Removal Procedure 1. Remove the throttle body. Refer to Throttle Body Assembly Replacement . 2. Remove the fuel injectors. Refer to Fuel Injector Replacement . Fig. 55: View Of MAP Sensor & Knock Sensor Electrical Connectors 3. Disconnect the following electrical connectors: Manifold absolute pressure (MAP) sensor (1) Knock sensor (2) IMPORTANT: The intake manifold, throttle body, fuel rail, and injectors may be removed as an assembly. If not servicing the
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
