Fig. 39: Removing Safety Belt Guide Cover
Courtesy of FORD MOTOR CO.

47. Release the tab and open the safety belt guide cover.

48. Remove the safety belt guide nut. Remove the safety belt guide.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup





2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 40: Removing Safety Belt Guide Nut
Courtesy of FORD MOTOR CO.

49. Remove the weatherstripping from the driver side B-pillar.

Fig. 41: Removing Weatherstripping From Driver Side B-Pillar
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



50. Remove the driver side B-pillar assist handle.

1. Remove the caps.

2. Remove the screws.

3. Remove the assist handle.

Fig. 42: Removing Driver Side B-Pillar Assist Handle
Courtesy of FORD MOTOR CO.

51. Pull outward to release the clips. Remove the driver side B-pillar trim panel.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup
