Mercury Sable (2009 year). Instruction

Fuel gauge: Indicates
approximately how much fuel is left
in the fuel tank (when the ignition
is in the on position). The fuel
gauge may vary slightly when the
vehicle is in motion or on a grade.

The FUEL icon and arrow indicates
which side of the vehicle the fuel
filler door is located.

Refer to Filling the tank in the Maintenance and Specifications
chapter for more information.

Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.

Odometer: Registers the total miles
(kilometers) of the vehicle.

Refer to Message center in the
Drivers Controls chapter on how to
switch the display from Metric to
English.

Trip odometer: Registers the miles
(kilometers) of individual journeys.
To reset, press and release the
message center INFO button until
“TRIP” appears in the display (this
represents the trip mode). Press the
control again to select Trip A and
Trip B features. Press and release
the RESET button to reset.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Instrument Cluster

-------------------------------------------------------------------------------------------------------------------------------------------------------------

AUDIO SYSTEMS
Quick start — How to get going

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

drivers use extreme caution when using any device that may take their
focus off the road. The drivers primary responsibility is the safe
operation of their vehicle. Only use cell phones and other devices not
essential to the driving task when it is safe to do so.

Listening to the radio

1. If the audio system is off, press
VOL-PUSH to turn the radio on.
Turn VOL-PUSH to adjust the
volume.

Note: The system may take a few
moments to turn on.

2. Press AM/FM repeatedly to
choose between AM/FM1/FM2
frequency bands.

3. Press

to instructionly go

up/down the frequency band.

Press

SEEK

to search

down/up the chosen frequency band
for the next strongest station.
To disengage SEEK mode,
press

4. Once you are tuned to the
desired station, press and hold a
memory preset (1–6) to save the
station. PRESET SAVED will appear on the display and the sound will
return signifying the station has been saved. You can save up to six
stations in each frequency band — six in AM, six in FM1 and six in FM2.
To access your saved stations, press the corresponding memory preset.
The memory preset # and the station frequency will appear on the
display.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Listening to satellite radio (if equipped)

1. If the audio system is turned off,
press VOL-PUSH to turn the radio
on. Turn VOL-PUSH to adjust the
volume.

Note: The system may take a few
moments to turn on.

2. Press AUX repeatedly to cycle
through auxiliary audio sources.
Select SAT1, SAT2 or SAT3 to listen
to satellite radio.

3. Press

SEEK, SEEK

access the previous or next satellite
channel.

You may also seek by music
category. For further information, refer to CATEGORY listing under the
MENU control on your specific audio system.

4. Once you are tuned to the
desired channel, press and hold a
memory preset (1–6) to save the
channel. PRESET SAVED will appear on the display and the sound will
return signifying the station has been saved. You can save up to six
channels in each — six in SAT1, six in SAT2, and six in SAT3.

To access your saved channels, press the corresponding memory preset.
The memory preset # and the channel name will appear on the display.

Listening to a CD/MP3 (if equipped)

1. If the audio system is turned off,
press VOL-PUSH to turn the radio
on. Turn VOL-PUSH to adjust the
volume.

Note: The system may take a few
moments to turn on.

2. Press CD to enter CD mode. If a
disc is already loaded into the
system, CD play will begin where it
ended last.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

For a single CD system, if a disc
is not already loaded, insert only
one, label side up into the CD slot.
LOADING CD and READING DISC will appear in the display. The first
track on the disc will begin playing.

For an in-dash six CD system, if
a disc is not already loaded, press
LOAD. Select a slot number using
memory presets 1–6. When the
display reads LOAD CD#, load the
desired disc, label side up. If you do not choose a slot within five
seconds, the system will choose for you. Once loaded, the first track will
begin to play.
To auto load up to six discs, press and hold LOAD until the display
reads AUTOLOAD#. Load the desired disc, label side up. The system will
prompt you to load discs for the remaining available slots. Insert the
discs, one at a time, label side up, when prompted. Once loaded, the last
loaded disc will begin to play.

