RELEASE .

2. Disconnect the rear high-pressure fuel line from the front high-pressure fuel line.

Fig. 73: Disconnecting Rear High-Pressure Fuel Line From Front High-Pressure Fuel Line
Courtesy of FORD MOTOR CO.

3. Remove the P-clip retaining bolt.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 74: Removing P-Clip Retaining Bolt
Courtesy of FORD MOTOR CO.

4. Remove the rear high-pressure fuel line.

1. Disconnect the rear high-pressure fuel line from the fuel filler valve.

2. Remove the rear high-pressure fuel line.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 75: Removing Rear High-Pressure Fuel Line
Courtesy of FORD MOTOR CO.

Installation

NOTE:

Replace the fuel line O-ring seal.

NOTE:

Lubricate the fuel line O-ring seal with 5W30 engine oil meeting Ford
specification WSS-M2C153-G or equivalent prior to installation, to help
seal and ease the installation.

NOTE:

When tightening the fuel lines, a torque wrench adapter must be used with
the torque wrench. The use of a torque wrench adapter will alter the
effective torque of the torque wrench being used. To correct the effective
torque, a torque multiplication conversion must be used; Refer to
TORQUE MULTIPLICATION CONVERSION .



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup



Fig. 76: Installing Rear High-Pressure Fuel Line
Courtesy of FORD MOTOR CO.
