1. To deplete the backup power supply energy, disconnect the battery ground cable and wait at least one minute. Be sure to disconnect auxiliary batteries and power supplies (if equipped). Disconnect the battery ground cable and wait at least one minute. Refer to BATTERY DISCONNECT . Vehicles equipped with floor console 2. Remove the floor console. Refer to INSTRUMENT PANEL . All vehicles 3. Remove the floor duct panel. z Remove the pin-type retainers and release the expander clip. Fig. 20: Removing Floor Duct Panel backup power supply must be depleted before repairing or replacing
2003 Ford Pickup F150 2003 HVAC Control Components - F150 Pickup
|
