Fig. 6: Identifying Blower Motor Thermal Limiter The heater blower motor switch resistor has the following features: z The assembly is located on the passenger side of the plenum assembly behind the glove compartment z Three resistance elements are mounted on the resistor board to provide four A/C blower motor speeds. z Depending on the heater blower motor switch position, series resistance is added or bypassed in the A/C
