10. Install the thrust washer (5) onto the oil pump cover assembly. The thrust washer snaps into place. 11. Install 3 new overlap seal rings (6) onto the oil pump cover assembly rear hub. 12. Install a new overlap seal ring (2) onto the middle of the stator shaft (3). 13. Install a new overlap seal ring (1) onto the front of the stator shaft (3).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
