Fig. 98: Routing Wires To Apply Power For Controlled Bag Deployment (Right ) 30. Route the deployment harness out of the passenger's side of the vehicle. 31. Completely cover the windshield and the front door openings with a drop cloth. 32. Deploy each deployment loop one at a time. 33. Stretch out all of the deployment harness wires on the left and right side of the vehicle to their full length. 34. Place a power source, 12 volt minimum/2 amp minimum, such as a vehicle battery, near the shorted end of the harnesses. 35. Separate one set of wires and touch the wire ends to the power source in order to deploy the seat belt pretensioners. 36. Disconnect the deployment harness from the power source and twist the wire ends together. 37. Continue the same process with the remaining deployment harnesses that are available. 38. Remove the drop cloth from the vehicle. 39. Disconnect all harnesses from the vehicle. 40. Discard the harnesses. 41. Scrap the vehicle in the same manner as a non-SIR equipped vehicle. 42. If one or more of the seat belt pretensioners did not deploy, perform the following steps to remove the undeployed seat belt pretensioner from the vehicle, refer to Seat Belt
2008 Chevrolet Silverado 1500 2008 RESTRAINTS Supplemental Inflatable Restraints - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
