![]() CONSUMER INFORMATION
8
5
I060A01FC-GAT
I070A01A-AAT
TIRE ROTATION
TIRE BALANCING
!
WARNING:
A tire that is out of balance may affect
o Do not use the temporary spare
handling and tire wear. The tires on
tire for tire rotation.
your Hyundai were balanced before
o Do not mix bias-ply and radial-
the car was delivered but may need
ply tires under any circum-
balancing again during the years you
stances. This may cause dan-
own the car.
gerous handling characteristics.
Whenever a tire is dismounted for
repair, it should be rebalanced before
being reinstalled on the car.
Spare tire
HA1409
Tires should be rotated every 10,000
I080A01A-AAT
km (6,000 miles). If you notice that
TIRE TRACTION
tires are wearing unevenly between
rotations, have the car checked by a
Tire traction can be reduced if you
Hyundai dealer so the cause may be
drive on worn tires, tires that are
corrected.
improperly inflated or on slippery road
After rotating, adjust the tire pres-
surfaces. Tires should be replaced
sures and be sure to check wheel nut
when tread wear indicators appear.
torque.
To reduce the possibility of losing
control, slow down whenever there is
rain, snow or ice on the road.
![]() CONSUMER INFORMATION
8
6
I090A01HP-GAT
WHEN TO REPLACE TIRES
If you nevertheless decide to
!
WARNING:
equip your vehicle with any tire/
1.6 mm (0.06 in.)
o Driving on worn-out tires is dan-
wheel combination not recom-
gerous! Worn-out tires can cause
mended by Hyundai for off-road
loss of braking effectiveness,
driving, you should not use these
steering control and traction.
tires for highway driving.
When replacing tires, never mix
radial and bias-ply tires on the
same car. If you replace radial
Wear indicator
tires with bias-ply tires, they must
be installed in sets of four.
o Your vehicle is equipped with
I090A02FC
tires designed to provide for safe
The original tires on your car have
ride and handling capability.
tread wear indicators. The tread wear
Do not use a size and type of tire
indicators appear when the tread
and wheel that is different from
depth is 1.6 mm (0.06 in.). The tire
the one that is originally installed
should be replaced when these ap-
on your vehicle. It can affect the
pear as a solid bar across two or
safety and performance of your
more grooves of the tread. Always
vehicle, which could lead to han-
replace your tires with those of the
dling failure or rollover and seri-
recommended size. If you change
ous injury.
wheels, the new wheel's rim width
When replacing the tires, be sure
and offset must meet Hyundai speci-
to equip all four tires with the tire
fication.
and wheel of the same size, type,
tread, brand and load-carrying ca-
pacity.
![]() CONSUMER INFORMATION
8
SPARE TIRE AND TOOLS
7
I100A01FC-GAT
D060B01FC
Your Hyundai is delivered with the
following:
Spare tire and wheel
Wheel nut wrench, Wrench bar, Span-
ner, Screw driver
Jack
![]() VEHICLE SPECIFICATIONS
Measurement
9-2
Engine
9-3
Lubrication Chart
9-4
9
9
![]() 9 VEHICLE SPECIFICATIONS
2
J010A01FC-GAT
J030A01FC-GAT
MEASUREMENT
mm (in.)
TIRE
Standard
185/65 R14
Overall length
4,025(158.4)
Option
195/55 R15
Overall width
1,740(68.5)
205/55 R15 (1.8 DOHC only)
Overall height (unladen)
1,635(64.3)
*1,685(66.3)
J030B01FC-GAT
Wheel base
2,600(102.3)
SPARE TIRE
Wheel tread
Front
1,485 (58.5)
Standard
Temporary
Rear
1,485 (58.5)
Option
Full size
*Installed roof rack
J040A03FC-GAT
J020A01FC-GAT
ELECTRICAL
POWER STEERING
Item
GASOLINE
DIESEL
Type
Rack and pinion
Battery
MF45AH, MF60AH(12V)
CMF 68 AH
Wheel free play
0 ~ 30 mm (0 ~ 1.18 in.)
Generator
90A (13.5V)
120A (12V)
Rack stroke
146±1mm (5.7±0.04 in.)
