Hyundai i30 / Elantra Neos. Body repair manual - part 15

BODY DIMENSIONS

BD-15

Tooling hole                               (ø25)

Subframe mounting bolt

Tooling and paint drain hole
                                                  (ø20)

Subframe mounting pipe         (ø25)

Subframe mounting bolt

Rear suspension mounting hole
                                                 (ø21)

Tooling hole                               (ø25)

Tooling hole                               (ø11)

Cross member mounting hole
                                                  (ø19)

Spring mounting hole                (ø20)

Tooling hole                                  (ø25)

BFDBD6136

BFDBD6136A

BEDBD6503

BFDBD6137

BFDBD6136B

BEDBD6504

BFDBD6138

BFDBD6140

BFDBD6140A

BFDBD6141

A,A'

B,B'

C,C'

D,D'

D,D'

E,E'

F,F'

G,G'

BFDBD6139

H,H'

I,I'

J,J'

BD-16

BODY DIMENSIONS

UNDER BODY (ACTUAL-MEASUREMENT DIMENSIONS)

*  These dimensions indicated in this figure are actual-measurement dimensions.

Point symbol

Length(mm)

Point symbol

Length(mm)

A-C

H-J'

A-E'

C-E'

E-F'

F-G'

F-H'

G-H'

G-J'

1045

1110

1422

1219

1558

1055

1227

1128

1390

BFDBD6501A

A

C

E

F

H

G

J

A'

C'

E'

F'

H'

G'

J'

BODY DIMENSIONS

BD-17

Tooling hole                               (ø25)

Tooling and paint drain hole
                                                  (ø20)

Tooling hole                               (ø25)

Tooling hole                               (ø25)

Rear suspension mounting hole
                                                 (ø21)

Tooling hole                               (ø11)

Cross member mounting hole
                                                  (ø19)

BFDBD6137

BFDBD6136B

BFDBD6140

BFDBD6141

BFDBD6136

A,A'

C,C'

E,E'

BFDBD6138

F,F'

G,G'

BFDBD6139

H,H'

J,J'

BP-2

BODY  PANEL REPAIR PROCEDURE

REPLACING BODY PANELS

CODES FOR REMOVING AND INSTALLING BODY PANELS

BVQBP6001A

Location for cut and assembly

Rough cutting location

20~30 mm

(0.8~1.2 in.)

20~30 mm

(0.8~1.2 in.)
