4R70W Transmission 1. Disconnect the battery ground cable. Raise and support vehicle. Disconnect the Digital Transmission Range (DTR) sensor electrical connector. See Fig. 3 . Do not pry on the swivel tube to disconnect the 2. Loosen the DTR sensor bolts. Manual shift lever must be in the Neutral position. Using the Transmission Range Sensor Alignment Gauge (307-351), align the DTR sensor slots. See Fig. 4 . The tool is designed 3. Install and position the manual control lever. Install a NEW manual lever shaft outer nut and torque to specification. With the manual lever in overdrive connect the shift lever control cable. Install the DTR Fig. 3: Identifying Digital Transmission Range Sensor Components (4R70W) NOTE: When the battery is disconnect and reconnected, some abnormal drive
2003 Ford Pickup F150 2003 STARTING & CHARGING SYSTEMS Starters - F150 Pickup
|
