4. Remove the O-ring (421) from the tube, as required. EXHAUST MANIFOLD REMOVAL - LEFT SIDE Fig. 305: Exhaust Manifold 1. Remove the spark plug wires from the spark plugs. 2. Remove the exhaust manifold, bolts, and gasket. 3. Discard the gasket. be used again if it is not cut or damaged.
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
