Fig. 500: Identifying Selective Spacer Dimension B - 4WD 3. At dimension B, measure the distance from the rear face of the low and reverse clutch housing (3) to the rear face of the retaining ring (4). 4. Calculate Dimension C by subtracting Dimension B from Dimension A. 5. Select the appropriate selective spacer (1) based upon Dimension C. Refer to Selective Components Specifications . 6. Install the selective spacer (1) onto the output shaft (2). TRANSMISSION END PLAY MEASUREMENT
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
