Fig. 11: Heater Core Material Specifications Removal and Installation 1. Drain the radiator. Refer to DRAINING . 2. Remove the instrument panel. Refer to INSTRUMENT PANEL . 3. Disconnect the heater core hose coupling. Refer to CLIMATE CONTROL SYSTEM . NOTE: If a heater core leak is suspected, the heater core must be pressure leak tested
2003 Ford Pickup F150 2003 HVAC Heating And Ventilation - F150 Pickup
|
