Operating the Switches Around the Steering Wheel

Light Switches

192

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When you turn the light switch to AUTO, the
headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

The headlights comes on when you unlock a
door in dark areas with the headlight switch in
AUTO.

Once you lock the door, the headlights
will go off.

■

Automatic Operation (automatic lighting control)

Automatic Operation (automatic lighting control)

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Light Sensor

Models without automatic
intermittent wipers

Models with automatic
intermittent wipers

193

Operating the Switches Around the Steering Wheel

Fog Lights

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain number of intervals with the headlight switch in AUTO.
The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF, take the remote with you,
and close the driver’s door.

If you set the power mode to VEHICLE OFF with the headlight switch on, but do not
open the door, the lights turn off after 10 minutes (three minutes, if the switch is in
the AUTO position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

Fog Lights

When the low beam headlights are on, turn
the fog light switch on to use the fog lights.

■

Headlight Integration with Wipers

■

Automatic Lighting Off Feature

Automatic Operation (automatic lighting control)

You can adjust the auto light sensitivity as follows:

2 Customized Features P. 367, 378

Setting

The exterior lights come on

when the ambient light is at

Max

High

Mid

Low

Min

Bright

Dark

Headlight Integration with Wipers

This feature activates while the headlights are off in
AUTO.
The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

You can turn the headlight integration with wipers
function on and off.

2 Customized Features P. 367, 378

Automatic Lighting Off Feature

You can change the headlight auto off timer setting.

2 Customized Features P. 367, 378

Fog Light Switch

* Not available on all models

194

Operating the Switches Around the Steering Wheel

Daytime Running Lights

Co
ntrols

Daytime Running Lights

The parking/daytime running lights come on when the following conditions have
been met:

• The power mode is in ON.
• The headlight switch is off, or in

• The parking brake is released.

The lights remain on even if you set the parking brake. Setting the power mode to
VEHICLE OFF will turn off the daytime running lights.

The daytime running lights are off once the headlight switch is turned on, or when
the head light switch is in AUTO and it is getting darker outside.

Daytime Running Lights

The parking lights serve as daytime running lights.

195

Operating the Switches Around the Steering Wheel

Auto High-Beam

Continued

Co
ntrols

Auto High-Beam

Using a camera mounted to the inside of the windshield, this system detects light
sources ahead of the vehicle. Depending on the light source, the system
automatically switches the headlights to high beam for optimal visibility at night.

Auto High-Beam

The auto high-beam determines when to change the
headlight beams by responding to the brightness of
the lights ahead of your vehicle. In the following
cases, the system may not respond to the lights
properly:

•

The brightness of the lights from the preceding or
oncoming vehicle is intense or poor.

•

Visibility is poor due to the weather (rain, snow,
fog, windshield frost, etc.).

•

Other light sources, such as streetlights and electric
billboards are illuminating the road ahead.

•

The brightness level of the road ahead constantly
changes.

•

The road is bumpy or with many curves.

•

A vehicle cuts in front of you, or a vehicle in front
of you is not in the preceding or oncoming
direction.

•

Your vehicle is tilted with a heavy load in the rear.

If you find the timing of beam changes inconvenient
for driving, change the headlight beams manually.

If you do not want the system to be activated at any
time when the headlight switch is in AUTO, consult a
dealer or disable the system.

2 Disabling or Re-enabling the System P. 197

■

The headlight switch is in AUTO.

■

The lever is in the low beam
position.

■

The low beams are on and the
system recognizes that you are
driving at night.

■

The vehicle speed is above 25 mph
(40 km/h).

The system operates when:

When the camera detects no lights coming from a preceding or oncoming vehicle,
the headlights change to high beam.

The view angle or distance that the camera can detect lights ahead differs
depending on conditions, such as the brightness of the lights and the weather.

How it works

When the camera detects lights coming from a preceding or oncoming vehicle, the
headlights remain in low beam.

Operating the Switches Around the Steering Wheel

Auto High-Beam

196

Co
ntrols

To activate the system, turn the headlight
switch to AUTO and then set the headlights
to low beam. The auto high-beam indicator
will come on.

2 Light Switches P. 191

The high beams remain on unless:
• You have been driving below 15 mph (24 km/h) for an extended amount of time.
• The speed of the vehicle drops below 6 mph (10 km/h).
• The windshield wipers have been running at a high speed for more than a few

seconds.

• You enter a well lit location.

The high beams come back on once the condition that caused them to turn off no
longer exists.

If needed, you can temporarily turn the system off manually. Turn on the high
beams by pushing the lever forward until you hear a click, or flash the high beams
once by pulling the lever toward you. To turn the system back on, pull and hold the
lever toward you for a few seconds.

■

Operating the System

Operating the System

For the auto high-beam to work properly:

•

Do not place an object that reflects light on the
dashboard.

•

Keep the windshield around the camera clean.

•

When cleaning the windshield, be careful not to
apply the windshield cleanser to the camera lens.

