Citroen C3 (2017 year). Manual

143

Safety

B618_en_Chap05_securite_ed01-2016

"ISOFIX" mountings

Your vehicle has been approved in accordance
with the latest ISOFIX regulation

The seats, represented below, are fitted with
regulation ISOFIX mountings:

- a ring B, located behind the seat and

identified by a marking, referred to as the
Top Tether

for fixing the upper strap.

There are three rings for each seat:

- two rings A, located between the vehicle

seat back and cushion, indicated by a
marking,

To secure the child seat to the TOP TETHER

- remove and stow the head restraint before

installing the child seat on the seat (refit it
once the child seat has been removed),

pass the upper strap of the child seat
behind the seat backrest, between the
apertures for the head restraint rods,

- fix the hook of the upper strap to the ring B,
- tighten the upper strap.
When fitting an ISOFIX child seat to the left-
hand rear seat, before fitting the seat, first
move the centre rear seat belt towards the
middle of the vehicle, so as to avoid the seat
interfering with the operation of the seat belt.

The incorrect installation of a child seat
in a vehicle compromises the child's
protection in the event of an accident.
Follow strictly the fitting instructions
provided by with the child seat.

For information on the possibilities for
installing ISOFIX child seats in your
vehicle, refer to the summary table.

This ISOFIX mounting system provides fast,
reliable and safe fitting of the child seat in your
vehicle.
The ISOFIX child seats are fitted with two
latches which are secured on the two rings A.

Some seats also have an upper strap, known
as the Top Tether, which is attached to ring B.

144

Safety

B618_en_Chap05_securite_ed01-2016

ISOFIX child seats recommended by CITROËN

"RÖMER Baby-Safe Plus" and its

ISOFIX base

(size category: E)

Group 0+: from birth to 13 kg

Installed rearward facing using an ISOFIX
base which is attached to the rings A.
The base has a support leg, adjustable for
height, which sits on the vehicle's floor.
This child seat can also be secured with a
seat belt. In this case, only the shell is used
and attached to the vehicle's seat by the
three-point seat belt.

"RÖMER Duo Plus ISOFIX"

(size category: B1)

Group 1: from 9 to 18 kg

Is installed only in the forward facing
position.
Is attached to the rings A and the upper
ring B, referred to as the TOP TETHER,
using an upper strap.
Three seat body angles: sitting, reclining,
lying down.
This child seat can also be used on seats
not equipped with ISOFIX mountings. In
this case, it must be secured to the vehicle's
seat by the three-point seat belt. Adjust the
position of the vehicle's front seat so that the
child's feet are not touching the backrest.

CITROËN offers a range of ISOFIX child seats listed and type approved for your vehicle.

Refer also to the child seat
manufacturer's fitting instructions for
information on installing and removing
the seat.

145

Safety

B618_en_Chap05_securite_ed01-2016

Locations for ISOFIX child seats

In line with European regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fitted with ISOFIX mountings.
In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A to G, is indicated on the child
seat next to the ISOFIX logo.

Weight of the child

/ indicative age

Under 10 kg

(group 0)

Up to about

6 months

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year

From 9 to 18 kg

(group 1)

From about 1 to 3 years

Type of ISOFIX child seat

Cot

Rearward facing

Forward facing

ISOFIX size category

Seat

Passenger's

front airbag

Row 1 (a)

Passenger's seat

Deactivated

"OFF"

IL-SU

IUF / IL-SU

Activated "ON"

IUF / IL-SU

Row 2

Seat behind
driver's seat

X(1)

IL-SU(3)

IL-SU

IL-SU(3)

IL-SU

IUF / IL-SU

Seat behind
passenger's seat

X(1)

IL-SU(2)

IL-SU

IL-SU(2)

IL-SU

IUF / IL-SU

Centre rear seat

Not ISOFIX

146

Safety

B618_en_Chap05_securite_ed01-2016

(a)

Refer to the legislation in force in your

country before installing a child at this
seating position.

Remove and stow the head restraint
before installing a child seat with a
backrest on a passenger seat. Refit the
head restraint once the child seat has
been removed.

