Citroen C3 (2017 year). Manual - part 4

Instruments

B618_en_Chap01_Instruments-de-bord_ed01-2016

Driving functions tab

Corresponding function

Comments

Stop & Start

Activation/deactivation of the function.

Parking sensors

Activation/deactivation of the function.

Traction control

Activation/deactivation of the function

Blind spot sensors

Activation/deactivation of the function.

Under-inflation initialisation

Reinitialisation of the under-inflation detection system.

Adjusting Speeds

Memorisation of speed settings for the speed limiter or the cruise control.

Diagnostic

List of current alerts.

For more information on one of these functions, refer to the corresponding section.

Instruments

Button

Comments

Turn off the screen.

Adjustment of brightness.

Choice and settings for three profiles.

Settings for the touch screen.

Activation and adjustment of Wi-Fi settings.

Configuration

The functions available through this menu are detailed in the table below. Certain adjustments are accessible in the secondary page.

Instruments

B618_en_Chap01_Instruments-de-bord_ed01-2016

Button

Comments

Adjustment of the display settings (scrolling of text, animations, etc.) and brightness.

Choice of units:
- temperature (°Celsius or °Fahrenheit)
- distance and fuel consumption (l/100 km, mpg or km/l).

Choice of language used for the touch screen.

Setting the date and time.

Instruments

Trip computer

System that gives you information on the current journey (range, fuel consumption…).

Display of information

These are displayed in turn:
-  Trip distance.
-  Range.
-  Current consumption.
-  Average speed.
-  Stop & Start time counter.
-  Speed limit recognition information.

F Press the button on the end of the wiper

control stalk

Press the thumbwheel on the steering

wheel.

Instruments

B618_en_Chap01_Instruments-de-bord_ed01-2016

Trip reset

F Press the button on the end of the wiper

control stalk

for more than two seconds.

Press the thumbwheel on the steering

wheel for more than two seconds.

Press this button for more than

two seconds.

The reset is carried out when the trip is displayed.

Instruments

A few definitions…

Range

(miles or km)

This value may vary following a change
in the style of driving or the relief,
resulting in a significant change in the
current fuel consumption.

When the range falls below 20 miles (30 km),
dashes are displayed.
After filling with at least 5 litres of fuel, the
range is recalculated and is displayed if it
exceeds 60 miles (100 km).

This function is only displayed from
20 mph (30 km/h).

Current fuel
consumption

(mpg or l/100 km or km/l)

Distance travelled

(miles or km)

Stop & Start time counter
(minutes / seconds or hours /
minutes)

A time counter calculates the time spent in
STOP mode during a journey.
It resets to zero every time the ignition is
switched on.

Average fuel consumption

(mpg or l/100 km or km/l)

Calculated since the last trip computer reset.

If dashes are displayed continuously
while driving in place of the digits,
contact a CITROËN dealer or a
qualified workshop.

The distance which can still be travelled with
the fuel remaining in the tank (at the average
fuel consumption seen over the last few miles
(kilometres) travelled).

Calculated over the last few seconds.

Average speed

(mph or km/h)

Calculated since the last trip computer reset.

Instruments

B618_en_Chap01_Instruments-de-bord_ed01-2016

Lighting dimmer control

Two buttons

With the exterior lighting on, press button A
to increase the brightness of the instruments
and controls and the interior mood lighting or
button B

to reduce it.

As soon as the lighting reaches the required
level of brightness, release the button.

Touch screen

F In the Configuration

menu, select

"Brightness

Adjust the brightness using the arrows or

by moving the cursor.

Allows the manual adjustment of the brightness of the instrument panel and touch screen to suit the
ambient light level.
Operates only when the vehicle lighting is on, with the exception of the daytime running lamps.

Instruments

Setting the date and time

With audio system

Without audio system

F Press the MENU button for access to the

main menu.

F Press the "7" or "8" button to select the

"Personalisation-configuration" menu, then
the "OK"

button.

F Press the "5" or "6" button to select the

"Display configuration" menu, then the
"OK"

button.

F Press the "5" or "6" button to select the

"Date and time adjustment" line, then the
"OK"

button.

F Press the "7" or "8" button to select the

setting to change. Confirm by pressing the
"OK"

button.

Adjust the settings one by one, confirming

by pressing the "OK" button.

F Press the "5" or "6" button, then the "OK"

button to select the "OK"

box and confirm

or press the "Back"

button to cancel.

With CITROËN Connect
Radio

F Select the Settings

menu.

F Select "System configuration

You can set the date and time from the
instrument panel display.

F Select "Date" or "Time

Choose the display formats.

Change the date and/or the time using the

numeric keypad.

F Select "Date and time

Press this button to confirm.

Press and hold this button.

F Press this button briefly to

confirm.

F Press one of these buttons to

select the setting to change.

F Press one of these buttons to

change the setting and confirm
again to save the change.

Instruments

B618_en_Chap01_Instruments-de-bord_ed01-2016

F Select the Settings

menu.

F Press the "OPTIONS

" button to go to the

secondary page.

The system does not automatically
manage the change between winter and
summer time (depending on country).
The change between winter and
summer time is done by changing the
time zone.

F Select the "Date" or "Time

" tab.

Set the time or the date using the numeric

keypad.

F Select "Setting the time-date

Press this button to confirm.

With CITROËN Connect Nav

The date and time settings are only available
if the synchronisation with the GPS is
deactivated.

Additional settings

You can choose to:
- change the date and time display format

(12hr / 24hr),

- change the time zone,
-

activate or deactivate the synchronisation
with the GPS (UTC).