Note: An MP3 disc with folders will show F001 (folder #) T001 (track #)
in the display. An MP3 disc without folders will show T001 (track#) in
the display. Refer to MP3 track and folder structure later in this
chapter for further information.

3. In CD/MP3 mode, you can access the following features:

Press

SEEK, SEEK

access the previous/next tracks.

Press and hold REW to instructionly
reverse in a CD/MP3 track.

Press and hold FF to instructionly
advance in a CD/MP3 track.

While in folder mode, press
FOLDER to access the previous
folder on MP3 discs, if available.

While in folder mode, press
FOLDER

to access the next

folder on MP3 discs, if available.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Press SHUFFLE to engage shuffle
mode. SHUFFLE ON will appear in
the display. If you wish to engage
shuffle mode right away, press SEEK to begin random play. Otherwise,
random play will begin when the current track is finished playing. CD
SHUF will appear in the display.
To disengage, press SHUFFLE again. SHUFFLE OFF will appear in the
display.

Note: In track mode, all tracks on the current disc will shuffle in
random order. In MP3 folder mode, the system will randomly play all
tracks within the current folder.

Press

(play/pause) when a

CD/MP3 is playing to pause the disc.
CD PAUSE will appear in the
display. Press again to resume play.

4. For a single CD system,
press

to eject the current disc.

The display will read CD EJECT.

For an in-dash six CD system,
press

and then select the

correct slot number using memory presets 1–6. When ready, the system
will eject the disc and the display will read REMOVE CD. If the disc is
not removed in 15 seconds, the system will reload the disc.
To auto eject up to six discs, press and hold

until the system

begins ejecting all loaded discs. If the discs are not removed, the system
will reload the discs.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

AM/FM Single CD/MP3 satellite compatible sound system
(if equipped)

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

drivers use extreme caution when using any device that may take their
focus off the road. The driver’s primary responsibility is the safe
operation of their vehicle. Only use cell phones and other devices not
essential to the driving task when it is safe to do so.

Accessory delay: Your vehicle is equipped with accessory delay. With
this feature, the window switches, radio and moon roof (if equipped)
may be used for up to ten minutes after the ignition is turned off or until
either front door is opened.

(Tuner): Press to

instructionly go up or down the radio
frequency. Also use in menu mode
to select various settings.

In satellite radio mode (if equipped), press

to tune to the

next/previous channel.
In CATEGORY mode, press

to scroll through the list of

available SIRIUS channel Categories (Pop, Rock, News, etc.). Refer to

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Category under Menu for further information.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

(Phone): Your vehicle may

be equipped with SYNC which has
special phone features. For more
information, please refer to the SYNC supplement.

3. MENU: Press repeatedly to
access the following settings:

Setting the clock: Press MENU until SET HOURS or SET MINUTES is
displayed. Use

to instructionly increase/decrease. Press MENU again

to disengage clock mode.

If your vehicle is equipped with an in-dash clock, refer to Clock in the
Driver Controls chapter.

SATELLITE RADIO MENU (if equipped): Press MENU when satellite
radio mode is active to access. Press OK to enter into the satellite radio
menu. Press

to cycle through the following options:

• CATEGORY: Press OK to enter category mode. Press

scroll through the list of available SIRIUS channel Categories (Pop,
Rock, News, etc.) Press OK when the desired category appears in the
display. After a category is selected, press SEEK to search for that
specific category of channels only (i.e. ROCK). You may also select
CATEGORY ALL to seek all available SIRIUS categories and channels.
Press OK to close and return to the main menu.

