Fig. 7: Intake Manifold Spacer Tightening Sequence (4.2L) Removal & Installation (4.2L - Lower Intake Manifold) 1. Remove upper intake manifold. See REMOVAL (4.2L - UPPER INTAKE MANIFOLD) . Remove intake manifold spacer. See REMOVAL & INSTALLATION (4.2L - INTAKE MANIFOLD 2. Disconnect by-pass hose and PCV heater hose from lower intake manifold. Remove lower intake manifold bolts, noting position of short and long bolts. See Fig. 11 . Remove lower intake manifold. 3. To install, apply a bead of silicone gasket and sealant to the intake manifold front and rear end seal mounting points. See Fig. 8 . Install lower intake manifold front and rear end seals. Apply a bead of
2003 Ford Pickup F150 2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline
|