Oil pump type
Vane type
J050A01FC-GAT
BRAKE
J060A01S-GAT
Type
Dual hydraulic with brake booster
FUEL SYSTEM
Front brake type
Ventilated disc
Fuel tank
Liter
US.gal
Imp.gal
Rear brake type
Drum
capacity
55
14.5
12
Parking brake
Cable
![]() VEHICLE SPECIFICATIONS
9
ENGINE
3
J070A04FC-GAT
ITEMS
GASOLINE
DIESEL
Engine Type
1.6/1.8 4Cylinder in-line DOHC
1.5 4Cylinder in-line DOHC
Idle Speed (RPM)
A/CON OFF
800 ± 100 (1.6L), 750 ± 100 (1.8 L)
740 ± 100
A/CON ON
800 ± 100 (1.6L), 800 ± 100 (1.8 L)
Spark Plug
NGK
BKR5ES-11
-
Unleaded
CHAMPION
RC10YC4
-
NGK
BKR5ES
-
Leaded
CHAMPION
RC10YC
-
Spark Plug Gap
Unleaded
1.0 ~ 1.1 mm (0.039 ~ 0.043 in.)
-
Leaded
0.7 ~ 0.8 mm (0.028 ~ 0.032 in.)
-
Valve Clearance
Auto Lash (1.6 DOHC)
Intake
(Cold engine:20 ± 5°C)
0.17 ~ 0.23 mm (0.0067 ~ 0.0091 in.) (1.8DOHC)
For adjusting
Auto Lash
Auto Lash (1.6 DOHC)
Exhaust
0.25 ~ 0.31 mm (0.0098 ~ 0.0122 in.) (1.8 DOHC)
Auto Lash (1.6 DOHC)
Intake
0.12 ~ 0.28 mm (0.0047 ~ 0.011 in.) (1.8 DOHC)
For checking
Auto Lash
Auto Lash (1.6 DOHC)
Exhaust
0.20 ~ 0.38 mm (0.0079 ~ 0.015 in.) (1.8 DOHC)
Ignition Timing
BTDC 5° ± 5° (1.6L), BTDC 7° ± 5° (1.8L)
-
Firing Order
1 - 3 - 4 - 2
1 - 3 - 4 - 2
![]() 9 VEHICLE SPECIFICATIONS
LUBRICATION CHART
4
J080A07FC-GAT
Item
Oil & Grease Standard
Q'ty (liter)
Engine Oil
Gasoline
API SJ, SL
SAE 5W-20, 5W-30
1.6 DOHC - 3.3 (with oil filter)
or ABOVE,
SAE 10W-30 (ABOVE -18°C)
(3.5 us.qts., 2.9 Imp.qts)
ILSAC GF-3
SAE 15W-40 (ABOVE -13°C)
1.8 DOHC - 4.0 (with oil filter)
or ABOVE
SAE 20W-50 (ABOVE -7°C)
(4.2 us.qts., 3.5 Imp.qts)
Diesel
API CH-4
SAE 30 (0°C ~ 40°C)
1.5 CRDi - 5.3 (with oil filter)
or ABOVE,
SAE 20W-40 (ABOVE -10°C)
(5.6 us.qts., 4.7 Imp.qts)
Recommends
ACEA B4
SAE 15W-40 (ABOVE -15°C)
or ABOVE
SAE 10W-30 (-20°C ~ 40°C)
SAE 5W-30 (-25°C ~ 40°C)
SAE 0W-30 (BELOW 10°C) *1, *2
*1. Restricted to driving condition and area
*2. Not recommended for sustained high speed vehicle operation
Engine oil consumption
Normal driving condition
MAX. 1L / 1,500 Km
Severe driving condition
MAX. 1L / 1,000 Km
Transaxle
Manual
2.15 (2.3 us. qts., 1.86 Imp. qts)
HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4)
2.0 (2.11 us. qts., 1.76 Imp. qts) (1.5 CRDi)
Automatic
HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF
6.1 (6.4 us. qts., 5.3 Imp.qts) (1.6 DOHC)
SP III or other brands approved by Hyundai Motor Co.,
6.7 (7.0 us. qts., 5.8 Imp.qts) (1.8 DOHC)
Power steering
PSF-3
As required
Brake fluid
DOT 3, DOT 4 or equivalent
As required
Gasoline : 6.2(1.6 DOHC), 6.5(1.8 DOHC)
Coolant
Ethylene glycol base for aluminum radiator
Diesel : 6.3
![]() INDEX
10
10
10 INDEX
2
A
C
Accessory Tray
1-72
Care of Cassette Tapes
1-132
Air Bag
1-37
Care of Disc
1-131
Air Cleaner Filter
6-15
Cargo Area Cover
1-81
Air Conditioning
Cassette Tape Player Operation (H220, H280)
Care
6-24
.................................................................. 1-108, 1-122
Operation
6-24
Catalytic Converter
7-3
Switch
1-89
CD Auto changer
1-79
Air Conditioner Filter
1-99
CD Auto Changer (H260, H280)
1-116, 1-127
Antenna
1-133
Child-Protector Rear Door Lock
1-9
Ashtray
1-66