• SAVE SONG: Press OK to save the currently playing song in the

system’s memory. (If you try to save something other than a song,
CANT SAVE will appear in the display.) When the chosen song is
playing on any satellite radio channel, the system will alert you with
an audible prompt. Press OK while SONG ALERT is in the display and
the system will take you to the channel playing the desired song. You
can save up to 20 songs. If you attempt to save a song when the
system is full, the display will read REPLACE SONG? Press OK to
access the saved songs and press

to cycle through the saved

songs. When the song appears in the display that you would like to
replace, press OK. SONG REPLACED will appear in the display.

• DELETE SONG: Press OK to delete a song from the system’s

memory. Press

to cycle through the saved songs. When the

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

song appears in the display that you would like to delete, press OK.
The song will appear in the display for confirmation. Press OK again
and the display will read SONG DELETED. If you do not want to
delete the currently listed song, press

to select either

RETURN or CANCEL.
Note: If there are no songs presently saved, the display will read NO
SONGS.

• DELETE ALL SONGS: Press OK to delete all song’s from the

system’s memory. The display will read ARE YOU SURE ? Press OK to
confirm deletion of all saved songs and the display will read ALL
DELETED.
Note: If there are no songs presently saved, the display will read NO
SONGS.

• ENABLE ALERTS / DISABLE ALERTS: Press OK to enable/disable

the satellite alert status which alerts you when your selected songs are
playing on a satellite radio channel. (The system default is disabled.)
SONG ALERTS ENABLED/DISABLED will appear in the display. The
menu listing will display the opposite state. For example, if you have
chosen to enable the song alerts, the menu listing will read DISABLE
as the alerts are currently on, so your other option is to turn them off.

Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

AUTOSET: Press MENU until the display reads AUTOSET. Autoset
allows you to set the strongest local radio stations without losing your
original instructionly set preset stations for AM/FM1/FM2. Use

turn on/off.
When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.

RBDS: Available only in FM mode. This feature allows you to search
RBDS-equipped stations for a certain category of music format:
CLASSIC, COUNTRY, INFORM, JAZZ/RB, ROCK, etc.
To activate, press MENU repeatedly until RBDS (ON/OFF) appears in
the display. Use

to toggle RBDS ON/OFF. When RBDS is OFF,

you will not be able to search for RBDS equipped stations or view the
station name or type.

To search for specific RBDS music categories: When the desired
category appears in the display, press

to find the desired type,

then press and release

SEEK, SEEK

or press and hold SCAN to

begin the search.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

To view the station name or type: When the desired category appears
in the display, press TEXT/SCAN to toggle between displaying the station
type (COUNTRY, ROCK, etc.) or the station name (WYCD, WXYZ, etc.).

BASS: Press MENU to reach the bass setting. Use

to adjust.

TREB (Treble): Press MENU to reach the treble setting. Use

adjust.

BAL (Balance): Press MENU to reach the balance setting. Use

to adjust the audio between the left (L) and right (R) speakers.

FADE: Press MENU to reach the fade setting. Use

to adjust the

audio between the back (B) and front (F) speakers.

SPEED VOL (Speed sensitive volume, if equipped): Press MENU to
reach the SPEEDVOL setting. Radio volume automatically gets louder
with increasing vehicle speed to compensate for road and wind noise.

Use

to adjust.

The default setting is off; increasing your vehicle speed will not change
the volume level.

Adjust 1–7: Increasing this setting from 1 (lowest setting) to 7 (highest
setting) allows the radio volume to automatically change slightly with
vehicle speed to compensate for road and wind noise.

Recommended level is 1–3; SPEED OFF turns the feature off and level 7
is the maximum setting.

TRACK/FOLDER MODE: Available only on MP3 discs in CD mode.

In track mode, press

SEEK, SEEK

to scroll through all tracks on

the disc
In folder mode, press

SEEK, SEEK

to scroll through tracks

within the selected folder.
Press

FOLDER, FOLDER

to access the previous/next folder (if

available). Press OK to close and return to the main menu.

