Fig. 11: Window Lower Supports
Courtesy of GENERAL MOTORS CORP.

12. Remove the window lower supports (1) by using a flat-bladed tool, lightly prying upward in

the middle until the support releases.

IMPORTANT: The window lower supports have molded locks with an

urethane adhesive strip on the back side. Once the window
lower stops have been removed, the stops must be replaced.

2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,

Sierra & Silverado

Fig. 12: Separating Urethane Adhesive From Window
Courtesy of GENERAL MOTORS CORP.

13. Use J 24402-A , J 39032 , or equivalent in order to remove the window. See Special

Tools.

Leave a base of urethane on the pinchweld flange.

The only suitable lubrication is clear water.

IMPORTANT: Keep the cutting edge of the tool against the window in order

to properly separate the urethane adhesive from the window.

2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,

Sierra & Silverado

Fig. 13: Separating Bottom Of Window
Courtesy of GENERAL MOTORS CORP.

14. Remove the bottom of the window from the urethane adhesive using a long utility knife or

similar tool.

2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,

Sierra & Silverado

Fig. 14: View Of Removed Window
Courtesy of GENERAL MOTORS CORP.

15. With the aid of an assistant remove the window (1) from the vehicle.

Installation Procedure

1. Install a stationary window into the opening. Refer to Adhesive Installation of Stationary

Windows (Windshield) or Adhesive Installation of Stationary Windows (Rear
Window).
