Fig. 142: View Of CMP Actuator Magnet, Bolts, Gasket & Oil Seal 1. Install a NEW CMP actuator magnet gasket (753) onto the CMP actuator magnet. 2. Install the CMP actuator magnet (752) to the front cover. IMPORTANT: The gasket surface should be free of oil or other foreign material during assembly. NOTE: Refer to Fastener Notice .
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