COMPRESS (Compression): Available only in CD/MP3 mode. Press
MENU until COMPRESS ON/OFF appears in the display. Use

toggle ON/OFF. When COMPRESS is ON, the system will bring the soft
and loud CD passages together for a more consistent listening level.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4. AUX: Press repeatedly to cycle
through LINE IN (auxiliary audio
mode), SAT1, SAT2 and SAT3
(satellite radio, if equipped) and SYNC (if equipped).
For location and further information on auxiliary audio mode, refer to
Auxiliary input jack later in this chapter.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.
If your vehicle is equipped with SYNC, please refer to the SYNC
supplement.
5. SEEK: In radio mode,
press

to access the

previous/next strong station.

In CD mode, press

access the previous/next CD track.

In satellite radio mode (if equipped), press

SEEK, SEEK

seek to the previous/next channel. If a specific category is selected,
(Jazz, Rock, News, etc.), press

SEEK, SEEK

to seek to the

previous/next channel in the selected category. Press and hold
SEEK, SEEK

to fast seek through the previous /next channels.

In TEXT MODE, press

SEEK, SEEK

to view the

previous/additional display text.
In CATEGORY mode, press

SEEK, SEEK

to select a category.

Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

(Play/Pause): When a CD is
playing, press this control to play or
pause the current CD.
OK: Use in various menu selections.
Your vehicle may be equipped with special phone and media features.
For further information, refer to the SYNC supplement.

7. SHUFFLE: Press SHUFFLE to
engage shuffle mode. SHUFFLE ON
will appear in the display. If you
wish to engage shuffle mode right away, press SEEK to begin random
play. Otherwise, random play will begin when the current track is
finished playing. CD SHUF will appear in the display.
To disengage, press SHUFFLE. SHUFFLE OFF will appear in the display.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note: In track mode, all tracks on the current disc will shuffle in
random order. In MP3 folder mode, the system will randomly play all
tracks within the current folder.

8. FOLDER

: In folder mode,

press FOLDER

to access next

folder on MP3 discs, if available.

FOLDER: In folder mode,

press

FOLDER to access the

previous folder on MP3 discs, if
available.

10. FF (Fast forward): Press FF
to instructionly advance in a CD/MP3
track.

11. REW (Rewind): Press REW to
instructionly reverse in a CD/MP3 track.

12. Memory presets: To set a
station, select the desired frequency
band, AM, FM1 or FM2. Tune to the
desired station. Press and hold a preset button until sound returns and
PRESET # SAVED appears in the display. You can save up to 18 stations,
six in AM, six in FM1 and FM2.

In satellite radio mode (if equipped), there are 18 available presets,
six each for SAT1, SAT2 and SAT3. To save satellite channels in your
memory presets, tune to the desired channel then press and hold a
preset control until sound returns.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

13. TEXT/SCAN: In radio and
CD/MP3 mode, press and hold for
a brief sampling of radio stations or
CD tracks. Press again to stop.
In MP3 mode, press and release to display track title, artist name, and
disc title.

In satellite radio mode (if equipped), press and release to enter
TEXT MODE and display the current song title. While in TEXT MODE,
press again to scroll through the current song title, artist, channel
category and the SIRIUS long channel name.
Press and hold to hear a brief sampling of the next channels. Press again
to stop.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In CATEGORY mode, press SCAN to hear a brief sampling of the
channels in the selected category. Press again to stop.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

In TEXT MODE, sometimes the display requires additional text to be
displayed. When the “>” indicator is active, press SEEK

to view the

additional display text. When the “<” indicator is active, press

SEEK

to view the previous display text.

14. AM/FM: Press to select
AM/FM1/FM2 frequency band.

15. ON/OFF/Volume: Press to turn
ON/OFF. Turn to increase/decrease
volume.

Note: If the volume is set above a
certain level and the ignition is
turned off, the volume will come back on at a “nominal” listening level
when the ignition switch is turned back on.

