Hyundai i30 (2018 year). Manual - part 10
Convenient features of your vehicle
To manually reset the information,
Digital Speedometer
press and hold the OK button when
■ Type A
■ Type B
viewing the Driving info. The trip dis-
tance, the average fuel economy, and
total driving time will reset simultane-
ously.
The driving information will continue
to be counted while the engine is still
running (for example, when the vehi-
cle is in traffic or stopped at a stop
light.)
i
Information
OPDE046145/OPDE046146
The vehicle must be driven for a min-
This message shows the speed of
imum of 300 meters (0.19 miles) since
the vehicle (km/h, MPH).
the last ignition key cycle before the
average fuel economy will be recalcu-
lated.
3-82
LIGHT
Exterior lights
NOTICE
Lighting control
•
Do not cover or spill anything on
the sensor (1) located on the
instrument panel.
•
Do not clean the sensor using a
window cleaner, the cleanser
may leave a light film which
3
could interfere with sensor oper-
ation.
•
If your vehicle has window tint
OPDE046036
or other types of metallic coat-
ing on the front windshield, the
AUTO light position (if equipped)
AUTO light system may not work
OPDE046065
When the light switch is in the AUTO
properly.
position, the position lamp and head-
To operate the lights, turn the knob at
lamp will be turned ON or OFF auto-
the end of the control lever to one of
matically depending on the amount
the following positions:
of light outside the vehicle.
(1) O position
(2) AUTO light position (if equipped)
Even with the AUTO light feature in
(3) Position lamp position
operation, it is recommended to
(4) Headlamp position
manually turn ON the lamps when
driving at night or in a fog, or when
you enter dark areas, such as tun-
nels and parking facilities.
3-83
Convenient features of your vehicle
High beam operation
OAE046469L
OAE046467L
Position lamp position (
)
Headlamp position (
)
OAE046453L
The position lamp, license plate lamp
The headlamp, position lamp, license
To turn on the high beam headlamp,
and instrument panel lamp are turned
plate lamp and instrument panel lamp
push the lever away from you. The
ON.
are turned ON.
lever will return to its original position.
The high beam indicator will light
i
Information
when the headlamp high beams are
The ignition switch must be in the ON
switched on.
position to turn on the headlamp.
To turn off the high beam headlamp,
pull the lever towards you. The low
beams will turn on.
WARNING
Do not use high beam when there
are other vehicles approaching
you. Using high beam could
obstruct the other driver's vision.
3-84
Smart high beam (if equipped)
Operating condition
1.Place the light switch in the AUTO
position.
2.Turn on the high beam by pushing
the lever away from you.
The smart high beam (
) indica-
tor will illuminate.
3
3.The Smart High Beam will turn on
when vehicle speed is above
45km/h (25mph).
OAE046455L
• If the lever is pushed away when
the Smart High Beam is operat-
To flash the high beam headlamp,
OPDE046057
pull the lever towards you, then
ing, the Smart High Beam will
The Smart High Beam is a system
turn off and the high beam will be
release the lever. The high beams
that automatically adjusts the head-
on continuously. The smart high
will remain ON as long as you hold
lamp range (switches between high
beam (
) indicator will turn off.
the lever towards you.
beam and low beam) according to
4.If the light switch is placed to the
the brightness of other vehicles and
headlamp position, the Smart High
road conditions.
Beam will turn off and the low
beam will be on continuously.
3-85
Convenient features of your vehicle
The high beam switches to low beam
Warning light and message
CAUTION
in the below conditions.
-
When the Smart High Beam is off.
The system may not operate
-
When the light switch is not in the
normally in the below condi-
AUTO position.
tions.
-
When the headlamp is detected
•
When the light from the on-
from the on-coming vehicle.
coming or front vehicle is not
-
When the tail lamp is detected
detected because of lamp
from the front vehicle.
damage, hidden from sight,
etc.
-
When the surrounding is bright
enough high beams are not needed.
