Fig. 4: Pressure Testing Radiator Cap 3. Use the J 24460-01 (1) with J 42401 (2) in order to test the pressure cap. 4. Test the pressure cap for the following conditions: Pressure release when the J 24460-01 exceeds the pressure rating of the pressure cap. Maintain the rated pressure for at least 10 seconds. Note the rate of pressure loss. 5. Replace the pressure cap under the following conditions: The pressure cap does not release pressure which exceeds the rated pressure of the cap. The pressure cap does not hold the rated pressure. COOLING SYSTEM LEAK TESTING Tools Required J 24460-01 Cooling System Pressure Tester J 42401 Radiator Cap/ Surge Tank Test Adapter Testing IMPORTANT: Lubricate J-42401 and pressure cap o-rings with coolant and press cap to seat o-ring on J-42401 before turning to engage CAUTION: Under pressure, the temperature of the solution in the radiator can be considerably higher, without boiling. CAUTION: In order to help avoid being burned, do not remove the
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Cooling - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