•

Do not attach an object or film to the area around
the camera.

•

Do not touch the camera lens.

If the camera receives a strong impact, or repairing of
the area near the camera is required, consult a dealer.

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed toward the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

Headlight Switch

197

Operating the Switches Around the Steering Wheel

Auto High-Beam

Co
ntrols

Disable or re-enable the system when the
vehicle is parked and the power mode is in ON
and the light switch is in the AUTO position.
Disabling the system: Pull the light switch
lever toward you and hold it for at least 40
seconds. The auto high-beam indicator in the
meter will blink twice.
Re-enabling the system: Pull the light
switch lever toward you and hold it for at least
30 seconds. The auto high-beam indicator in
the meter will blink once.

■

Disabling or Re-enabling the System

Disabling or Re-enabling the System

The auto high-beam is in the previously selected
disabled or re-enabled setting each time you turn the
power system on.

AUTO Position

198

Operating the Switches Around the Steering Wheel

Wipers and Washers

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, INT

/AUTO

, LO,

HI)

Move the lever up or down to change the
wiper settings.

■

Adjusting wiper operation

Turn the adjustment ring to adjust the wiper
operation.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

*1: Models with manual intermittent operation
*2: Models with automatic intermittent operation

■

Windshield Wiper/Washer

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle speeds up, the wiper operation’s
shortest delay setting ( ) and the LO setting become
the same.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
the wipers. Use the defroster or heated windshield

to warm the windshield, then turn the wipers on.

Models with intermittent time adjustment ring

Intermittent Time
Adjustment Ring

MIST

INT

/AUTO

OFF

LO: Low speed wipe

HI: High speed wipe

Pull to
use
washer.

Lower speed, fewer sweeps

Higher speed, more sweeps

* Not available on all models

199

Operating the Switches Around the Steering Wheel

Wipers and Washers

Co
ntrols

When you push the lever down to AUTO, the
windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stops in
accordance with the amount of rainfall the
rainfall sensor detects.

■

AUTO sensitivity adjustment

When the wiper function is set to AUTO, you
can adjust the sensitivity of the rain fall sensor
(using the adjustment ring) so that wipers will
operate in accordance with your preference.

Sensor sensitivity

■

Automatic Intermittent Wipers

Wipers and Washers

If the wipers stop operating due to an obstacle such
as the build-up of snow, park the vehicle in a safe
place.
Rotate the wiper switch to OFF, and set the power
mode to ACCESSORY or VEHICLE OFF, then remove
the obstacle.

Automatic Intermittent Wipers

The rainfall sensor is in the location shown below.

NOTICE

AUTO should always be turned OFF before the
following situations in order to prevent severe
damage to the wiper system:

•

Cleaning the windshield

•

Driving through a car wash

•

No rain present

Rainfall Sensor

Adjustment Ring

Low Sensitivity

High Sensitivity

* Not available on all models

200

Operating the Switches Around the Steering Wheel

Rear Defogger/Heated Door Mirror Button

Co
ntrols

Rear Defogger/Heated Door Mirror Button

Press the rear defogger and heated door
mirror button to defog the rear window and
mirrors when the power mode is in ON.

The rear defogger and heated door mirror
automatically switches off after 10-30
minutes depending on the outside
temperature.
However, if the outside temperature is 32°F
(0°C) or below, it does not automatically
switch off.

Heated Windshield Button

Press the heated windshield button to deice
the windshield when the power mode is in
ON.

Rear Defogger/Heated Door Mirror Button

This system consumes a lot of power, so turn it off
when the window has been defogged. Also, do not
use the system for a long time while the power
system is stopped. This may weaken the 12-volt
battery, making it difficult to turn the power system
on.

When the power mode is set to ON and the outside
temperature is below 41°F (5°C), the heated door
mirror may automatically activate for 10 minutes.

Canadian models

Heated Windshield Button

This system consumes a lot of power, so turn it off
when the window has been deiced. Also, do not use
the system for a long period when the power system
is stopped. This may weaken the 12-volt battery,
making it difficult to turn the power system on.

201

Operating the Switches Around the Steering Wheel

Brightness Control

Continued

Co
ntrols

Brightness Control

When the power mode is in ON, you can use
the brightness control dial to adjust
instrument panel brightness.
Brighten: Turn the dial up.
Dim: Turn the dial down.

You will hear a beeper when the brightness
reaches minimum or maximum. Several
seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

■

Brightness level indicator

The brightness level is shown on the driver
information interface while you are adjusting
it.

■

Adjusting the Instrument Panel Brightness

Brightness Control

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

To cancels the reduced instrument panel brightness
when the exterior lights are on, turn the dial up until
the brightness display is up to max, the beeper
sounds.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

Control Dial

202

Operating the Switches Around the Steering Wheel

Brightness Control

Co
ntrols

When the head-up display is on, press and
hold the HUD button until its brightness level
indicator on the driver information interface.
Brighten: Press the

button.

Dim: Press the

button.