•
When the lamp of the on-com-
ing or front vehicle is covered
-
When streetlights or other lights
ODM046655L
with dust, snow or water.
are detected.
When the Smart High Beam Assist
•
When the light from the on-
-
When vehicle speed is below
System is not working properly, the
coming or front vehicle is not
35km/h (15mph).
warning message will come on for a
detected because of exhaust
few second. After the message disap-
fumes, smoke, fog, snow, etc.
pears, the master warning light (
)
•
When the front window is cov-
will illuminate.
ered with foreign matter such
We recommend that you take your
as ice, dust, fog, or is dam-
vehicle to an authorized HYUNDAI
aged.
dealer and have the system
(Continued)
checked.
3-86
(Continued)
(Continued)
WARNING
•
When there is a similar
•
When the front vehicle’s head-
shaped lamp with the front
lamps are off but the fog
•
Do not place any accessories,
vehicle’s lamps.
lamps on.
stickers or tint the windshield.
•
When it is hard to see
•
When a vehicle suddenly
•
Have the windshield glass
because of fog, heavy rain or
appears from a around a cor-
replaced by an authorised
snow.
ner.
dealer.
3
•
When the headlamp is not
•
When the vehicle is tilted from
•
Do not remove or impact relat-
repaired or replaced at an
a flat tyre or being towed.
ed parts of the Smart High
authorized dealer.
Beam system.
•
When the LDWS (Lane Departure
•
When headlamp aiming is not
Warning System) or LKAS (Lane
•
Be careful that water doesn’t
properly adjusted.
Keeping Assist System) warning
get into the Smart High Beam
light illuminates. (if equipped)
unit.
•
When driving on a narrow
winding road or rough road.
•
Do not place objects on the
instrument panel that reflect
•
When driving downhill or
light such as mirrors, white
uphill.
paper, etc. The system may
•
When only part of the vehicle
malfunction if sunlight is
in front is visible on a cross-
reflected.
road or on a corner.
•
At times, the Smart High
•
When there is a traffic light,
Beam system may not work
reflecting sign, flashing sign
properly, always check the
or mirror.
road conditions for your safe-
•
When the road conditions are
ty. When the system does not
bad such as being wet or cov-
operate normally, manually
ered with snow.
change between the high
(Continued)
beam and low beam.
3-87
Convenient features of your vehicle
Turn signals and lane change
One-touch turn signal function
Front fog lamp (if equipped)
signals
To activate an one-touch turn signal
function, move the turn signal lever
slightly and then release it. The lane
change signals will blink 3, 5 or 7
times.
You can activate/deactivate the One
Touch Turn Signal function or choose
the number of blinking (3, 5, or 7)
from the User Settings mode on the
LCD display. For more details, refer
to "LCD Display" in this chapter.
OPDE046066
OTLE045284
Fog lamps are used to provide
To signal a turn, push down on the
improved visibility when visibility is
lever for a left turn or up for a right
poor due to fog, rain or snow, etc. Use
turn in position (A). To signal a lane
the switch next to the headlamp switch
change, move the turn signal lever
to turn the fog lamps ON and OFF.
slightly and hold it in position (B).The
1. Turn on the position lamp.
lever will return to the OFF position
2. Turn the light switch (1) to the front
when released or when the turn is
fog lamp position.
completed.
If an indicator stays on and does not
flash or if it flashes abnormally, one of
the turn signal bulbs may be burned
out and will require replacement.
3-88
3. To turn off the front fog lamp, turn
Rear fog lamp
the light switch to the front fog
lamp position again or turn off the
position lamp.
NOTICE
When in operation, the fog lamps
3
consume large amounts of vehicle
electrical power. Only use the fog
lamps when visibility is poor.
