Honda Accord Hybrid (2019 year). Manual

Gauges and Displays

Driver Information Interface

144

strum

nt Pa

nel

2 Driver Information Interface Warning and

Information Messages P. 108

■

Oil Life

Shows the remaining oil life and Maintenance
Minder

2 Maintenance Minder

P. 571

■

Warnings

Warnings

If there are no Warnings, None message appears on
the driver information interface.

(Example)

■

Maintenance

145

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

Shows the current phone information.

2 Bluetooth® HandsFreeLink® P. 424

■

Phone

* Not available on all models

146

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

■

Electric motor

The degree to which the electric motor is
being powered is displayed by the readings on
the POWER side.

■

Battery charge in progress

The degree to which the High Voltage battery
is being charged is displayed by the readings
on the CHARGE side.

■

Speed unit

Enables you to show another speed unit on
the driver information interface and set the
displayed measurements to read in either mph
and km/h.

Press and hold the left selector wheel when
you select Power/Charge on the driver
information interface. Each time you do this,
the unit will change from mph to km/h or vice
versa. After this, a confirmation screen will
appear for a few seconds.

■

POWER/CHARGE Gauge

147

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

Shows the current audio information.

2 Audio System Basic Operation P. 267

Shows the traffic sign recognition system.

2 Traffic Sign Recognition System P. 531

■

Audio

■

Traffic Sign Recognition System

* Not available on all models

Gauges and Displays

Driver Information Interface

148

strum

nt Pa

nel

The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is
being driven in a manner consistent with drowsy or inattentive driving. If it
determines that the vehicle is being driven in such a manner, it will display the
degree of the driver’s attention on the driver information interface.

When you select Driver Attention on the
driver information interface, bars on it light up
in white to indicate the degree of the driver’s
attention.

2 Accessing contents in the main display

P. 135

■

Driver Attention Monitor

Driver Attention Monitor

The Driver Attention Monitor cannot always detect if
the driver is tired or inattentive.
Regardless of the system’s feedback, if you are
feeling tired, stop in a safe location and rest for as
long as needed.

Driver Information
Interface

Left Selector Wheel

(Home) Button

Level

149

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

If two bars light up, the Driver Attention
Level Low message will appear.

If one bar lights up, the Driver Attention
Level Low. Time For A Break message will
appear, a beep will sound, and the steering
wheel will vibrate.
If this message appears, stop in a safe location
and rest for as long as needed.
The message will disappear when the left
selector wheel is pressed or when the system
has determined that the driver is driving
normally.
If the driver does not take a break and the
monitor continues to detect that the driver is
very tired, the message will appear again after
approximately 15 minutes, accompanied by a
beep and steering wheel vibrations.
The message does not appear when the
traveling time is 30 minutes or less.

Gauges and Displays

Driver Information Interface

150

strum

nt Pa

nel

■

The Driver Attention Monitor resets when:

• The power system is turned off.
• The driver unfastens the seat belt and opens the door while the vehicle is stopped.

■

For the Driver Attention Monitor to function:

• The vehicle must be traveling above 25 mph (40 km/h).
• The electric power steering (EPS) system indicator must be off.

■

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances:

• The steering assist function of the Lane Keeping Assist System (LKAS) is active.

2 Lane Keeping Assist System (LKAS) P. 519

• The condition of the road is poor, e.g. the surface is unpaved or bumpy.
• It is windy.
• The driver is frequently operating the vehicle in an assertive manner such as

changing lanes or accelerating.

■

Customizing

You can change the Driver Attention Monitor settings. Select Tactile and Audible
Alert

/Tactile And Audible Alert

, Tactile Alert, or Off

/OFF

2 Customized Features P. 367, 378

*1: Models with color audio
*2: Models with Display Audio

For the Driver Attention Monitor to function:

The bars on the driver information interface remain
grayed out unless the Driver Attention Monitor is
functioning.

Continued

151

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

Shows the distance between your vehicle and
the vehicle detected ahead.
Informs you whether ACC with LSF and/or
LKAS is activated or not. If ACC with LSF is
activated, the set following interval is
displayed. If LKAS is activated, the displayed
lane marks change to indicate that LKAS is
activated.

2 Adaptive Cruise Control (ACC) with Low

Speed Follow (LSF) P. 503

2 Lane Keeping Assist System (LKAS) P. 519

■

Driving Support Information

Driving Support Information

In case ACC with LSF is not activated, when the
distance between your vehicle and the vehicle ahead
becomes to small, the section behind the vehicle icon
turns amber and alerts you.

Amber gradation

Icon of vehicle ahead

Distance of vehicle ahead

When ACC with LSF and LKAS is in On

Set Vehicle Interval

ACC with LSF on: The section
behind the vehicle icon turns
green.
LKAS on: The lane outlines appear
on the display.
LKAS starts: The lane lines change
to solid ones.
LKAS suspend: The lane lines
change to dotted ones.