Child Restraint System
1-28 ~ 1-34
Audio System
1-102
Cigarette Lighter
1-65
Auto Fuel Cut Switch
1-82
Clutch
Checking fluid
6-23
B
Pedal free play
6-26
Battery
2-21, 6-32
Combination Light
Bleeding The Fuel System
6-33
Headlight flasher
1-60
Brake
Headlight switch
1-59
Anti-lock system
2-13
High-beam switch
1-60
Brake traction control system
2-14
Lane change signal
1-59
Checking the brakes
6-21
Turn signal operation
1-59
Fluid
6-22
Compact Disc Player Operation (H260, H280)
Pedal clearance
6-27
.................................................................. 1-113, 1-124
Pedal free play
6-27
Cooling Fans
6-32
Practices
2-17
Corrosion Protection
Brake Pad Wear Warning Sound
1-53
Cleaning the interior
4-5
Brake Traction Control System
2-14
Protecting your Hyundai from corrosion
4-2
Breaking-In your new Hyundai
1-3
Washing and waxing
4-4
Bulbs Wattage
6-38
INDEX
10
3
D
F
Defrosting/Defogging
1-88
Fog Light
Digital Clock
1-65
Front fog light switch
1-63
Door
Rear fog light switch
1-64
Central door lock
1-9
Fold-up Tray
1-76
Child-protector rear door lock
1-9
Front Seats
Door locks
1-7
Adjustable front seats
1-14
Locking and unlocking front doors with a key
1-7
Lumbar support control
1-16
Drink Holder
1-67
Seat cushion height adjustment
1-16
Drive Belts
6-29
Fuel
Driving
Capacity
9-2
Economical driving
2-18
Gauge
1-54
Smooth cornering
2-19
Recommendations
1-2
Winter driving
2-20
Fuel Filler Lid
Remote release
1-77
E
Fuse Panel Description
6-39
EGR System
7-4
Fuses
6-29
Electronic Stability Program (ESP)
2-16
Emissions Control Systems
7-2
G
Engine
General Checks
6-5
Before starting the engine
2-3
Glove box
1-73
Compartment
6-2 ~ 6-4
Coolant
6-12
H
Coolant temperature gauge
1-54
Hazard Warning System
1-62
If the engine overheats
3-4
Headlight Aiming Adjustment
6-35
Number
8-2
Headlight Bulb
6-37
Oil
6-6
Headlight Leveling Device System
1-64
Starting
2-5
Heating and Cooling Control
1-83
Engine Exhaust Can Be Dangerous
2-2
10 INDEX
4
Heating and Ventilation
L
Air flow control
1-85
Lubrication Chart
9-4
Air intake control
1-87
Luggage Net
1-80
Bi-level heating
1-88
Fan speed control
1-84
M
Heating controls
1-87
Maintenance Intervals
Temperature control
1-84
Explanation of scheduled maintenance items
5-8
High-mounted Rear Stoplight
1-76
Maintenance under severe usage conditions
5-7
Hood Release
1-76
Scheduled maintenance
5-4 ~ 5-6
Horn
1-82
Service requirements
5-2
Mirror
I
Day-night inside rearview
1-75
Ignition Switch
2-3
Outside rearview
1-73
Immobilizer System
1-5
Multi Box
1-72
Instrument Cluster and Indicator
1-44 ~ 1-47
Interior Light
O
Interior light
1-71
Odometer
1-56
Map light
1-71
Outside Rearview Mirror Heater
1-74
Intermittent Wiper
1-62
P
J
Parking Brake
1-68
Jump Starting
3-3
Power Outlet
1-66
Power Steering Fluid Level
6-32
K
Pre-tensioner Seat Belt
1-35
Keys
1-4
If you lose your keys
3-15
Positions
2-4
INDEX
10
5
R
Stereo Radio Operation (H210, H220, H260, H280)
Rear Fog Audible Warning Sound
1-53
............................................ 1-102, 1-105, 1-110, 1-119
Rear Seat
Stereo Sound System
1-99
Adjustable headrests
1-18
Sunroof
1-68
Adjusting seatback angle