OTLE045285
Vehicle without front fog lamp
OPDE046064
To turn on the rear fog lamp:
Vehicle with front fog lamp
Position the light switch in the head-
To turn on the rear fog lamp:
lamp position, and then turn the light
Position the light switch in the posi-
switch (1) to the rear fog lamp position.
tion lamp position, turn the light
switch (1) to the front fog lamp posi-
tion, and then turn the light switch (1)
To turn the rear fog lamps off, do one
to the rear fog lamp position.
of the following:
To turn the rear fog lamps off, do one
• Turn off the headlamp switch.
of the following:
• Turn the light switch to the rear fog
• Turn off the position light switch.
lamp position again.
• Turn the light switch to the rear fog
lamp position again.
• When the light switch is in the posi-
tion lamp position, if you turn off
the front fog lamp, the rear fog
lamp will also turn off.
3-89
Convenient features of your vehicle
Battery saver function
Headlamp delay function
NOTICE
The purpose of this feature is to pre-
(if equipped)
If the driver gets out of the vehicle
vent the battery from being dis-
If you place the ignition switch to the
through other doors (except dri-
charged. The system automatically
ACC or OFF position with the head-
ver's door), the battery saver func-
turns off the position lamp when the
lamps ON, the headlamps (and/or
tion does not operate and the
driver turns the engine off and opens
position lamps) remain on for about 5
headlamp delay function does not
the driver-side door.
minutes. However, with the engine off if
turn off automatically. Therefore, It
With this feature, the position lamps
the driver’s door is opened and closed,
causes the battery to be dis-
will turn off automatically if the driver
the headlamps (and/or position lamps)
charged. In this case, make sure to
parks on the side of road at night.
are turned off after 15 seconds.
turn off the lamp before getting out
If necessary, to keep the lamps on
The headlamps
(and/or position
of the vehicle.
lamps) can be turned off by pressing
when the engine is turned off, perform
the following:
the lock button on the remote key or
smart key twice or turning the light
1) Open the driver-side door.
switch to the OFF or AUTO position.
2) Turn the position lamps OFF and
However, if you turn the light switch
ON again using the light switch on
to the AUTO position when it is dark
the steering column.
outside, the headlamps will not be
turned off.
You can activate or deactivate the
Headlamp Delay function from the
User Settings mode on the LCD dis-
play. For more details, refer to
"LCD Display" in this chapter.
3-90
Daytime running light (DRL)
Headlight leveling device
Listed below are the examples of
(if equipped)
(if equipped)
proper switch settings. For loading
conditions other than those listed
The Daytime Running Lights (DRL)
below, adjust the switch position so
can make it easier for others to see
that the beam level may be the near-
the front of your vehicle during the
est as the condition obtained accord-
day, especially after dawn and before
ing to the list.
sunset.
The DRL system will turn the dedi-
Switch
3
Loading condition
cated lamp OFF when:
position
1. The headlights or front fog lights
Driver only
0
are in the ON position.
Driver + Front passenger
0
2. The position light switch is in the
Full passengers (including driver)
1
ON position.
OPD046035
Full passengers (including driver)
3. The engine is turned off.
2
+ Maximum permissible loading
Manual type
Driver + Maximum permissible
To adjust the headlight beam level
3
loading
according to the number of the pas-
sengers and loading weight in the
luggage area, turn the beam leveling
switch.
The higher the number of the switch
position, the lower the headlight
beam level. Always keep the head-
light beam at the proper leveling
position, or headlights may dazzle
other road users.
3-91
Convenient features of your vehicle
Automatic type
Static bending light
Welcome system (if equipped)
It automatically adjusts the headlight
(if equipped)
Welcome light (if equipped)
beam level according to the number
While driving a corner, for greater
of passengers and loading weight in
visibility and safety, either the left or
the luggage area.
right side static bending light will turn
And it offers proper headlight beam
on automatically. The static bending
under various conditions.
light will turn on when one of the fol-
lowing conditions occur.