IUF:

seating position suitable for the installation

of an I

sofix Universal seat, Forward facing

secured using the upper strap.

IL-SU:

seating position suitable for the

installation of an I

sofix Semi-Universal

seat either:

- rearward facing fitted with an upper strap

or a support leg,

- forward facing fitted with a support leg,
-

a cot fitted with an upper strap or a support
leg.

For securing the upper strap using the ISOFIX
mountings

, refer to the corresponding section.

seating position not suitable for the

installation for an ISOFIX seat or cot of the
weight group indicated.

(1):

the installation of the cot at this seating

position may prevent the use of one or
more seats in this row.

(2):

adjust the front seat to the fully forward

position.

(3):

adjust the front seat to 16 notches minimum

from the fully rearward position.

147

Safety

B618_en_Chap05_securite_ed01-2016

Locations for i-Size child seats

The i-Size child seats have two latches that engage on the two rings A.
The i-Size child seats also have:
- either an upper strap which is attached to the ring B
- or a support leg which sits on the vehicle's floor, compatible with the seat approved for i-Size
the role of which is to prevent the child seat from tipping forward in the event of a collision.
For more information on ISOFIX mountings, refer to the corresponding section.

In accordance with the new European regulations, this table indicates the options for installing i-Size child seats on seats in the vehicle fitted with
ISOFIX mountings approved for i-Size.

Seating position

Passenger's front airbag

i-Size restraint system

Row 1 (a)

Passenger seat

Deactivated, "OFF"

i-U

Activated, "ON"

i-UF

Row 2

Seat behind the
driver's seat

i-U

Seat behind
the front
passenger's seat

i-U

Centre rear seat

Not i-Size

148

Safety

B618_en_Chap05_securite_ed01-2016

Remove and stow the head restraint
before installing a child seat on a
passenger seat.
Refit the head restraint once the child
seat has been removed.

i-U:

suitable for i-Size restraint systems of

the "Universal" category, forward facing
or rearward facing.

i-UF:

only suitable for i-Size restraint systems

in the "Universal" category, forward
facing.

seating position not suitable for i-Size

restraint systems in the "Universal"
category.

(a)

Refer to the current legislation in your

country before installing a child at this
seating position.

149

Safety

B618_en_Chap05_securite_ed01-2016

Advice

Children at the front

The legislation on carrying children on the
front passenger seat is specific to each
country. Refer to the legislation in force in
your country.
Deactivate the passenger's front airbag
when a rearward facing child seat is installed
on the front passenger seat.
Otherwise, the child risks being seriously
injured or killed if the airbag is deployed.

For optimum installation of the forward facing
child seat, ensure that the back of the child
seat is as close as possible to the backrest
of the vehicle's seat, in contact if possible.
You must remove the head restraint before
installing a child seat with backrest to a
passenger seat.
Ensure that the head restraint is stored or
attached securely to prevent it from being
thrown around the vehicle in the event of
sharp braking. Refit the head restraint when
the child seat is removed.

Installing a booster seat

The chest part of the seat belt must be
positioned on the child's shoulder without
touching the neck.
Ensure that the lap part of the seat belt
passes correctly over the child's thighs.
CITROËN recommends the use of a booster
seat which has a back, fitted with a seat belt
guide at shoulder level.

As a safety precaution, do not leave:
-

a child or children alone and
unsupervised in a vehicle,

- a child or an animal in a vehicle which

is exposed to the sun, with the windows
closed,

- the keys within reach of children inside

the vehicle.

To prevent accidental opening of the doors
and rear windows, use the child lock.
Take care not to open the rear windows by
more than one third.
To protect young children from the rays of
the sun, fit side blinds on the rear windows.

The incorrect installation of a child seat in a
vehicle compromises the child's protection in
the event of an accident.
Ensure that there is no seat belt or seat belt
buckle under the child seat, as this could
destabilise it.
Remember to fasten the seat belts or the
child seat harnesses keeping the slack
relative to the child's body to a minimum,
even for short journeys.
When installing a child seat using the seat
belt, ensure that the seat belt is tightened
correctly on the child seat and that it secures
the child seat firmly on the seat of your
vehicle. If your passenger seat is adjustable,
move it forwards if necessary.
At rear seating positions, always leave
sufficient space between the front seat and:
- a rearward facing child seat,
- the child's feet for a child seat fitted

forward facing.

