6. Install the pinion gear and the pinion thrust washers. Place the pinion gears and the pinion thrust washers 180 degrees apart. 7. Rotate the pinion gears and the pinion thrust washers 90 degrees and align the pinion gears with the pinion shaft opening in the differential case. 8. Install the thrust block. The open side of the thrust block must face the window opening. 9. Install the pinion shaft. 10. Install the new pinion shaft lock bolt. Tighten: Tighten the pinion shaft lock bolt finger tight. NOTE: Refer to Fastener Notice
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