WARNING
•
Vehicle speed is less than 10 km/h
(6 mph) and steering wheel angle
If it does not work properly even
is turned approximately 80 degrees
though your car is inclined
with the low beam on.
backward according to passen-
•
Vehicle speed is between 10 km/h
ger's posture, or the headlight
(6 mph) to 90 km/h (56 mph) and
OPDE046051
beam is irradiated to the high or
steering wheel angle is turned
Puddle lamp (if equipped)
low position, we recommend
approximately 35 degrees with the
When all the doors (and tailgate) are
that the system be inspected by
low beam on.
an authorized HYUNDAI dealer.
closed and locked, the puddle lamp
•
When the vehicle is in reverse with
will come on for about 15 seconds if
Do not attempt to inspect or
one of the conditions above satis-
any of the below is performed.
replace the wiring yourself.
fied, the light opposite to the direc-
• When the door unlock button is
tion the steering wheel is steered
pressed on the remote key or
will turn on.
smart key.
• When the button of the outside
door handle is pressed with the
smart key in possession.
3-92
Door handle lamp (if equipped)
Interior lamp
Interior lights
When all the doors (and tailgate) are
When the interior lamp switch is in
NOTICE
closed and locked, the door handle
the DOOR position and all doors (and
lamp will come on for about 15 sec-
tailgate) are closed and locked, the
Do not use the interior lights for
onds if any of the below is performed.
room lamp will come on for 30 sec-
extended periods when the engine
onds if any of the below is performed.
is turned off or the battery will dis-
• When the door unlock button is
charge.
pressed on the remote key or
• When the door unlock button is
smart key.
pressed on the remote key or
3
smart key.
• When the button of the outside
WARNING
door handle is pressed with the
• When the button of the outside
smart key in possession.
door handle is pressed with the
Do not use the interior lights
smart key in possession.
when driving in the dark.The inte-
rior lights may obscure your view
Headlamp and position lamp
At this time, if you press the door lock
and cause an accident.
When the headlamp (lamp switch in
or unlock button, the room lamp will
the headlamp or AUTO position) is on
turn off immediately.
and all doors (and tailgate) are locked
Interior lamp AUTO cut
and closed, the position lamp and
The interior lamps will automatically
headlamp will come on for 15 seconds
go off approximately 20 minutes after
if/or any of the below is performed.
the engine is turned off and the
• When the door unlock button is
doors closed. If a door is opened, the
pressed on the remote key or
lamp will go off 40 minutes after the
smart key.
engine is turned off. If the doors are
At this time, if you press the door lock
locked and the vehicle enters the
or unlock button, the position lamp and
armed stage of the theft alarm sys-
headlamp will turn off immediately.
tem, the lamps will go off five sec-
onds later.
You can activate or deactivate the
Welcome Light from the User
Settings mode on the LCD display.
For more details, refer to "LCD
Display" in this chapter.
3-93
Convenient features of your vehicle
Front lamps
Front map lamp
Front door lamp (
)
Press the map lamp lens (1) to turn
ON the map lamp. Re-press the map
The room lamp for the front/rear
lamp lens to turn OFF the map lamp.
seats is automatically turned ON for
approximately 30 seconds, when a
Front room lamp
door is opened.
The room lamp for the front/rear
•
:
seats is automatically turned ON for
Press the button to turn ON the
approximately 15 seconds, when the
room lamp for the front/rear seats.
remote key (smart key) unlocks the
doors. The room lamp fades out,
when the ignition switch is placed to
•
:
OPDE046041
the ON position in 15 seconds. The
Press the button to turn OFF the
room lamp remains ON up to 20 min-
(1) Front Map Lamp
room lamp for the front/rear seats.
utes, when a door is opened with the
(2) Front Room Lamp
ignition switch in the either the ACC
(3) Front Door Lamp
or OFF position.
3-94
Rear lamps
NOTICE
Luggage room lamp
■ Type A
Do not leave the lamp switches on
for an extended period of time
when the engine is turned off.
3
OAD045407
■ Type B
OPD046042
The luggage room lamp comes on
when the tailgate is opened.
NOTICE
The luggage room lamp comes on
as long as the tailgate lid is open.
To prevent unnecessary charging
system drain, close the tailgate lid
OPD046406
securely after using the tailgate.