To do this, move the front seat forwards
and, if necessary, move its backrest into the
upright position.

150

Safety

B618_en_Chap05_securite_ed01-2016

Manual child lock

Turning the child lock on

Using the ignition key or the integral key,

depending on version, turn the red control
as far as it will go:
- to the right on the left-hand rear door,
- to the left on the right-hand rear door.

Turning the child lock off

Using the ignition key or the integral key,

depending on version, turn the red control
as far as it will go:
- to the left on the left-hand rear door,
- to the right on the right-hand rear door.

Mechanical system to prevent opening of a rear door using its interior control.
The control, red in colour, is located on the edge of each rear door.
It is identified by a marking on the bodywork.

Do not confuse the child lock control,
which is red, with the back-up locking
control, which is black.

151

Driving

B618_en_Chap06_conduite_ed01-2016

Driving recommendations

Observe the driving regulations and remain
vigilant whatever the traffic conditions.
Pay close attention to the traffic and keep your
hands on the wheel so that you are ready to
react at any time to any eventuality.
As a safety precaution, the driver must only
carry out actions requiring sustained attention
when the vehicle is stationary.
On a long journey, a break every two hours is
strongly recommended.
In difficult weather, drive smoothly, anticipate
the need to brake and increase the distance
from other vehicles.

Driving on flooded
roads

We strongly advise against driving on flooded
roads, as this could cause serious damage
to the engine or gearbox, as well as to the
electrical systems of your vehicle.

If you are obliged to drive through water:

- check that the depth of water does not

exceed 15 cm, taking account of waves
that might be generated by other users,

- deactivate the Stop & Start system,
-

drive as slowly as possible without
stalling. In all cases, do not exceed 6 mph
(10 km/h),

do not stop and do not switch off the
engine.

On leaving the flooded road, as soon as
circumstances allow, make several light brake
applications to dry the brake discs and pads.
If in doubt on the state of your vehicle, contact
a CITROËN dealer or a qualified workshop.

Important!

Never drive with the parking brake
applied - Risk of overheating and
damage to the braking system!
Risk of fire!
As the exhaust system of your vehicle
is very hot, even several minutes after
switching off the engine, do not park
or leave the engine running over areas
where inflammable substances and
materials are present: grass, leaves,
etc.

Never leave a vehicle unsupervised
with the engine running. If you have
to leave your vehicle with the engine
running, apply the parking brake
and put the gearbox into neutral or
position N or P

, depending on the type

of gearbox.

152

Driving

B618_en_Chap06_conduite_ed01-2016

When towing

Distribution of loads

F Distribute the load in the trailer so that the

heaviest items are as close as possible to
the axle and the nose weight approaches
the maximum permitted without
exceeding it.

Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load must
be reduced by 10 % for every 1 000 metres of
altitude.
For more information on Weights, refer to the
corresponding section.

Side wind

Take into account the increased sensitivity

to side wind.

Cooling

Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its cooling
capacity is not dependent on the engine speed.
F

To lower the engine speed, reduce your

speed.

The maximum towed load on a long incline
depends on the gradient and the exterior
temperature.
In all cases, keep a check on the coolant
temperature.

If the warning lamp and the

STOP

warning lamp come on,

stop the vehicle and switch off
the engine as soon as possible.

Braking

Towing a trailer increases the braking distance.
To avoid overheating of the brakes, the use of
engine braking is recommended.

Tyres

Check the tyre pressures of the towing

vehicle and of the trailer, observing the
recommended pressures.

Lighting

Check the electrical lighting and signalling

on the trailer and the headlamp beam
height of your vehicle.

For more information on Adjusting the
headlamp beam height, refer to the
corresponding section.

The rear parking sensors will be
deactivated automatically to avoid the
audible signal if a genuine CITROËN
towbar is used.

If the exterior temperature is high, it
is recommended that the engine be
allowed to idle for 1 to 2 minutes after
the vehicle comes to a stop, to facilitate
its cooling.