16. CD: Press to enter CD/MP3
mode. If a CD/MP3 is already loaded
into the system, CD/MP3 play will
begin where it ended last. If no CD is loaded, NO DISC will appear in the
display.

17.

(CD eject): Press to eject a

CD.

18. CD slot: Insert a CD label side
up in the CD slot.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Premium/Audiophile AM/FM in-dash six CD/MP3 satellite
compatible sound system (if equipped)

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

(Tune/Disc selector):

In radio mode, press to instructionly
go up (

) or down (

) the

radio frequency. Press and hold for
a fast advance through radio frequencies.
In menu mode, use to select various settings.
In CD/MP3 mode, press to select the desired disc.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In CATEGORY mode (if equipped), press to scroll through the list of
available SIRIUS channel categories.

Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

(Phone): Your vehicle may be

equipped with the SYNC system
which has special phone features.
For further information, refer to the SYNC supplement.

3. MENU: Press repeatedly to
access to the following settings:

Setting the clock: Press until SELECT HOURS or SELECT MINS is
displayed. Press

to adjust the hours/minutes. Press MENU again

to disengage clock mode.

If your vehicle is equipped with an in-dash clock, refer to Clock in the
Driver Controls chapter.

SATELLITE RADIO MENU (if equipped): Press MENU when satellite
radio mode is active to access. Press OK to enter into the satellite radio
menu. Press

to cycle through the following options:

• CATEGORY: Press OK to enter category mode. Press

• SAVE SONG: Press OK to save the currently playing song in the

to cycle through the saved

songs. When the song appears in the display that you would like to
replace, press OK. SONG REPLACED will appear in the display.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

• DELETE SONG: Press OK to delete a song from the system’s

memory. Press

to cycle through the saved songs. When the

song appears in the display that you would like to delete, press OK.
The song will appear in the display for confirmation. Press OK again
and the display will read SONG DELETED. If you do not want to

delete the currently listed song, press

to select either

RETURN or CANCEL.
Note: If there are no songs presently saved, the display will read NO
SONGS.

• DELETE ALL SONGS: Press OK to delete all songs from the

• ENABLE ALERTS / DISABLE ALERTS: Press OK to enable/disable

Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

to toggle RBDS ON/OFF. When RBDS is OFF,

you will not be able to search for RBDS equipped stations or view the
station name or type.

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

To search for specific RBDS music categories: When the desired
category appears in the display, press

to find the desired type,

then press and release

SEEK, SEEK

or press and hold SCAN to

begin the search.

BASS: Press MENU to reach the bass setting. Use

to adjust.

TREB (Treble): Press MENU to reach the treble setting. Use

adjust.

BAL (Balance): Press MENU to reach the balance setting. Use

to adjust the audio between the left (L) and right (R) speakers.

FADE: Press MENU to reach the fade setting. Use

to adjust the

audio between the back (B) and front (F) speakers.

ALL SEATS (Occupancy mode) (Available on Audiophile radios only):
Press MENU repeatedly to access. Press

to optimize sound for

ALL SEATS, DRIVERS SEAT or REAR SEATS.

SPEEDVOL (Speed sensitive volume, if equipped): Press MENU to
reach the SPEEDVOL setting. Radio volume automatically gets louder
with increasing vehicle speed to compensate for road and wind noise.
Use

to adjust.

The default setting is off; increasing your vehicle speed will not change
the volume level.

Recommended level is1–3; SPEED OFF turns the feature off and level 7
is the maximum setting.

Track/Folder Mode: Available only on MP3 discs in CD mode. In Track
Mode, pressing

SEEK

will scroll through all tracks on the disc.

In Folder mode, pressing

SEEK

will scroll only through tracks

within the selected folder.
Press

FOLDER, FOLDER

to access the previous/next folder (if

available).

2009 Sable (mgo)
Owners Guide, 2nd Printing
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Mercury Sable (2009 year). Instruction - part 2
