will not stop in as
Regenerative Brake
Anti-lock Brake System
short a distance with only a portion
Warning Light
(ABS) Warning Light
of the brake system working.
If the brakes fail while you are driv-
ing, shift to a lower gear for addition-
This warning light illuminates :
This warning light illuminates:
al engine braking and stop the vehi-
• When you place the Engine Start/
•
When you place the Engine Start/
cle as soon as it is safe to do so.
Stop button to the ON position.
Stop button to the ON position.
- It illuminates for approximately 3
- It illuminates for approximately 3
WARNING
seconds.
seconds and then goes off.
• When the regenerative brake does
•
When there is a malfunction with
Parking Brake & Brake Fluid
not operate and the brake does not
the ABS (The normal braking sys-
Warning Light
perform well. This causes the Brake
tem will still be operational without
Driving the vehicle with a warn-
Warning light and Regenerative
the assistance of the anti-lock
ing light ON is dangerous. If the
Brake Warning Light to illuminate
brake system).
Parking Brake & Brake Fluid
simultaneously.
In this case, have the vehicle inspect-
Warning Light illuminates with
In this case, drive safely and have
ed by an authorized HYUNDAI deal-
the parking brake released, it
your vehicle inspected by an author-
er.
indicates that the brake fluid
ized HYUNDAI dealer.
level is low.
The operation of the brake pedal may
In this case, have the vehicle
be more difficult than normal and the
inspected by an authorized
braking distance can increase.
HYUNDAI dealer.
3-64
Electronic Brake Force
Electric Power Steering
(Continued)
Distribution (EBD)
(EPS) Warning Light
In this case, avoid high speed
System Warning Light
driving and abrupt braking.
Have the vehicle inspected by
This warning light illuminates:
an authorized HYUNDAI dealer
as soon as possible.
•
When you place the Engine Start/
Stop button to the ON position.
These two warning lights illuminate
3
at the same time while driving:
- It illuminates for approximately 3
i
Information - Electronic
seconds and then goes off.
• When the ABS and regular brake
Brake Force Distribution
system may not work normally.
•
When there is a malfunction with
(EBD) System Warning Light
the EPS.
In this case, have the vehicle inspect-
When the ABS Warning Light is on or
ed by an authorized HYUNDAI deal-
In this case, have the vehicle inspect-
both ABS and Parking Brake & Brake
er.
ed by an authorized HYUNDAI deal-
Fluid Warning Lights are on, the
er.
speedometer, odometer, or tripmeter
WARNING
may not work. Also, the EPS Warning
Light may illuminate and the steering
Electronic Brake Force
effort may increase or decrease.
Distribution (EBD) System
In this case, have the vehicle inspected
Warning Light
by an authorized HYUNDAI dealer as
soon as possible.
When both ABS and Parking
Brake & Brake Fluid Warning
Lights are on, the brake system
will not work normally and you
may experience an unexpected
and dangerous situation during
sudden braking.
(Continued)
3-65
Convenient features of your vehicle
Malfunction Indicator
NOTICE
Engine Oil Pressure
Lamp (MIL)
Warning Light
If the Malfunction Indicator Lamp
(MIL) illuminates, potential catalyt-
ic converter damage is possible
This warning light illuminates:
which could result in loss of
This warning light illuminates:
• When you place the Engine Start/
engine power.
• When the engine oil pressure is low.
Stop button to the ON position.
In this case, have the vehicle inspect-
- It illuminates for approximately 3
ed by an authorized HYUNDAI dealer
If the engine oil pressure is low:
seconds and then goes off.
as soon as possible.
1. Drive carefully to the nearest safe
• When there is a malfunction with
location and stop your vehicle.
the emission control system.
Charging System
2. Turn the engine off and check the
In this case, have the vehicle inspect-
Warning Light
engine oil level (For more details,
ed by an authorized HYUNDAI deal-
refer to "Engine Oil" in chapter 7).
er.
If the level is low, add oil as required.
