34. Install the solenoid O-ring (6) onto the TCC PCS (7). 35. Install the solenoid O-ring (5) onto the TCC PCS (7). 36. Install the TCC PCS spring (3). 37. Install the TCC PCS valve (4) 38. Align the TCC PCS (7) so that the electrical connection faces up. 39. Install the TCC PCS. Seat the solenoid. 40. Align the PCS retaining bracket (2) with the main valve body locating pin. 41. Install the PCS retaining bracket (2) so that the TCC PCS is against the valve body. 42. Install the bolt (1) retaining the PCS retaining bracket (2). Tighten: Tighten the bolt to 12 N.m (108 lb in).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
