gear cam unit in order to align the pinion gear shaft opening with the pinion shaft opening in If the pinion shaft cannot be installed after pressing on the locking differential side gear cam 5. Install the pinion shaft lock bolt. Tighten: Tighten the pinion shaft lock bolt finger tight. 6. Rotate the pinion gear closest to the lock bolt so that one of the teeth is pointing downward, perpendicular to the ring gear flange. 7. Install a brass drift between the locking differential side gear cam unit and the pinion shaft. Press the brass drift in far enough in order to compress the clutch discs. NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