Access

B618_en_Chap02_ouvertures_ed01-2016

General points

Remote control

The remote control can be used for the
following functions, depending on version:
- unlocking / locking / deadlocking of the

vehicle,

-  opening of the fuel tank cap,
-  remote switching on of the lighting,
-  activation / deactivation of the alarm,
-  locating the vehicle,
-  vehicle immobiliser.
In normal operating conditions, it is preferable
to use the remote control.

The key, integral with the remote control, can
be used for the following functions, depending
on version:
- unlocking / locking / deadlocking of the

vehicle,

- turning the child lock on or off,
- activation / deactivation of the passenger's

front airbag,

- back-up door locking,
- switching on the ignition and starting /

stopping the engine.

Back-up procedures allow the vehicle to be
locked or unlocked in the event of a failure of
the remote control, the central locking, the
battery...
For more information on the Back-up
procedures

, refer to the corresponding

section.

Ejecting the key

Version with Keyless Entry and Starting
F

Pull on this button to remove the key from

the housing.

To return it to the housing, first pull on this
button.

Version without Keyless Entry and Starting
F

Press this button; the key is ejected from its

housing.

To avoid damaging the mechanism, first press
this button to fold it.

Access

B618_en_Chap02_ouvertures_ed01-2016

If one of the doors or the boot is not
fully closed, the locking does not take
place. However, if your vehicle has an
alarm, this will be fully activated after
about 45 seconds.
If the vehicle is unlocked inadvertently
and there is then no action on the doors
or boot, the vehicle will automatically
lock itself again after about 30 seconds.
If the alarm had been previously
activated, it will be reactivated
automatically.

Press the open padlock to unlock

the vehicle.

Unlocking the vehicle

When the unlocking button is pressed, the
flashing of the direction indicators for a
few seconds signals:
- unlocking of the vehicle for versions

without an alarm,

- deactivation of the alarm for other versions.

Normal locking

Deadlocking

Press this button.

Make a first press on this button.

F Within five seconds, press this

button again to deadlock the
vehicle.

When the locking button is pressed,
illumination of the direction indicators for a few
seconds signals:
- locking of the vehicle for versions without

an alarm,

- activation of the alarm for other versions.

For versions without alarm, deadlocking is
confirmed by illumination of the direction
indicators for few seconds on the second press
of the locking button.

Locking the vehicle

Deadlocking renders the interior door
controls inoperative.
It also deactivates the interior central
locking button on the dashboard.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

Access

B618_en_Chap02_ouvertures_ed01-2016

Locating your vehicle

This function allows you to identify your vehicle
from a distance, especially when the light is
poor.

Press this button.

The sidelamps and the dipped headlamps
come on for 30 seconds.
Pressing the button again before the end of this
period switches the lamps off immediately.

Access

B618_en_Chap02_ouvertures_ed01-2016

Keyless Entry and Starting

System that allows the unlocking, locking
and starting of the vehicle while keeping the
electronic key on your person.

The electronic key can also be used as
a remote control.
For more information on the Remote
Control

, refer to the corresponding

section.

Unlocking the vehicle

With the electronic key on your person and

in the recognition zone A, pass your hand
behind the door handle of one of the front
doors to unlock the vehicle or press the
tailgate opening control.

The flashing of the direction indicators
for a few seconds signals:
- unlocking of the vehicle for versions

without an alarm,

- deactivation of the alarm for other

versions.

Access

B618_en_Chap02_ouvertures_ed01-2016

As a safety measure (children on
board), never leave the vehicle without
taking the electronic key for the Keyless
Entry and Starting system with you,
even for a short period.
Be aware of the risk of theft when the
electronic key for the Keyless Entry and
Starting system is in one of the defined
zones with the vehicle unlocked.

If one of the doors or the boot is still
open or if the electronic key for the
Keyless Entry and Starting system has
been left inside the vehicle, the central
locking does not take place.
However, the alarm (if fitted) will be fully
activated after about 45 seconds.

If the vehicle is unlocked by mistake
and with no action on the doors or boot,
the vehicle will lock again automatically
after about 30 seconds.
If fitted to your vehicle, the alarm will
also be reactivated automatically.

In order to preserve the battery in the
electronic key and the vehicle's battery,
the "hands-free" functions are put into
long-term standby after 21 days without
use. To restore these functions, press
one of the remote control buttons or
start the engine with the electronic key
in the reader.
For more information on Starting with
Keyless Entry and Starting, refer to
the corresponding section.

Access

B618_en_Chap02_ouvertures_ed01-2016

Locking the vehicle

Normal locking

With the electronic key in the recognition

zone A

, press with a finger or thumb

on one of the front door handles (at the
markings) to lock the vehicle.

It is not possible to lock the vehicle if one of the
keys is left inside the vehicle.

The lighting of the direction indicators
for a few seconds signals:
- locking of the vehicle for versions

without an alarm,

- activation of the alarm for other

versions.

For reasons of safety and theft protection,
do not leave your electronic key in the
vehicle, even when you are close to it.
It is recommended that you keep it on
your person.

Accumulations (water, dust, grime,
salt...) on the inner surface of the door
handle may affect detection.
If cleaning the inner surface of the door
handle using a cloth does not restore
detection, contact a CITROËN dealer or
a qualified workshop.
A sudden splash of water (stream of
water, high pressure jet washer, …)
may be identified by the system as the
desire to open the vehicle.

Access

B618_en_Chap02_ouvertures_ed01-2016

Deadlocking renders the interior door
controls inoperative.
It also deactivates the central locking
button on the dashboard.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

Deadlocking

With the electronic key in the recognition

zone A

, press a finger or thumb on one of

the front door handles (at the markings) to
lock the vehicle.

F Within five seconds, press the front door

handle again to deadlock the vehicle.

Content .. 2 3 4 5 ..