Rear room lamp switch :
Press this button to turn the room
lamp on and off.
3-95
Convenient features of your vehicle
Vanity mirror lamp (if equipped)
Puddle lamp (if equipped)
Escort light
When the ignition switch is in the
OFF position and the driver's door is
opened, the puddle lamp will come
on for 30 seconds. If the driver's door
is closed within the 30 seconds, the
puddle lamp will turn off after 15 sec-
onds. If the driver's door is closed
and locked, the puddle lamp will turn
off immediately.
The Puddle Lamp Escort Light will
turn on only the first time the driver's
door is opened after the engine is
OPD046043
OLF044259
turned off.
Push the switch to turn the light on or
Welcome light
off.
When all doors (and tailgate) are
•
: The lamp will turn on if this
closed and locked, the puddle lamp
button is pressed.
will come on for 15 seconds if the
•
: The lamp will turn off if this
door is unlocked by the smart key or
button is pressed.
outside door handle button.
For more details, refer to "Welcome
NOTICE
System" in this chapter.
Always have the switch in the off
position when the vanity mirror
lamp is not in use. If the sunvisor
is closed without the lamp off, it
may discharge the battery or dam-
age the sunvisor.
3-96
WIPERS AND WASHERS
■ Front windshield wiper/washer
■ Rear windshield wiper/washer
• Type A
• Type B
3
A : Wiper speed control (front)
B : Intermittent control wipe time adjust-
D : Rear wiper control*
ment
·
- Single wipe
· 2 - High wiper speed
· O
- Off
· 1 - Low wiper speed
· --- - Intermittent wipe
C : Wash with brief wipes (front)
· O
- Off
AUTO* - Auto control wipe
· 1 - Low wiper speed
E : Wash with brief wipes (rear)
· 2
- High wiper speed
* : if equipped
OPDE046058/OPDE046059/OPDE046060
3-97
Convenient features of your vehicle
Windshield wipers
AUTO (Automatic) control
WARNING
(if equipped)
Operates as follows when the igni-
tion switch is turned ON.
■ Type A
To avoid personal injury from the
: For a single wiping cycle, move
windshield wipers, when the
the lever down and release it.
engine is running and the wind-
The wipers will operate continu-
shield wiper switch is placed in
ously if the lever is held in this
the AUTO mode:
position.
• Do not touch the upper end of
O : Wiper is not in operation
■ Type B
the windshield glass facing the
--- : Wiper operates intermittently at
rain sensor.
the same wiping intervals. Use
• Do not wipe the upper end of
this mode in light rain or mist. To
the windshield glass with a
vary the speed setting, turn the
damp or wet cloth.
speed control knob.
OPDE046061
• Do not put pressure on the
1 : Normal wiper speed
windshield glass.
The rain sensor located on the upper
2 : Fast wiper speed
end of the windshield glass senses
the amount of rainfall and controls
NOTICE
the wiping cycle for the proper inter-
i
Information
val. The more it rains, the faster the
• When washing the vehicle, set the
If there is heavy accumulation of snow
wiper operates.
wiper switch in the O position to
or ice on the windshield, defrost the
stop the auto wiper operation. The
When the rain stops, the wiper stops.
windshield for about 10 minutes, or until
wiper may operate and be damaged
To vary the speed setting, turn the
the snow and/or ice is removed before
if the switch is set in the AUTO
speed control knob (1).
using the windshield wipers to ensure
mode while washing the vehicle.
If the wiper switch is set in AUTO
proper operation.
• Do not remove the sensor cover
mode when the ignition switch is in
If you do not remove the snow and/or ice
located on the upper end of the
the ON position, the wiper will oper-
before using the wiper and washer, it may
passenger side windshield glass.
ate once to perform a self-check of
damage the wiper and washer system.
Damage to system parts could
the system. Set the wiper to OFF
occur and may not be covered by
position when the wiper is not in use.
your vehicle warranty.
3-98
