INFLATABLE RESTRAINT INSTRUMENT PANEL MODULE DISABLE SWITCH REPLA Presence System Rezeroing. 1 Front Seat Recliner Lever (If Equipped) 2 Front Seat Adjuster Outer Finish Cover 3 Front Seat Adjuster Inner Finish Cover 4 Front Seat Cushion Cover and Pad 1. Disengage the j-channel retainers from the seat cushion frame. 2. Remove the seat cushion cover and pad from the seat cushion frame as an assembly. 5 Inflatable Restraint Front Passenger Presence Sensor Retainer (Qty: 2) 6 Inflatable Restraint Front Passenger Presence Sensor 1. Lay the seat on it's side. 2. Unhook connector from retainer on seat frame and push up through seat pan. 3. Disconnect and remove sensor. 7 Front Seat Adjuster Assembly 8 Inflatable Restraint Front Passenger Presence Module Rivets (Qty: 2) 9 Inflatable Restraint Front Passenger Presence Module
2008 Chevrolet Silverado 1500 2008 RESTRAINTS Supplemental Inflatable Restraints - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