Gauges and Displays

Driver Information Interface

152

strum

nt Pa

nel

Indicates the state of RDM, CMBS

and Blind spot information System

, such as On,

Off, or Failure, by color and letters.

The following colors indicate the state of any of the above mentioned systems:
• Green: The system is on.
• Gray: The system is off.
• Amber: There is a problem with the system.

■

Safety Support

Safety Support

If a system is indicated by the color amber, have your
vehicle checked by a dealer immediately.

To turn on or off each system, first rotate the left
selector wheel to switch displays. From the next
display you can select which system to turn on or off.

2 RDM On and Off P. 529
2 CMBS

On and Off P. 497

2 Blind spot information system on and off

P. 487

You can also confirm the state of the each function
by the color of the safety support indicator.

2 Safety Support Indicator (Amber) P. 104
2 Safety Support Indicator (Green/Gray)

P. 107

Area Info for CMBS

CMBS

Icon

and State Info

Area Info for
Blind spot
information
System

RDM Icon and
State Info

Area Info for
RDM

Blind spot
information
System Icon
and State Info

* Not available on all models

153

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

Shows the average fuel economy for the last
three driving cycles (1-3), and the current
driving cycle (0) in mpg or l/100 km.

Each time you set the power mode to ON, the
display is updated, and the oldest record is
deleted.

■

Average Fuel Economy Records

Gauges and Displays

Driver Information Interface

154

strum

nt Pa

nel

■

Eco Drive Display

The vehicle icon on the display moves forward or backward while driving.
The more aggressive the acceleration is, the further the icon moves forward.
The more aggressive the deceleration is, the further the icon moves backward.
Keep the icon near the center of the circle for better fuel economy while driving.

■

Eco Drive Display/Drive Cycle Score/Lifetime Points

Eco Drive Display

Switch between the average fuel economy A and
average fuel economy B by rolling the left selector
wheel.

Aggressive
Deceleration

Vehicle Icon

Aggressive
Acceleration

Moderate
Deceleration

Slow
Acceleration/
Deceleration

Moderate
Acceleration

Average Fuel
Economy

155

Gauges and Displays

Driver Information Interface

Continued

strum

nt Pa

nel

■

Drive Cycle Score/Lifetime Points

Appear for a few seconds when you set the power mode to VEHICLE OFF. Each has
three stages. Depending on your driving style, the leaf icon(s) and the gauge
increase or decrease to indicate that you have reached a different stage of fuel
economy.

■

Resetting the Drive Cycle Score

1. Make sure the shift position is in

(

P. Set the power mode to ON.

2. If ECON mode is on, press the ECON button to turn it off.
3. Set the power mode to VEHICLE OFF.
4. Set the power mode to ON again.

Make sure to complete steps from 4 through 6 within 30 seconds.

5. Depress the brake pedal twice.

The color of the ambient meter will change from blue to green.

When the Fuel Efficiency Backlight setting on the audio/information screen
is off, the color stays blue.

6. Press the ECON button twice.

The color of the ambient meter will turn to monochrome.

7. Set the power mode to VEHICLE OFF.

Drive Cycle Score

Lifetime Points

Advancing
to 2nd
Stage

Receding
to 1st
Stage

Advancing
to 3rd
Stage

Receding
to 2nd
Stage

Gauges and Displays

Driver Information Interface

156

strum

nt Pa

nel

Displays the power flow of the motor and engine, indicating the vehicle’s power
source and whether the battery is being charged.

■

Power Flow Monitor

Power Flow Monitor

While the vehicle is stationary with the engine
running, the following may appear on the driver
information interface.

Power is supplied
by the motor and
the engine.

Hybrid (HV)

The engine is running
and the motor is
charging the High
Voltage battery.

Power is being
supplied by only
the engine.

Engine ON

Engine OFF

Power is supplied
by the motor.

Electric Vehicle (EV)

The engine is running
and the motor is
charging the High
Voltage battery.

Engine (Direct Drive)

Power Flow

Engine

The motor is
charging the High
Voltage battery.

Regeneration

157

Gauges and Displays

Head-Up Display

Continued

strum

nt Pa

nel

Head-Up Display

Shows the current mode for ACC with LSF, POWER/CHARGE gauge, traffic sign
recognition system, shift position indicator, or turn-by-turn directions along with the
vehicle speed. You can choose which item to be displayed using the (HUD)
button on the steering wheel. They are displayed when the power mode is in ON.

To turn the head-up display on and off : Press the HUD button on the driver
side control panel.
The display can be moved up and down to come level with your eyes.
To raise or lower the head-up display : Press and hold the

button until

the desired position is reached.

Button

3 4

HUD Button

Head-Up Display

Press and hold the

button

to raise the display.

Press and hold the

button

to lower the display.