153

Driving

B618_en_Chap06_conduite_ed01-2016

Anti-theft protection

Electronic engine immobiliser

The keys contain an electronic chip which has
a secret code. When the ignition is switched
on, this code must be recognised in order for
starting to be possible.
This electronic engine immobiliser locks the
engine management system a few minutes
after the ignition is switched off and prevents
starting of the engine by anyone who does not
have the key.

For reasons of safety and theft protection,
do not leave your electronic key in the
vehicle, even when you are close to it.
It is recommended that you keep it on
your person.

In the event of a malfunction, you are informed
by a message in the instrument panel screen.

In this case, your vehicle does not start; contact
a CITROËN dealer if required.

Starting / Switching off the engine with the key

It has 3 positions:
- position

1 (Stop)

: insert and removing the

key, steering column locked,

- position

2 (Ignition on)

: steering column

unlocked, ignition on, Diesel preheating,
engine running,

- position

3 (Starting)

Ignition switch

Switching off the engine leads to a loss
of braking assistance.

Ignition on position

It allows the use of the vehicle's electric
equipment or portable devices to be charged.
Once the state of charge of the battery drops
to the reserve level, the system switches to
energy economy mode: the power supply is
cut off automatically to preserve the remaining
battery charge.

Avoid attaching heavy objects to the
key or the remote control, which would
weigh down on its blade in the ignition
switch and could cause a malfunction.
It could adversely affect the deployment
of the front airbag.

154

Driving

B618_en_Chap06_conduite_ed01-2016

With a Diesel engine, turn the key to

position 2

, ignition on, to operate the

engine pre-heating system.

Wait until this warning lamp goes off in the
instrument panel then operate the starter
motor by turning the key to position 3
without pressing the accelerator pedal,
until the engine starts. Once the engine is
running, release the key.

In wintry conditions, the warning lamp
can stay on for a longer period. When
the engine is hot, the warning lamp
does not come on.

In temperate conditions, do not leave
the engine at idle to warm up but move
off straight away and drive at moderate
speed.

Never leave the engine running in
an enclosed area without adequate
ventilation: internal combustion
engines emit toxic exhaust gases,
such as carbon monoxide. Danger of
intoxication and death!
In very severe wintry conditions
(temperatures below -23°C), to ensure
the correct operation and durability of
the mechanical components of your
vehicle, engine and gearbox, it is
necessary to leave the engine running
for 4 minutes before moving off.

If the engine does not start straight
away, switch off the ignition. Wait a
few moments before operating the
starter motor again. If the engine does
not start after several attempts, do not
keep trying: you risk damaging the
starter motor or the engine. Contact
a CITROËN dealer or a qualified
workshop.

Starting the engine

With the parking brake applied and the gearbox
in neutral or position N or P

depress the clutch pedal fully (manual

gearbox),

or
F

press the brake pedal firmly (automatic

gearbox),

insert the key into the ignition switch; the

system recognises the code,

unlock the steering column by simultaneously

turning the steering and the key.

In certain cases, you may have to apply
more force to the steering (wheels on
full lock, for example).

With a petrol engine, operate the starter

motor by turning the key to position 3
without pressing the accelerator pedal,
until the engine starts. Once the engine is
running, release the key.

155

Driving

B618_en_Chap06_conduite_ed01-2016

Key left in the "Ignition on"
position

If the key has been left in the ignition
switch at position 2 (Ignition on),
the ignition will be switched off
automatically after one hour.
To switch the ignition back on, turn the
key to position 1 (Stop), then back to
position 2 (Ignition on)

Never switch off the ignition before the
vehicle is at a complete stop. With the
engine off, the braking and steering
assistance systems are also cut off: risk
of loss of control of the vehicle.

When you leave the vehicle, keep the
key with you and lock the vehicle.

To facilitate unlocking of the steering
column, it is recommended that the
wheels be returned to the straight ahead
position before switching off the engine.

Switching off the engine

Stop the vehicle.

With the engine running at idle, turn the key

to position 1

Remove the key from the ignition switch.

To lock the steering column, turn the

steering until it locks.

Check that the parking brake is correctly

applied, particularly on sloping ground.