1-17
Sunshade
1-68
Adjusting seat forward and rearward
1-17
Sun Visor
1-75
Arm Rest
1-68
Fold down
1-18
T
Rear Window Defroster Switch
1-63
Tail Gate
1-79
Recommended Shift Points
2-8
Tail Gate Wiper And Washer Switch
1-62
Removal of water from the fuel fiter
6-34
Tachometer
1-55
Replacing Light Bulbs
6-36
Theft Alarm System
1-10
Roof Rack
1-81
Tires
Balancing
8-5
S
Chains
8-4
Seat Belts
Changing a flat tire
3-7
2-Point Static Type
1-26
If you have a flat tire
3-7
3-Point system
1-24
Information
8-3
Adjustable height
1-23
Pressure
8-3
Adjusting your seat belt
1-25, 1-26
Replacement
8-6
Care of seat belts
1-23
Rotation
8-5
Precautions
1-21
Snow tires
8-4
Seat Warmer
1-20
Spare tire
3-6
Spectacle Case
1-72
Traction
8-5
Speedometer
1-55
Towing
Starting Procedures
2-5
A trailer (or vehicle)
2-23
Steering Wheel
Emergency
3-14
Free play
6-26
If your car must be towed
3-12
Tilt lever
1-82
10 INDEX
6
Transaxle
Automatic
2-9
Automatic transaxle fluid checking
6-19
Manual
2-7
Manual transaxle oil checking
6-18
Trip Computer
1-57
Trip Odometer
1-56
U
Under Tray
1-17
V
Vehicle Identification Number (VIN)
8-2
Vehicle Specification
9-2
Ventilation
Center ventilator
1-83
Side ventilator
1-83
W
Warning and Indicator Light
1-48
Windows
Manual
1-13
Power
1-13
Windshield Wiper and Washer Switch
1-61
Windshield Wiper Blades
6-16
![]() ![]() Printing : JUN. 15, 2006
Publication No.:A17O-EE66R
Seoul Korea
Printed in Korea
![]() SA010A1-E
OWNER'S MANUAL
Operation
Maintenance
Specifications
HFC001-2D
The information in this Owner's Manual is current at the time of publication. However, the right to amend specifications without
notice or obligation to incorporate such amendments into vehicles already produced is reserved.
This manual applies to all markets and includes descriptions and explanations of optional as well as standard equipment.
As a result, some of the equipment operating descriptions referred to may not apply to the particular vehicle with which this
manual is supplied.
Please refer to the nearest franchised Hyundai authorised repairer for information regarding current standard and optional
equipment levels.
F1
fcuk-0.p65
1
12/27/2006, 10:10 AM
![]() SA020A1-E
Responsibilty For Maintenance
It is the responsibility of the vehicle owner/driver to ensure that all routine mainte-
nance services are undertaken in line with the recommendations specified in Section
5 of this manual. In addition, in order to ensure continued validity of the new vehicle
warranty and safe operation of the vehicle, non scheduled maintenance/running
repairs should be undertaken at the earliest available opportunity.
Under severe operating conditions, more frequent maintenance is required. Details
of the maintenance schedule for such conditions are also given in section 5.
It is recommended that all maintenance operations and repairs are entrusted to a
franchised Hyundai authorised repairer to ensure that the latest repair methods,
specialised tooling and genuine Hyundai parts are used to ensure the continued
reliability and safety of the vehicle.
F2
fcuk-0.p65
2
12/27/2006, 10:10 AM
|
|
|