Several seconds after you have adjusted the
brightness or press the HUD button, you will
be returned to the previous screen.

■

Brightness level indicator

The brightness level is shown on the driver
information interface while you are adjusting
it.

■

Adjusting the Head-Up Display Brightness

Button

3 4

HUD Button

* Not available on all models

203

Operating the Switches Around the Steering Wheel

Driving Position Memory System

Continued

Co
ntrols

Driving Position Memory System

You can store two driver’s seat (except for power lumbar) with the driving position
memory system.
When you unlock and open the driver’s door with a remote transmitter, or smart
entry system, the seat adjusts to retracted positions of one of the two preset
positions automatically.
The seat will move to the stored position when you set the power mode to
ACCESSORY.

When you enter the vehicle, the driver information interface briefly shows you which
remote transmitter you used to unlock the vehicle.
• DRIVER 1 transmitter is linked to memory button 1.
• DRIVER 2 transmitter is linked to memory button 2.

The driver’s seat moves rearward depending
on the set seating position once you
• Stop the vehicle.
• Put the transmission in

(

• Set the power mode to VEHICLE OFF.
• Then open the driver’s door.
Once the power mode is in the ACCESSORY
position, the driver’s seat moves forward to
the DRIVER 1 or 2 preset position.

Driving Position Memory System

Using the audio/information screen, you can disable
the automatic seat adjustment function.

2 Customized Features P. 378

The driver’s seat easy exit feature can be turned ON/
OFF.

2 Customized Features P. 378

System Operation
The system will not operate if:

•

The vehicle speed is above 2 mph (3 km/h).

•

Either memory position button is pressed while the
seat is in motion.

•

The seat position is adjusted while in operation.

•

The memory 1 or 2 position is set fully to the rear.

DRIVER 1

DRIVER 2

* Not available on all models

Operating the Switches Around the Steering Wheel

Driving Position Memory System

204

Co
ntrols

1. Set the power mode to ON. Adjust the

driver’s seat to the desired position.

2. Press the SET button.

You will hear the beeper, and the
memory button indicator light will blink.

3. Press memory button

(

1 or

(

2 within five

seconds of pressing the SET button.

Once the seat position has been
memorized, you will hear the beeper
twice, and the indicator light on the
button you pressed stays on.

1. Put the transmission into

(

2. Apply the parking brake.
3. Press a memory button (

(

1 or

(

2).

You will hear a beep, and the indicator
light will blink.

The seat will automatically move to the
memorized position. When it has finished
moving, you will hear the beeper twice, and
the indicator light stays on.

■

Storing a Position in Memory

Storing a Position in Memory

After you press the SET button, the storing operation
will be canceled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat position before the double-
beep.

•

You set the power mode to any position except
ON.

Memory
Button 1

Memory
Button 2

SET Button

■

Recalling the Stored Position

Recalling the Stored Position

The seat will stop moving if you:

•

Press the SET button or memory button

(

1 or

(

•

Adjust the seat position.

•

Put the transmission into a position other than

(

Memory Buttons

SET Button

205

Operating the Switches Around the Steering Wheel

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

1. Push the steering wheel adjustment lever

down.

The steering wheel adjustment lever is
under the steering column.

2. Move the steering wheel up or down, and

in or out.

Make sure you can see the instrument
panel gauges and indicators.

3. Pull the steering wheel adjustment lever up

to lock the steering wheel in position.

After adjusting the position, make sure
you have securely locked the steering
wheel in place by trying to move it up,
down, in, and out.

Adjusting the Steering Wheel

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

To adjust

To lock

Lever

206

Co
ntrols

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

Flip the tab to switch the position.
The night position will help to reduce the glare
from headlights behind you when driving
after dark.

When you are driving after dark, the
automatic dimming rearview mirror reduces
the glare from headlights behind you. Press
the auto button to turn this function on and
off. When activated, the auto indicator comes
on.

■

Rearview Mirror with Day and Night Positions

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

2 Front Seats P. 208

Tab

Daytime
Position

Night Position

Down

■

Automatic Dimming Rearview Mirror

Automatic Dimming Rearview Mirror

The auto dimming function cancels when the
transmission is in

(

AUTO button

Down

* Not available on all models

207

Adjusting the Mirrors

Power Door Mirrors

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
power mode is in ON.

■

Mirror position adjustment

L/R selector switch: Select the left or right
mirror. After adjusting the mirror, return the
switch to the center position.
Mirror position adjustment switch: Press
the switch left, right, up, or down to move the
mirror.

If activated, the passenger side door mirror
automatically tilts downward when you put
the transmission into

(

R: this improves close-

in visibility on the passenger side of the vehicle
when backing up. The mirror automatically
returns to its original position when you take
the transmission out of

(

To activate this feature, set the power mode to ON and slide the selector switch to
the passenger’s side.

Selector Switch

Adjustment Switch

■

Reverse Tilt Door Mirror

Selector Switch

* Not available on all models

Honda Accord Hybrid (2019 year). Manual - part 13