For more information on Energy
economy mode, refer to the
corresponding section.

Energy economy mode

After switching off the engine (position 1-Stop),
for a maximum of 30 minutes you can still use
functions such as the audio and telematic
system, the wipers, dipped beam headlamps,
courtesy lamps, ...

156

Driving

B618_en_Chap06_conduite_ed01-2016

Starting / Switching off the engine with Keyless Entry and

Starting

Starting the engine

F With a manual gearbox,

put the gear lever

into neutral.

With the electronic key inside the vehicle,

fully depress the clutch pedal.

or
F With an automatic gearbox, place the

gear selector at position P or N.

With the electronic key inside the vehicle,

fully depress the brake pedal.

If one of the starting conditions is not met,
a reminder message is displayed in the
instrument panel.
In some circumstances, it is necessary
to turn the steering wheel slightly while
pressing the "START/STOP" button to
assist unlocking of the steering column; a
message warns you when this is needed.

The presence of the "Keyless Entry
and Starting" electronic key in the
recognition zone is essential.
If the electronic key is not detected in
this zone, a message is displayed.
Move the electronic key into this zone
so that the engine can be started.
If there is still a problem, refer to the
"Key not detected - Back-up starting"
section.

F Briefly press the "START/

STOP

" button while maintaining

pressure on the pedal until the
engine starts.

The steering column unlocks and the engine
starts.

For Diesel engines

, in temperatures below

zero and/or with a cold engine, the engine will
not start until the pre-heater warning lamp has
gone off.

If this warning lamp comes on after
pressing the "START/STOP" button:

F With a manual gearbox, you should

keep the clutch pedal fully depressed until
the warning lamp goes off and not press
the "START/STOP

" button again until the

engine is running.

or
F With an automatic gearbox, you should

keep the brake pedal fully depressed until
the warning lamp goes off and not press
the "START/STOP

" button again until the

engine is running.

As a safety measure, never leave the
vehicle while the engine is running.

157

Driving

B618_en_Chap06_conduite_ed01-2016

Switching off the engine

Immobilise the vehicle, engine at idle.

F With a manual gearbox

, put the gear lever

into neutral.

or
F With an automatic gearbox, place the

gear selector at position P or N.

With the electronic key inside

the vehicle, press the "START/
STOP

" button.

The engine stops and the steering column
locks.

Never leave your vehicle with the
electronic key still inside.

If the vehicle is not immobilised, the
engine will not stop.

Switching off the engine leads to a loss
of braking assistance.

Ignition on
(without starting)

With the Keyless Entry and Starting remote
control inside the vehicle, pressing the "START/
STOP" button, with no action on the pedals,
allows the ignition to be switched on.
This also allows the accessories to be used
(for example: audio system, lighting...).

Press the "START/STOP" button,

the instrument panel comes on
but the engine does not start.

Press the button again to switch off the

ignition and allow the vehicle to be locked.

With the ignition on, the system
automatically goes into energy
economy mode to maintain an adequate
state of charge in the battery.

158

Driving

B618_en_Chap06_conduite_ed01-2016

Key not detected

Back-up starting

A back-up reader is fitted to the steering
column to allow the engine to be started if
the system does not detect the key in the
recognition zone, or when the battery in the
electronic key is discharged.
F

Place and hold the remote control against

the reader.

F Press the "START/STOP

" button.

The engine starts.

Back-up switch off

When the electronic key is not detected or is
no longer in the recognition zone, a message
appears in the instrument panel when closing a
door or trying to switch off the engine.

Emergency switch-off

In the event of an emergency only, the engine
can be switched off without conditions (even
when driving).
Press the "START/STOP" button for about five
seconds.
In this case, the steering column locks as soon
as the vehicle stops.

To confirm the instruction to switch off the

engine, press the "START/STOP" button
for about five seconds.

In the event of a fault with the electronic key,
contact a CITROËN dealer or a qualified
workshop.

If your vehicle has a manual gearbox, place

the gear lever in neutral then fully depress
the clutch pedal.

If your vehicle has an automatic gearbox,

select position P

then press the brake

pedal firmly.

Citroen C3 (2017 year). Manual - part 10
