Fig. 101: Applying Pinch-Weld Primer 1. Remove all mounds or loose pieces of urethane adhesive from the pinch-weld area. 2. If the original window is being reused, remove all but a thin film of the existing urethane adhesive from the window surface by using a clean utility knife or razor blade scraper. 3. Inspect the following components for the causes of a broken window: The flange of the window opening CAUTION: Refer to GLASS AND SHEET METAL HANDLING CAUTION . IMPORTANT: Remove all but approximately 2 mm (3/64 in) of the existing bead of urethane adhesive from the pinch-weld flange.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
