1-2-3-4 Clutch Piston Installation 1-2-3-4 CLUTCH PLATE INSTALLATION Callout Component Name 1 1-2-3-4 Clutch Piston 2 1-2-3-4 Clutch Spring NOTE: Ensure the clutch spring is centered on the piston 3 1-2-3-4 Clutch Piston Dam Assembly 4 1-2-3-4 Clutch Piston Dam Retaining Ring NOTE: Use care when compressing the 1-2-3-4 clutch NOTE: Refer to Retaining Ring Reuse Notice .
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