When this warning light illuminates
If the warning light remains on
NOTICE
while running the engine, the battery
after adding oil or if oil is not avail-
is not being charged. Immediately
able, have the vehicle inspected
Driving with the Malfunction
turn OFF all electrical accessories.
by an authorized HYUNDAI dealer
Indicator Lamp
(MIL) on may
Try not to use electrically operated
as soon as possible.
cause damage to the emission
controls, such as the power win-
control system which could affect
dows. Keep running the engine.
drivability and/or fuel economy.
Have the vehicle inspected by an
authorized HYUNDAI dealer as soon
as possible.
3-66
NOTICE
Low Fuel Level
Engine Coolant
Warning Light
Temperature Warning
•
If the engine does not stop
Light
immediately after the Engine Oil
Pressure Warning Light is illumi-
nated, severe damage could
This warning light illuminates:
This warning light illuminates:
result.
• When the fuel tank is nearly empty.
• When the engine coolant temper-
•
If the warning light stays on
Add fuel as soon as possible.
ature is above 248°F (120°C). This
3
while the engine is running, it
means that the engine is overheat-
indicates that there may be seri-
ed and may be damaged.
NOTICE
ous engine damage or malfunc-
tion. In this case:
Driving with the Low Fuel Level
If your vehicle is overheated, refer
warning light on or with the fuel
to "Overheating" in chapter 6.
1. Stop the vehicle as soon as it
level below "E" can cause the
is safe to do so.
engine to misfire and damage the
2. Turn off the engine and check
catalytic converter (if equipped).
the oil level. If the oil level is
low, fill the engine oil to the
proper level.
3. Start the engine again. If the
warning light stays on after the
engine is started, turn the
engine off immediately. In this
case, have the vehicle inspect-
ed by an authorized HYUNDAI
dealer.
3-67
Convenient features of your vehicle
Master Warning Light
Low Tire Pressure
This warning light remains ON
Warning Light
after blinking for approximately 60
(if equipped)
seconds, or repeatedly blinks ON
and OFF in 3 second intervals:
• When there is a malfunction with
This indicator light illuminates:
This warning light illuminates:
the TPMS.
•
When there is a malfunction in oper-
• When you place Engine Start/Stop
In this case, have the vehicle inspect-
ation in any of the following systems:
button to the ON position.
ed by an authorized HYUNDAI deal-
- Low washer fluid (if equipped)
- It illuminates for approximately 3
er as soon as possible.
- Exterior lamp malfunction
seconds and then goes off.
• When one or more of your tires are
For more details, refer to
- Forward
Collision-Avoidance
Assist
(FCA) malfunction
(if
significantly underinflated.
"Tire Pressure Monitoring System
equipped)
(TPMS)" in chapter 6.
For more details, refer to
- Blind-Spot Collision Warning
"Tire Pressure Monitoring System
(BCW) System malfunction
(if
WARNING
(TPMS)" in chapter 6.
equipped)
- Smart cruise control malfunction
Safe Stopping
(if equipped)
• The TPMS cannot alert you to
- High Beam Assist malfunction (if
severe and sudden tire damage
equipped)
caused by external factors.
- Tire Pressure Monitoring System
• If you notice any vehicle insta-
(TPMS)
bility, immediately take your
foot off the accelerator pedal,
- Service reminder
apply the brakes gradually with
To identify the details of the warning,
light force, and slowly move to
look at the LCD display.
a safe position off the road.
3-68
Electronic Stability
Electronic Stability
Immobilizer Indicator
Control (ESC) Indicator
Control (ESC) OFF
Light
Light
Indicator Light
This indicator light illuminates:
This indicator light illuminates:
This indicator light illuminates for
up to 30 seconds:
• When you place the Engine Start/
• When you place the Engine Start/
Stop button to the ON position.
Stop button to the ON position.
• When the vehicle detects the smart
3
key in the vehicle with the Engine
- It illuminates for approximately 3
- It illuminates for approximately
Start/Stop button in the ACC or ON
seconds and then goes off.
3 seconds and then goes off.
position.
• When there is a malfunction with
• When you deactivate the ESC sys-
- At this time, you can start the
the ESC system.
tem by pressing the ESC OFF but-
engine.
ton.
In this case, have the vehicle inspect-
- The indicator light goes off after
ed by an authorized HYUNDAI dealer.
starting the engine.
For more details, refer to
"Electronic Stability Control (ESC)"
This indicator light blinks:
in chapter 5.
This indicator light blinks for a few
• While the ESC is operating.
seconds:
• When the smart key is not in the vehi-
For more details, refer to
cle.
"Electronic Stability Control (ESC)"
- At this time, you cannot start the
in chapter 5.
engine.
3-69
Convenient features of your vehicle
This indicator light illuminates for 2
Turn Signal Indicator
High Beam Indicator
seconds and goes off:
Light
Light
• If the smart key is in the vehicle and
the Engine Start/Stop button is ON,
but the vehicle cannot detect the
This indicator light blinks:
This indicator light illuminates:
smart key.
• When you operate the turn signal
• When the headlamps are on and in
In this case, have the vehicle inspect-
indicator light.
the high beam position.
ed by an authorized HYUNDAI dealer.
• When the turn signal lever is pulled
If any of the following occurs, there
into the Flash-to-Pass position.
This indicator light blinks:
may be a malfunction with the turn
• When the battery voltage of the
signal system.
Light ON Indicator
smart key is low.
- The turn signal indicator light illumi-
Light
- At this time, you can not start the
nates but does not blink
engine. However, you can start
- The turn signal indicator light blinks
the engine if you press the
rapidly
This indicator light illuminates:
Engine Start/Stop button with the
- The turn signal indicator light does
smart key.
(For more details,
• When the tail lights or headlamps
refer to "Starting the Vehicle"
not illuminate at all
are on.
in chapter 5).
If either of these conditions occur,
have your vehicle inspected by an
• When there is a malfunction with
authorized HYUNDAI dealer.
the immobilizer system.
In this case, have the vehicle
inspected by an authorized
HYUNDAI dealer.
3-70
High Beam Assist
Exterior Light Warning
LED Headlight Warning
(HBA) indicator light
Light (if equipped)
Light (if equipped)
(if equipped)
This indicator light illuminates :
This warning light illuminates:
This warning light illuminates:
• When the high-beam is on with the
• When one of the exterior bulbs
• When you place the Engine Start/
light switch in the AUTO light posi-
(headlamp, tail lamp, fog lamp, etc.)
Stop button to the ON position.
3
tion.
is not operating properly. One of the
• When there is a malfunction with
bulbs may need to be replaced.
• If your vehicle detects oncoming or
the LED headlight.
preceding vehicles, the High Beam
In this case, have the vehicle
Assist (HBA) system will switch the
i
Information
inspected by an authorized
high beam to low beam automati-
HYUNDAI dealer.
Make sure to replace the burned out
cally.
bulb with a new one of the same
wattage rating.
For more details, refer to "High
This warning light blinks:
Beam Assist (HBA) system" in this
• When there is a malfunction with a
chapter.
LED headlight related part.
In this case, have the vehicle
inspected by an authorized
HYUNDAI dealer.
NOTICE
Continuous driving with the LED
Headlight Warning Light on or
blinking can reduce LED headlight
life.
3-71
Convenient features of your vehicle
Cruise Indicator Light
SPORT Mode Indicator
Forward Collision-
(if equipped)
Light
Avoidance Assist
Waning Light
(if equipped)
This indicator light illuminates:
This indicator light illuminates
This warning light illuminates :
• When the cruise control system is
enabled.
• When the driver moves the shift
•
When you place the Engine Start/
lever to S (Sport).
Stop button to the ON position.
For more details, refer to "Cruise
- It illuminates for approximately 3
Control System" in chapter 5.
For more details, refer to "Dual
seconds. (for cluster type B)
Clutch Transmission" in chapter 5.
•
When the FCA system is turned
Cruise SET Indicator
off.
Light (if equipped)
ECO Mode Indicator
•
When the radar sensor or cover is
Light
blocked with dirt or snow. Check
the sensor and cover and clean
them by using a soft cloth.
This indicator light illuminates:
This indicator light illuminates:
•
When there is a malfunction with
• When the cruise control speed is
FCA. In this case, have your vehicle
set.
• When the driver moves the shift
inspected by an authorized dealer of
lever to D (Drive).
HYUNDAI.
For more details, refer to "Cruise
Control System" in chapter 5.
For more details, refer to "Dual
Clutch Transmission" in chapter 5.
3-72
